FinePix S6000fd | Aperture priority | Spot | 3sec | F/8.0 | +1.00 EV | 12.8mm | ISO-200 | Off Compulsory | 2008:02:05 18:07:07

피셔사의 빈티지 진공관 리시버들과 인티엠프들의 계보입니다. 요즘들어 가격이 더 많이 올랐지만. 볼륨부분만

상태가 좋다면 오랫동안 사용하기 좋은 진공관 리시버들의 한 레이블에 속합니다. 현재 시판되는 중국생산

1~2백만원서의 엠프들과 비교하면 내부부품부터 소리까지 상대가 안된다고 생각합니다만. 새것과 50년이 넘는

중고의 단점을 비교한다면 또 다른입장일수 있을듯 합니다. 결국에 취향 차이겠지요.

위 사진에 보이듯이 모노시절 발매되었던 TA-600 과 TA-800 500S 등의 제품들은 AM 기능과 함께 MPX 멀티플렉스

디코더를 따로 사용해야 스테레오를 들을수 있던 아이들 입니다. 그리고 500B 롤 필두로 800B 출력은 조금 적지만

완성도가 높았던 400 500-B의 계량버젼인 500C와 800B의 계량 버젼인 800C 가 출시되었습니다. 개인적으론

스테레오로 초기에 발매된 500B를 더 좋아하지만 대중성에서는 800C 나 500C 리시버들이 튜너부가 밝고 명쾌하여

인기가 더 많습니다.



2012:01:23 08:44:48



위에 사진처럼 피셔 400리시버는 체널당 60W 이고 출력관은 7868을 사용합니다. 7591보다는 15W정도 적은 출력

이지만. 개인적으로 안전성과 내구성에서는 가장 압도적인 제품입니다.  그옆에 500-C와 800-C 는 같은회로에

같은 7591 출력관을 사용하며 500C와 800C의 차이는 튜너부에 AM이 추가되어있는지 없는지의 차이입니다

요즘같은 시대에는 AM방송도 거의없을 더불어 듣는사람이나 많은 방송이 없으니 의미는 없겠지만 출시당시

옵션이 추가되어 개량되어 출시된 제품이기에 출시가격은 800C 가 가장 비샀다고 합니다.



2012:01:23 08:44:53

위에 사진에 아이들은 피셔 진공관 튜너 시리즈의 아이들 입니다. 최초로 출시된 R-200은 사람들이 흔히 알고계신

FM-200B 의 전신인 제품입니다. 내부는 200B튜너와 많이 차이가 납니다. 물량차이로 봐도 크게 차이가 나며 MPX

부분자체가 틀리기에 두제품의 비교는 불가능하다고 생각합니다. 가볍지만 잘만든 FM-50B나 100B등은 가격대비

소리가 좋으며 KM-60 같은 KIT 제품으로 판매하던 제품들도 스펙데로 만들어서 조립해서 사용할수 있었기 떼문에

충분히 좋은소리를 들을수 있습니다. FM-200B부터 정교한 소리가 조금더 우월하며 FM-1000 같은 튜너는 방송용

장비로 랙타입인 FMR-1 을 출시할 정도로 가장뛰어난 성능을 보유한 튜너로도 알려져 있습니다.



2012:01:23 08:45:05

튜너 최초로 오토메틱 센서를 추가시켰던 MF-300 진공관 튜너. 저시절에 센서를 만들었다는 자체로도 엄청난 파격

이자 창조인듯 합니다. 하지만. 저당시 오토메틱 기능은 현재에 와서 얼마나 정교할지는 모르겠습니다. 오토메틱이

있는 트렌지스터 리시버들은 그닥 좋은 성능을 보여주지 못한듯 합니다.





2012:01:23 08:44:58



위에 사진에 보듯 피셔 SA-1000 진공관 파워엠프는 피셔사의 가장고급 파워엠프 였습니다. 지금에 와서 더 유명해진

모노모노 파워엠프도 있지만 출시가격부터 저당시 피셔제품중 가장 고급버젼으로 출시된 제품이지요. 체널당 150W

로 못울리는 스피커가 없다고 유명했었던 제품이기도 하구요. 그리고 피셔하면 가장 유명한 프리엠프가 400-CX 프리

엠프입니다. 음폭의 레인지는 넓지않지만 정교하고 세밀한 소리가 상당히 좋은 프리엠피 입니다 400XC-2 프리역시

개량 출시되어 엄청난 인기를 누렸습니다.  그리고 X-100B 인티엠프 200B의 전신모델 이지만 만듬세나 구동력등은

200B와 견주어도 뒤쳐지지 않는 제품입니다. X-100A는 6BQ5 를 사용했었고 X-100B는 7868 출력관을 사용했습니다

시리즈들 마다 출력관을 틀리게 채용한것도 전략적인 상술이 아니였나 생각합니다.



X-202B와 X-1000같은 경우는 워낙 인기가 많았던 제품으로 현재까지도 피셔 진공관 인티엠프 에서는 최고의 인기와

좋은소리로 유명합니다. 개인적으론 두툼하고 섬세한 EL34 소리를 좋아하기에 X-1000을 더 선호합니다만. 정기정검을

잘받은 제품을 선호합니다.



2012:01:23 08:45:01



피셔 스피커들은 국내에서 인기가 그닥많지 않지만. 그당시 수십명의 엔지니어 들이 물건을 만들고 테스트 하고

출시하기 전까지 수많은 테스트와 노력을 했으리라 봅니다. 피셔 진공관 제품군들이 AR군 스피커들과 매칭이 좋다고

알려져 있지만 그당시 엔지니어 들은 자사에서 생산하는 스피커와 가장 매칭을 많이해서 테스트후 출시하지 않았을까

생각하므로. 피셔스피커들과 피셔 엠프군들의 조합도 나쁘지 않고 당연히 좋다고 생각합니다.









피셔  KIT버젼의 KX 진공관 인티엠프 시리즈들 입니다. X-202B 와 X-100B의 모테가 보이는 제품들 입니다.

























그외 많은 피셔 진공관 인티엠프 들의 사진들 입니다. 피셔의 종류는 참많고 페널색상과 피셔 사의 상징인

제비 모양의 크기와 노브구성등에 따라서 초기형 중기형 후기형이 구별되곤했는데 요즘은 그게 큰의미를

부여하지는 않습니다.

저작자 표시 동일 조건 변경 허락
신고
Posted by 종합전자





RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/12sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:54:09



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/12sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:53:31



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/23sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:52:50



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/21sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:56:00



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/14sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:47:26



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/6sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:47:47



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/16sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:48:30



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/32sec | F/2.8 | 0.00 EV | 6.0mm | ISO-161 | Off Compulsory | 2015:03:23 02:48:53



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/32sec | F/2.8 | 0.00 EV | 6.0mm | ISO-154 | Off Compulsory | 2015:03:23 02:49:03



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/10sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:54:47



RICOH | GR DIGITAL 3 | Aperture priority | Pattern | 1/7sec | F/2.8 | 0.00 EV | 6.0mm | ISO-200 | Off Compulsory | 2015:03:23 02:55:31



이제품은 프로시드 라는 마크레빈슨의 자회사인 마드리갈 오디오에서 만들어낸 시디 라이브러리 대형큐브 시디



플레이어 입니다. 국내에 한대밖에 입고되지 않았다고 하여 이렇게 자료로 남깁니다. 91년도에 출시된 모델로서



그떼당시 최상급 부품으로만 구성시켜 출시한 제품이자. 출시가격이 3천만원가량 했으니. 지금의 아파트전셋값



수준의 비싼 제품이였습니다. 누가 한국에서 썼는지는 몰라도 이런시스템을 쓸정도의 분이시라면 엄청난 부호분?



이 아니신가 생각합니다. 마크레빈슨 자회사 답게 무게가 80KG을 육박하며. 내부의 들어가는 픽업은 필립스에서



반영구 픽업으로 한정생산한 CDM1MK2 가 채용되어 있습니다. CD음반이 100장이들어가는데 1곡으로 15곡변환



가능하다고 했으니 프로용으로 사용하기도 좋았을법합니다만. 리모컨과 더불어 구동시 필요한 키보드 대형센서



까지 사용하기 만만치 않았다고 생각합니다. 이런 기기는 구경하기도 힘들고 볼기회가 없으니 이렇게 자료라도



남겨놓습니다. 모양새는 어떻게 보면 촌스러운데 어떻게 보면 대형 큐브처럼 생겨서 독특한 레트로 디자인에



어울리는 모습이기도 합니다. 왠만한 대형 스피커 만한 사이즈에 저자체가 모두 CDP 한대라고 생각하시면



됩니다. 감사합니다...^^

저작자 표시 동일 조건 변경 허락
신고
Posted by 종합전자



국내에서 오디오 수입상과 레이블 품목이 무엇인지 모르는 분들이 대다수 이기에 정리하여 전화번호와 수입업체

명칭을 모아서 올립니다. 참조하시길 바랍니다...^ ^


  오디오갤러리 CAMPIA 성민음향 다빈월드 한주교역 샘에너지 S&P 디오플러스 미디앤그래픽 우리오디오
  SOVICO 로이코 태인기기 다웅 마란츠코리아 사운드솔루션 세기전자 신원이멕스 디지탈AV 인베스트코리아
  코포산업 케이원 FM Sound 헤이즈 젠오디오 MK엔터프라이즈 오디오디비젼 제이원 소노리스

  SIS 금잔디음향 나소텍 비지니스코리아 소닉크래프트 에이프릴 광우전자 바우하우스 장덕수오디오 크리스탈
  오스오디오 리비도 오디오플러스 에밀레 파워텍 ULSOUND



1. 오디오갤러리 (취급품목=골드문트, FM어쿠스틱, 소너스 파베르, 비비드오디오,오디오 리서치,비올라,

베르티 오디오,나그라 등등..(전화번호 02-926-9084/5 팩스 02-927-5083 위치:성북동)

2.다빈월드 (취급품목=트라이앵글, 패러다임, PMC, 뮤지컬피델리티 ,심오디오 전화번호 02-780-3116

팩스 02-780-2066)

3.한주교역 (취급품목=아크로링크, 팬오디오 전화번호 02-6416-9737)

4.샘애너지 (취급품목=ATOLL(아툴), 블라델리우스, 일렉트로 꼼빠니아, EMM LABS, 요르마 케이블 ,

마르텐, MBL ,팬오디오, 피에가, 로텔, 신세시스, 트렌스로터,비앤나어쿠스틱,와이어월드,와백

전화번호:02-3271-7501-3 팩스:)

5.디오플러스 (취급품목=프로악,네임,실텍,시스템오디오,GSP오디오,반덴훌,AR 전화번호:031-906-5381

A/S:02-546-5381)

6.미디앤그래픽 (취급품목=아포지,HK오디오,야마하 전화번호:02-515-1008 팩스:=02-515-1280)

7.우리오디오 (취급품목=MIT 케이블 에드컴 등등 전화번호:02-2246-0087)

8.소비코(취급품목=JBL,오디오랩,달리,엘락,자디스,렉시콘,마크레빈슨,나드,오르트폰,PSB,QUAD

레벨 전화:02-588-1815 팩스:02-588-1819)

9.로이코(취급품목=맥킨토시,B&W,KRELL,클라세,LINN,제프롤랜드 전화번호:02-322-0500)

10.태인기기 (취급품목=다인오디오,아방가르드,NHT,오디오아날로그,시스템피델리티,MAGNAT

전화번호:02-971-8241 팩스:02-971-9947)

11.다웅 (취급품목=프라이메어,오디오피직,크릭,에포스,노팅함,하베스,TRI,어드밴스어쿠스틱

전화번호:02-587-7300 팩스:02-597-9888)

12.마란츠코리아 (취급품목=마란츠 전제품 전화번호:02-715-9041 팩스 02-715-9040)

13.사운드솔루션 (취급품목=아캄,로그오디오,모니터오디오,와피데일,AE,록산,온쿄,첼로,오라클,

미션,유니슨리서치 전화번호:02-2168-4500 팩스 02-2168-4505)

14.세기전자 (취급품목=보스,오디오테크니카 전화번호:02-751-3331 A/S:02-3446-3516)

15.신원이맥스 (취급품목=패스랩 프랑코세브린 전화번호:02-707-1592/3 팩스:02-707-1594)

16.디지털AV (취급품목=폴크오디오 전화번호: 02-957-8521)

17.인베스트코리아 (취급품목=이소폰,스털링 등등.. 전화번호:031-932-0606 팩스:031-932-3346)

18.코포사운드 (취급품목=트렌스페어런트,VTL,HALCRO, 전화번호:02-497-1502)

19.케이원 (취급품목=BAT,볼더,코드,한센오디오,킴버케이블,매그넘다이나랩,메르디안,패토스

윌슨오디오,WBT 전화번호:02-553-3161/2 팩스:02-553-3397)

20.FM사운드 (취급품목=SME ,E.A.R, Lyra 등등, 전화번호:02-312-2210 팩스:02-312-2879)

21.헤이즈 (취급품목=포칼 JM LABS ,QED,어쿠스틱 솔리드 전화번호:02-558-4581 팩스:02-558-0698)

22.MK엔터프라이즈 (취급품목=캠브릿지오디오,모던쇼트,안소닉갈로,럭스만,포커스오디오,PS오디오

전화번호:02-715-4585 A/S: 02-707-1050)

23.오디오디비젼 (취급품목=아큐페이즈,후루텍 전화번호: 031-420-5698)

24.제이원 (취급품목=멜로디,하모닉 케이블,로버츠 라디오 전화번호:02-706-5436 팩스:02-706-5435)

25.소노리스 (취급품목=소노리스 전제품 전화번호:02-581-3094/5)

26.SIS(취급품목=마에스트로 시리즈 SIS시리즈 전품목 전화번호:02-2679-7165)

27.금잔디음향(취급품목=칼라스 전제품 전화번호:02-953-0940)

28.비지니스코리아(취급품목=판테온 시리즈 전품목 전화번호:02-401-1881)

29.소닉크래프트(취급품목=오퍼스시리즈 전제품 이니그마 시리즈 마일스톤 전제품 전화번호:031-384-5258)

30.에이프릴뮤직(취급품목=스텔로 시리즈 전제품 오라노트 전제품 전화번호:02-3446-5561 A/S:02-3446-5561)

31.광우전자(취급품목=에밀레 MUSE 시리즈 전제품 전화번호:055-382-7373)

31.바우하우스(취급품목=오디오랩 수납장 스텐드등 제작 판매 전제품 전화번호:031-575-0933)

32.오디오플러스(취급품목= 오디오플러스 스피커케이블 인터케이블 모든제품 전화번호:02-991-5782)

33.파워텍(취급품목=파워텍 AVR 전원장치 모든제품 전화번호:02-702-1212)

34.UL사운드(취급품목= UL사운드 어메이징 시리즈 진공관엠프 포노엠프 전제품 전화번호:031-774-1571)

35.지구스피커(취급품목=모든 스피커 수리A/S 전문점 위치:세운상가 전화번호:017-272-6167)

36:형제후끼(취급품목=모든스피커 엠프의 샷시부분 도색작업 위치:세운상가 전화번호:02-2267-7993)

37:에이스전자(취급품목=모든 오디오기기 A/S 수리 업체 위치:용산 원효상가 가격은 싸지 않음.

전화번호:02-713-9401)

38.고기사님(취급품목=아주큰 대형 스피커 전문 배달 셋업 스케줄 잡고 작업하셔야 합니다.

전화번호:011-273-7848)

39.우리용달(취급품목=위와같이 1.5톤 1톤 트럭으로 대형 스피커등 고급기종 운반전문 업체

전화번호:02-712-1515)

저작자 표시 변경 금지
신고
Posted by 종합전자




예전에도 제가 올렸던 적이 있는데요 그떼 올린 내용보다 조금더 충실하고 많은기기들의 픽업명이 있을거 같아

해외사이트에서 펌해왔습니다. 출처는 http://www.dutchaudioclassics.nl/ 이곳이며 조금더 좋은 자료를 위해

올려드립니다.^^















A | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

ABBINGDON AMR CD-77
TDA1541A
Sony

ACCUPHASE DAC10
2 x AD1853
D/A converter

ACCUPHASE DAC20
2 x AD1955
D/A converter

ACCUPHASE DC-61
12 x PCM1702 – SM5843AP
D/A converter

ACCUPHASE DC-81
8 x ICL8010ACPD – 2 x SM5801P
D/A converter

ACCUPHASE DC-81L
10 x ICL8010ACPD – SM5803AP
D/A converter

ACCUPHASE DC-91
16 x PCM63P-K
D/A converter

ACCUPHASE DC-101
6 x AD1853
D/A converter

ACCUPHASE DC-330
6 x AD1853
D/A converter

ACCUPHASE DC-801
8 x AD1955
D/A converter

ACCUPHASE DP-11
2 x PCM58P-S – SM5803AP
Sony KSS-190A

ACCUPHASE DP-55
6 x PCM1702 – SM5843AP
Sony KSS-240A

ACCUPHASE DP-55V
2 x AD1853
Sony KSS-240A

ACCUPHASE DP-57
2 x PCM1796 – AK4114VQ
Sony KSS-240A

ACCUPHASE DP-60
2 x PCM58P-K – SM5803AP
Sony KSS-190A

ACCUPHASE DP-65
8 x PCM1702 – SM5843AP
Sony KSS-272A

ACCUPHASE DP-65V
8 x PCM1702 – SM5843AS
Sony KSS-272A

ACCUPHASE DP-67
4 x AD1955 – AK4114VQ
Sony KSS-240A

ACCUPHASE DP-70
8 x ICL8010ACPD
Sony BU-1C

ACCUPHASE DP-70V
10 x ICL8010ACPD – SM5803AP
Sony KSS-190A

ACCUPHASE DP-75
16 x PCM1702 – SM5843AP
Sony KSS-272A

ACCUPHASE DP-75V
6 x AD1853
Sony KSS-272A

ACCUPHASE DP-77
4 x AD1853
SACD Sony

ACCUPHASE DP-78
6 x AD1955 – AK4114VQ
SACD

ACCUPHASE DP-80
Transport – CX23035
Sony BU-1C


ACCUPHASE DP-80L
Transport – CXD1125QZ
Sony KSS-190A

ACCUPHASE DP-85
6 x AD1853
SACD Sony KHM-230AAA

ACCUPHASE DP-90
Transport – CXD2500BQ
Sony KSS-272A

ACCUPHASE DP-100
Transport
SACD Sony KHS-180A

ACCUPHASE DP-400
2 x PCM1796
Sony KSS-213C

ACCUPHASE DP-500
4 x PCM1796
Sony KSS-213C

ACCUPHASE DP-600
6 x AD1955
SACD Sony KHM-230AAA

ACCUPHASE DP-700
8 x AD1955
SACD Sony KHM-230AAA

ACCUPHASE DP-800
Transport
SACD Sony KHM-230AAA

ACOUSTIC RESEARCH CD-04
2 x TDA1540P – SAA7030
CDM-2

ACOUSTIC RESEARCH CD-06
TDA1541
CDM-2

ACOUSTIC RESEARCH CD-06SE
TDA1541A
CDM-4

ACOUSTIC RESEARCH CD-07
TDA1541 – SAA7220
CDM-4

ACOUSTIC RESEARCH CD-07SE
SAA7350
CDM-4

ACURUS ACD 11
MN66271RA
Panasonic RAE0113Z

ADC CD-250XR
PCM54HP
KSS-123A


ADC CD-350XR
PCM54HP
KSS-123A

ADCOM GCD-575
TDA1541A
KSS-212B

ADCOM GCD-750
4 x PCM1702 – PMD100
Panasonic RAE0113Z

ADCOM GDA-600
2 x PCM63P – DF1700P – CS8412-CP
D/A converter

ADCOM GDA-700
2 x PCM1702 – PMD100
D/A converter

ADS CD3
2 x CX20152 – CX23034
KSS-121A / KSS-123A

ADVANTAGE CD1
2 x PCM1702 – NPC filter
Pioneer Stable Platter PEA1343

AIWA DX-1000
PCM53JG-V
-

AIWA DX-M45
TDA1541
CDM-4/25

AIWA DX-M75
LC7881
KSS-150A

AIWA XC-002
1 x PCM56P
KSS-150A

AIWA XC-003
1 x PCM56P – PD0036
KSS-150A

AIWA XC-004
2 x PCM56P
KSS-150A

AIWA XC-005
2 x PCM58P – YM3414
KSS-150A

AIWA XC-007
2 x PCM56P-K
KSS-151A

AIWA XC-300
TC9237N
KSS-210A

AIWA XC-333
µPD6376
KSS-210A

AIWA XC-500
TC9237N
KSS-210A

AIWA XC-777
2 x PCM61P
KSS-210B

AIWA XC-950
SAA7350 – SM5840BS
KSS-210A / KSS-212A

A&D DP-7000
2 x PCM56P
KSS-151A

A&D DP-9000
2 x PCM56P
KSS-151A

AKAI CD-26
TDA1543A
KSS-210A

AKAI CD-32
PCM56P
KSS-150A

AKAI CD-37
PCM67P
KSS-210A

AKAI CD-52
2 x PCM56P
KSS-150A

AKAI CD-55
2 x AD1856N / PCM56P – PD0036
KSS-210A / KSS-150A
AKAI CD-57
PCM67P-J – CXD1167Q
KSS-210A

AKAI CD-62
2 x PCM56P – YM3414
Sankyo SPM1001 – MLP-10-E2

AKAI CD-69
PCM63P – SM5813
KSS-150A / KSS-210A

AKAI CD-73
2 x PCM56P
KSS-151A

AKAI CD-79
2 x PCM63P-K – SM5813AP
KSS-150A / KSS-210A

AKAI CD-93
2 x PCM56P
KSS-151A

AKAI CD-A7
PCM53JP-V – HD61902A
KSS-120A / KSS-123A

AKAI CD-A405
1 x PCM56P
KSS-123A

AKAI CD-D1
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)

AKAI CD-M77
CX20017
-

AKAI CD-M459
PCM56

AKAI CD-M719
1 x PCM56P
MLP-7

AKAI CD-M839
PCM56
-

ALBA CD420
PCM54

ALCHEMIST FORSETI APD32A
2 x CS4334 – CS8414
Philips

ALCHEMIST FORSETI APD33A
Transport
Philips ECO Module

ALCHEMIST FORSETI APD34A
2 x CS4334
D/A converter
PDF
ALCHEMIST KRAKEN APD39A
CS4334 – CS8414
Philips
PDF
ALCHEMIST NEXUS APD32A
2 x TDA1549
CDM 12.1
PDF
ALCHEMIST TS-D-1
CS4334 – CS8414
D/A converter
PDF
ALPINE AD-7100
CX890
Toshiba OPH-31
PDF
ALTIS AUDIO CENTAURI
Transport
CDM 12 Ind
PDF
AMC CD6
SAA7323GP – SAA7220P/B
CDM-4/19
PDF
AMC CDM7
SAA7323GP
CDM-4/19
PDF
AMC CD8A
MN6474
KSS-210A
PDF
AMC CD8B
PCM1716
KSS-213
PDF
AMC CD8D
2 x PCM1730
-
PDF
AMC CD9
MN6474 – CDX1167Q
KSS-210A
PDF
AMC CD60
PCM1716
-
PDF
ANTHEM CD1
2 x PCM1702 – PMD100
KSK-2000A
PDF
APOGEE DA-1000
2 x PCM63P
D/A converter
PDF
APRIL MUSIC STELLO CDT200
Transport
VAM 1210
PDF
APRIL MUSIC STELLO DA100
AKM4395
D/A converter
PDF
APRIL MUSIC STELLO DA220
AKM4395
D/A converter
PDF
ARAGON D2A
2 x PCM58P-J – CXD1144 – YM3623B
D/A converter
PDF
ARAGON D2A2
2 x PCM63P-J – PMD100
D/A converter
PDF
ARCAM ALPHA
TDA1541A – SAA7220P/B
CDM-4/19
PDF
ARCAM ALPHA ONE
PCM1710
-
PDF
ARCAM ALPHA PLUS
TDA1541A – SAA7220P/B
CDM-4/19
PDF
ARCAM ALPHA 5
TDA1541A – SAA7220P/B
CDM-9/44
PDF
ARCAM ALPHA 5 PLUS
TDA1541A
CDM-9
PDF
ARCAM ALPHA 6
SM5864 – SM5840
CDM-9
PDF
ARCAM ALPHA 7
PCM1710
Sony CDM14
PDF
ARCAM ALPHA 7SE
PCM1716
Sony CDM14
PDF
ARCAM ALPHA 8
SM5864AP – SM5843
Sony CDM14
PDF
ARCAM ALPHA 8SE
SM5864AP – PMD100
Sony CDM14
PDF
ARCAM ALPHA 9
dCS RingDAC – PMD100
KSS-240A
PDF
ARCAM DELTA 70.2
TDA1541A-S1 (Single Crown)
CDM-4/11 / CDM-4/31
PDF
ARCAM DELTA 70.3
SAA7350
CDM-4
PDF
ARCAM DELTA 110
2 x SAA7321
-
PDF
ARCAM DELTA 110.2
2 x PCM67P-J
-
PDF
ARCAM DELTA 170
Transport
CDM-1 Mk II
PDF
ARCAM DELTA 270
PCM69AP-J – YSF210B-D (filter)
CDM-9
PDF
ARCAM DELTA BOX 1
TDA1541A – SAA7220P/B
D/A converter
PDF
ARCAM DELTA BOX 2
TDA1541A
D/A converter
PDF
ARCAM DELTA BOX 3
4 x SAA7321
D/A converter
PDF
ARCAM DELTA BOX 5
PCM67P-J
D/A converter
PDF
ARCAM DELTA BOX 50
PCM69AP – YM3623B
D/A converter
PDF
ARCAM DIVA CD72
PCM1716
KSS-213C
PDF
ARCAM DIVA CD73T
WM8740
KSS-213C
PDF
ARCAM DIVA CD82
2 x WM8740s
KSS-213C
PDF
ARCAM DIVA CD92
dCS RingDAC 24bit + PMD200
KSS-213C
PDF
ARCAM DIVA CD93
4 x WM8740s
-
PDF
ARCAM DIVA CD192
4 x WM8740s
-
PDF
ARCAM FMJ CD17
WM8741
-
PDF
ARCAM FMJ CD23T
dCS RingDAC + HDCD
KSS-213B / KSS-240A
PDF
ARCAM FMJ CD33
4 x WM8740 – AD1896A
KSS-213
PDF
ARCAM FMJ CD36
4 x WM8740 – AD1896A
KSS-213
PDF
ARCAM FMJ CD37
WM8741
-
PDF
ARISTON CD PLAYER
TDA1541A-S1 (Single Crown)
CDM-4/19
PDF
ASSEMBLAGE DAC-1.5
2 x PCM1702 – PMD100 – CS8412
D/A converter
PDF
ASSEMBLAGE DAC-2
2 x PCM1702 – PMD100 – CS8412-CP
D/A converter
PDF
ASSEMBLAGE DAC-2.6
2 x PCM1704 – PMD100 – CS8412-CS
D/A converter
PDF
ASSEMBLAGE DAC-2.7
2 x PCM1704 – PMD200 – CS8414-CS
D/A converter
PDF
ASSEMBLAGE DAC-3
4 x PCM1704 – PMD100 – CS8414-CS
D/A converter
PDF
ASSEMBLAGE DAC-3.1
4 x PCM1704 – PMD200
D/A converter
PDF
ATOLL CD 200
PCM1794
VAM 1202/12
PDF
AUDIO AERO CAPITOLE
AD1853
Philips CD-Pro 2 (VAM 1254)
PDF
AUDIO AERO PRESTIGE SACD
PCM1792
SACD
PDF
AUDIO AERO PRIMA
PCM1739
VAM 1201
PDF
AUDIO AGILE JOCKER’S CD
SM5872BS
CDM 12
PDF
AUDIO ALCHEMY ACD-1
AD1864N
-
PDF
AUDIO ALCHEMY DDE v1.0
SAA7323GP – SAA7274P
D/A converter
PDF
AUDIO ALCHEMY DDE v1.2
2 x AD1862 – PMD100
D/A converter
PDF
AUDIO ALCHEMY DDE v2.0
SAA7350GP – DF1700P – YM3623B
D/A converter
PDF
AUDIO ALCHEMY DDE v3.0
2 x AD1862N – PMD100 – CS8412-CP
D/A converter
PDF
AUDIO ALCHEMY D-I-T-B
2 x AD1860 – YM3433
D/A converter
PDF
AUDIO ALCHEMY DDS PRO
Transport
PEA1179 Stable Platter
PDF
AUDIO ALCHEMY XDP
TDA1547 – SAA7350 – DF1700P
D/A converter
PDF
AUDIO ANALOGUE MAESTRO
AD1855
KSS-210A
PDF
AUDIO ANALOGUE PAGANINI
CS4390
KSS-210A
PDF
Audio Crafters Guild X-DAC 3.0
CS4328-CP – AD1891JN
D/A converter
PDF
AUDIO DYNAMICS CD-2000E
1 x PCM56P-J – SM5807EP
CDM 12
PDF
AUDIO INNOVATIONS ALTO
PCM1716
-
PDF
AUDIO NOTE CD-1
PCM1710
Sony / Samsung SOH-A1
PDF
AUDIO NOTE CD-2
AD1865 – SM5843AP
KSS-210 / SOH-A1
PDF
AUDIO NOTE CD-2.1x
AD1865N
KSS-213
PDF
AUDIO NOTE CD-3
AD1865 – SM5843
SOH-A1
PDF
AUDIO NOTE CD-3.1x
AD1865N
KSS-213
PDF
AUDIO NOTE CDT-ZERO
PCM1710
KSS-213
PDF
AUDIO NOTE DAC-1
PCM63P
D/A converter
PDF
AUDIO NOTE DAC-2
PCM63P-J
D/A converter
PDF
AUDIO NOTE DAC-3
PCM63P-K
D/A converter
PDF
AUDIO NOTE DAC-4
PCM63P-K
D/A converter
PDF
AUDIO NOTE DAC-5
AD1862N-J
D/A converter
PDF
AUDIO RESEARCH CD1
SAA7341
CDM 12
PDF
AUDIO RESEARCH CD2
CS4329-KP
CDM 12.1
PDF
AUDIO RESEARCH CDT1
Transport
CDM 12.1
PDF
AUDIO RESEARCH DAC1-20
UltraAnalog D20400A – SM5803APT
D/A converter
PDF
AUDIO RESEARCH DAC2
UltraAnalog D20400A – NPC filter
D/A converter
PDF
AUDIO RESEARCH DAC3
CS4328-KP – CS8412
D/A converter
PDF
AUDIO SYNTHESIS DA-X
1 x D20400A / 2x PCM63P - SM5803APT
D/A converter
PDF
AUDIO SYNTHESIS DAX-2
2 x UA D20400A – SM5842AP / PMD100
D/A converter
PDF
AUDIO SYNTHESIS DAX-Decade
2 x UA D20400A – PMD100 - CS8412-CP
D/A converter
PDF
AUDIOLAB 8000 CD
CS4329
CDM 12.4
PDF
AUDIOLAB 8000 CDM
Transport
CDM-9 Pro
PDF
AUDIOLAB 8000 CDM II
Transport
Philips CD-Pro (VAM 1252)
PDF
AUDIOLAB 8000 DAC
TDA1547 – SAA7350 – SM5843AP
D/A converter
PDF
AUDIOLABOR 531
PCM1702
CDM-1 Mk II
PDF
AUDIOMECA DAMNATION
Transport
CDM 12
PDF
AUDIOMECA ELIXIR
SAA7321GP – CS8412-CP
D/A converter
PDF
AUDIOMECA OBSESSION
TDA1305T
CEC-Sanyo SF-P1
PDF
AUDIONET ART V2
AKM4395 – CS8420
CDM 12.1
PDF
AUDIONET ART G2
2 x AD1955 – SRC4192
VAM 1202
PDF
AURA CD-50
SAA7321GP
CDM-9
PDF
AURA CD-100
TDA1305T – SAA7345
-
PDF
AUREX XR-V9R
TD6709N
-
PDF
AUREX XR-Z90
CX890
Toshiba OPH-31
PDF
AVI SC2000MC
PCM63P – DF1700 – SAA7310
CDM-9/44 / CDM 12.1
PDF
AYON CD-1
CS4398
KSS-213Q
PDF
AYON CD-3
CS4398
KSS-213Q
PDF
AYRE CX-7
PCM1738 – DF1706
DVD-ROM DVS DSL-710A
PDF
AYRE D-1
4 x PCM1704 – DF1704
DVD

B | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
Balanced Audio Tech. VK-D5
4 x PCM63P-K – PMD100
CDM 12
PDF
Bang & Olufsen Beogram CDX
2 x TDA1540P – SAA7030
CDM-1
PDF
Bang & Olufsen Beogram CDX2
TDA1541A – SAA7220P/B
CDM-2/10
PDF
Bang & Olufsen Beogram CD3300
TDA1541
CDM-2/10
PDF
Bang & Olufsen Beogram CD5500
TDA1541A – SAA7220P/B
CDM-4/11
PDF
BEL CANTO DAC 3
PCM1792
D/A converter
PDF
BENCHMARK DAC 1
AD1853
D/A converter
PDF
BERENDSEN CDP I
CS4390
-
PDF
BERENDSEN CDP II
CS4327
-
PDF
BESTAR CD 900
YM3020 – YM3805
Hitachi HOP-M3
PDF
BETA LASER ADD 200
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)
PDF
BLAUPUNKT CP-2650
PCM54HP – YM2601
MLP-3C
PDF
BLAUPUNKT CP-2790
LC7881 – CXD1135QZ
KSS-210A
PDF
BLAUPUNKT CP-2800
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)
PDF
BLAUPUNKT CP-2850
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-4/11
PDF
BLAUPUNKT CP-2890 Artech
2 x PCM56P – SM5807BP
KSS-150A
PDF
BLAUPUNKT CP-2950 Artech
PCM54HP – YM2601
MLP-3C
PDF
BLAUPUNKT CP-2990 Artech
2 x PCM56P-J
KSS-152A
PDF
BOW TECHNOLOGIES Wizard
TDA1305
CDM 12 Pro
PDF
BOW TECHNOLOGIES ZZ-Eight
4 x PCM1702-K – PMD100
CDM 12 Pro
PDF
BRAUN CD2/3
2 x PCM56P-J – CXD1135QZ
KSS-152A
PDF
BRAUN CD3
2 x CX20152 – CX23034
KSS-121A / KSS-123A
PDF
BRAUN CD4
2 x PCM56P-J – YM3414
KSS-123A
PDF
BRYSTON BDA-1
2 x CS4398
D/A converter
PDF
BURMESTER 001
4 x PCM1704
Philips CD-Pro (VAM 1252)
PDF
BURMESTER 006
2 x PCM1704
Philips VAM 1250
PDF
BURMESTER 979
Transport
CDM-9 Pro

C | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
California Audio Labs Alpha
CS4328-KP – CS8412-CP
D/A converter
PDF
California Audio Labs Aria Mk III
2 x PCM58P-K
SOAD70A
PDF
California Audio Labs CL10
PCM1702 + HDCD
-
PDF
California Audio Labs CL15
PCM1702 + HDCD
-
PDF
California Audio Labs Delta
Transport
Panasonic RAE0113Z
PDF
California Audio Labs DX-1
MN66271
Panasonic RAE0113Z
PDF
California Audio Labs Gamma
PCM1710U – CS8412-CP
D/A converter
PDF
California Audio Labs Icon
2 x PCM61P – SM5813AP
SOAD70A
PDF
California Audio Labs Icon Mk II
2 x PCM1702 + HDCD
Panasonic RAE0113Z
PDF
California Audio Labs Sigma
CS4328 – CS8412-CP
D/A converter
PDF
California Audio Labs Sigma II
CS4328-KP – CS8412-CP
D/A converter
PDF
California Audio Labs Tempest
2 x TDA1540 – SAA7030
CDM-2
PDF
California Audio Labs Tempest II
TDA1541 – SAA7220P/A
CDM-4/11
PDF
CAMBRIDGE AUDIO azur340c
CS4338
-
PDF
CAMBRIDGE AUDIO azur540c
1 x Wolfson WM8716
Sony KSS-213
PDF
CAMBRIDGE AUDIO azur540c v2
1 x Wolfson WM8740
Sanyo SF-P101N
PDF
CAMBRIDGE AUDIO azur640c
1 x Wolfson WM8740
Sony KSS-213C
PDF
CAMBRIDGE AUDIO azur640c v2
2 x Wolfson WM8740
Sanyo SF-P101N
PDF
CAMBRIDGE AUDIO azur840c
2 x AD1955
Sanyo SF-P101N
PDF
CAMBRIDGE AUDIO CD1
6 x TDA1540
CDM-1
PDF
CAMBRIDGE AUDIO CD2
4 x TDA1541 – SAA7220
CDM-2/10
PDF
CAMBRIDGE AUDIO CD3
4 x TDA1541A – SAA7220P/B
CDM-1 Mk II
PDF
CAMBRIDGE AUDIO CD3M
Transport
CDM-1 Mk II
PDF
CAMBRIDGE AUDIO CD4
TDA1305
Sanyo
PDF
CAMBRIDGE AUDIO CD4SE
CS4327KS
CDM 12
PDF
CAMBRIDGE AUDIO CD6
2 x TDA1305T
Sanyo SF-91
PDF
CAMBRIDGE AUDIO D300SE
CS4338
Sony
PDF
CAMBRIDGE AUDIO D500
CS4327
KSS-213
PDF
CAMBRIDGE AUDIO D500SE
CS4391
KSS-213
PDF
Cambridge Audio DAC 3
2 x TDA1305T
D/A converter
PDF
Cambridge Audio DAC 3 D/A
4 x TDA1541A-S1
D/A converter
PDF
Cambridge Audio DACMAGIC 1
2 x TDA1305
D/A converter
PDF
Cambridge Audio DACMAGIC 2
2 x TDA1305
D/A converter
PDF
Cambridge Audio DISCMAGIC 1
Transport – CXD1167
Sanyo SF-91
PDF
CAMBRIDGE AUDIO S700
SAA7350
D/A converter
PDF
CARAT C57
PCM1732U
VAM 1202
PDF
CARAT C57 Mk2
PCM1796
-
PDF
CARVER DTL-50
PCM54HP – YM2601
MLP-3C
PDF
CARVER SD/A 360
SAA7350 – YM7121C
-
PDF
CARVER SD/A 450
MN6474
-
PDF
CARVER TL-3100
LC7881-C
-
PDF
CARY AUDIO DESIGN CD-300
2 x PCM63P-K – PMD100
Pioneer Stable Platter PEA1030
PDF
CARY AUDIO DESIGN CD-301
SM5872
-
PDF
CARY AUDIO DESIGN CD-303
2 x PCM1704U – PMD100
VAM 1202/12
PDF
CARY AUDIO DESIGN CD 303/200
2 x PCM1704U-K – PMD100
VAM 1202
PDF
CARY AUDIO DESIGN CD 303/300
2 x PCM1792U
DVD-ROM DVS DSL-710ALT
PDF
CARY AUDIO DESIGN CD 306
4 x PCM1794U
SCD-1
PDF
CARY AUDIO DESIGN CD-308
PCM1704U + HDCD
CDM 12
PDF
CARY AUDIO DESIGN CDP 1
2 x PCM1792
DVD-ROM DVS DSL-710ALT
PDF
CASEA CEPHEUS
CS43122 – CS8416
D/A converter
PDF
CASEA CORONA
CS4390-KP – CS8412
D/A converter
PDF
CAYIN CD-50T
PCM1732
KSS-213Q
PDF
CAYIN CDT-15A
PCM1732
Philips CDM 12.10
PDF
CAYIN CDT-17A
2 x PCM1792
Philips VAM 1206

CAYIN CDT-23
PCM1792
KSS-213
CAYIN VENUS CD-10i
PCM1792
-

C.E.C. 530CDII
Y3015
-

C.E.C. 540CD / 640CD
LC7880 ?
Sanyo SF-P1

C.E.C. 630CD
PCM56P – YM3815
Sanyo SF-86

C.E.C. 680CD
LC7881
Sanyo SF-P1

C.E.C. 780CD
LC7881 – YM7121R (filter)
Sanyo SF-P1

CEC CD2100
TDA1305T
CEC-Sanyo SF-P1 / SF-90

CEC CD3100
TDA1305T / PCM67U
CEC-Sanyo SF-P1 / SF-90

CEC CD3300
PCM1738
CEC-Sanyo SF-P101N

CEC CD3300R
PCM1796
CEC-Sanyo SF-P101N

CEC CD5300
2 x PCM1796
CEC-Sanyo SF-P101N


CEC DA53
2 x PCM1796 + PCM2906
D/A converter

CEC DX1N
2 x PCM1792

CEC DX71 Mk II
2 x SM5865CM
D/A converter

CEC TL0
Transport
CEC-Sanyo SF-90

CEC TL1
Transport
CEC-Sanyo SF-90

CEC TL2
Transport

CEC TL51XR
2 x PCM1796
CEC-Sanyo SF-P101N

CEC TL51XZ
SM5865CM
CEC-Sanyo SF-P101N

CEC TL51Z
4 x PCM1704 – DF1706
CEC-Sanyo SF-P1

CEC TL51Z Mk II
SM5865CM
CEC-Sanyo SF-P101N

CEC TL53Z
2 x PCM1792
-

CEC TL5100Z
2 x PCM1702 – SM5843AP
CEC-Sanyo SF-P1

CLAIRTONE MODEL 2704
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)

CLASSE AUDIO CDP-1
UltraAnalog D20400 – PMD100
CDM 12.4

CLASSE AUDIO CDP-1.5
2 x PCM1704
CEC-Sanyo SF-P

CLASSE AUDIO CDP.3
2 x PCM1702 – PMD100
CEC-Sanyo SF-P1

CLASSE AUDIO CDP.5
PCM1702
CDM 12.4

CLASSE AUDIO CDP-10
2 x PCM1738
Philips VAE 1250

CLASSE AUDIO CDP-100
2 x PCM1738 – PMD200
Philips VAE 1250 Pro

CLASSE AUDIO CDP-102
1 x CS4398
DVD-ROM TEAC

CLASSE AUDIO CDP-202
2 x PCM1792
DVD-ROM TEAC

CLASSE AUDIO CDP-300
3 x CS4398
DVD-ROM TEAC

CLASSE AUDIO CDP-502
3 x PCM1792
DVD

CLASSE AUDIO CDT-1
Transport
CDM 12.4

CLASSE AUDIO DAC-1
2 x UltraAnalog D20400A – PMD100
D/A converter

COMBAK REIMYO DAP-777
JVC – JCE4315 – K2
D/A converter

CONDOR CD950
YM3020
-

CONSONANCE CD 120
CS4396 / TDA1543

CONSONANCE Droplet CDP5.0
CS4398
KSS-213 / CDM 12

COPLAND CDA 266
2 x PCM63P – PMD100
KSS-240A

COPLAND CDA 277
2 x PCM63P – PMD100
VRDS CMK-4 – KSS-240A

COPLAND CDA 288
4 x PCM63P-K – PMD100
VRDS CMK-4 – KSS-240A

COPLAND CDA 289
4 x PCM63P – PMD100
KSS-240A

COUNTERPOINT DA-10E-AD
2 x AD1862N – DF1700P – CS8412-CP
D/A converter



COUNTERPOINT DA-10E-BB
PCM69P
D/A converter

COUNTERPOINT DA-10E-CS
CS4328
D/A converter

COUNTERPOINT DA-10E-UA
UltraAnalog D20400
D/A converter

COUNTERPOINT DA-11
Transport
CDM 12

CREEK CD42 Mk 2
CS4328
-

CREEK CD43
CS4390
CDM 14 Sony

CREEK CD43 Mk 2
CS4396
CDM 12

CREEK CD50
CS4396
CDM 12

CREEK CD50 Mk 2
CS4396
DVD-ROM DVS DSL-710A

CREEK CD53
CS4396
CDM 12

CREEK CD60
TDA1541A-S1 – SAA7220P/B
CDM-4/14

CREEK DAC 60
2 x PCM63P-K – DF1700P – YM3623B
D/A converter

CREEK DESTINY
CS4396
-

CREEK EVO CDP
PCM1738
Philips VAM 1201

CREEK EVOLUTION 2
PCM1796
-

CROWN AVC-9500
AD1864
-

CROWN CD2111R
LC7881
-

D | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

DBX DX 5
2 x PCM56P
-

DBX DX 900
2 x PCM56P-S – SM5804B
KSS-152A

DENON CDR-1000
AD1855
Writer

DENON DA-500
2 x PCM1702-J – SM5845AF – YM3623B
D/A converter

DENON DA-S1
4 x PCM1702-K – SM5843AP
D/A converter

DENON DP-S1
Transport
KSS-151A

DENON DAP-2500A
2 x PCM61P – SM5813AP – YM3623B
D/A converter

DENON DAP-5500
4 x PCM56P-K – SM5804D
D/A converter

DENON DCD-7.5
2 x PCM56P-L – SM5840CP
KSS-240A

DENON DCD-73M
1 x PCM56P
KSS-150A

DENON DCD-201SA
2 x PCM1702-L
-

DENON DCD-210
2 x PCM56P-L – CXD2551P
KSS-210A

DENON DCD-300
PCM54HP
KSS-123 / KSS-152

DENON DCD-335
PCM1716E
KSS-210A

DENON DCD-425
PCM1712
KSS-210A

DENON DCD-435
PCM1716E
KSS-213

DENON DCD-460
2 x PCM56P-L
KSS-210A

DENON DCD-480
2 x PCM61P-L – SM5840AP
KSS-240A

DENON DCD-485
PCM1735
KSS-213

DENON DCD-500
PCM54HP
KSS-123 / KSS-152

DENON DCD-500AE
PCM1791
KSS-213C

DENON DCD-520
2 x PCM56P – SM5807FP
KSS-150A

DENON DCD-560
2 x PCM61P-L
KSS-210A

DENON DCD-580
PCM67P

DENON DCD-590
2 x PCM61P-L – SM5840BP
KSS-240A

DENON DCD-595
2 x PCM61P-L – SM5841BP
KSS-240A

DENON DCD-600
1 x PCM56P
KSS-152A

DENON DCD-610
1 x PCM56P-L
KSS-210A

DENON DCD-615
2 x PCM61P-L – SM5841BP
KSS-240A

DENON DCD-620
2 x PCM61P-L
KSS-210A

DENON DCD-625
2 x PCM61P-L – SM5841
KSS-240A

DENON DCD-635
2 x PCM61P-L – SM5841BP
KSS-213B

DENON DCD-650F
PCM1700P
-

DENON DCD-655
2 x PCM1702
KSS-213

DENON DCD-660
2 x PCM61P – CXD2551P
KSS-210A

DENON DCD-685
2 x PCM1702
KSS-213

DENON DCD-690
2 x PCM61P-L – SM5840BP
KSS-240A

DENON DCD-695
2 x PCM61P-L – SM5841BP
KSS-240A

DENON DCD-700
PCM54HP
KSS-123 / KSS-152

DENON DCD-700AE
PCM1791

DENON DCD-715
2 x PCM61P-L – SM5841BP
KSS-240A

DENON DCD-725
2 x PCM61P-L
KSS-213

DENON DCD-735
2 x PCM61P-L – SM5845AF
KSS-213B

DENON DCD-755AR
2 x PCM1702 – SM5845AF
KSS-213C

DENON DCD-755 II
2 x PCM1702
KSS-213C

DENON DCD-770
2 x PCM61P-L – SM5840
KSS-240A

DENON DCD-800
1 x PCM56P – SM5807CP
KSS-152A

DENON DCD-810
2 x PCM56P – SM5807
KSS-150A

DENON DCD-815
2 x PCM61P
KSS-213

DENON DCD-820
2 x PCM56P
KSS-150A

DENON DCD-825
2 x PCM61P – SM5841BP
KSS-240A

DENON DCD-830
2 x PCM56P
KSS-150A

DENON DCD-835
2 x PCM61P-L
Sharp H8147AF

DENON DCD-860
2 x PCM61P
KSS-210A

DENON DCD-890
2 x PCM61P
KSS-240A

DENON DCD-895
2 x PCM61P – SM5841AP
KSS-240A

DENON DCD-900
1 x PCM56P-J
KSS-123A

DENON DCD-910
2 x PCM56P – SM5807FP / PD0036
KSS-150A

DENON DCD-920
2 x PCM61P – SM5818AP
KSS-210A

DENON DCD-960
2 x PCM61P – SM5840AP
KSS-150A

DENON DCD-970
2 x PCM61P-J
KSS-240A

DENON DCD-980
2 x PCM61P
KSS-240A

DENON DCD-1000
1 x PCM53JP-V – CX23035
KSS-121A / KSS-123A

DENON DCD-1015
2 x PCM61P – SM5845AF
KSS-240A

DENON DCD-1100
PCM53JP-V / PCM54HP – CX23035
KSS-121A / KSS-123A


DENON DCD-1130
2 x PCM61P – SM5840
KSS-150A

DENON DCD-1290
2 x AD1861N-D / PCM61P – SM5840AP
KSS-240A

DENON DCD-1300
PCM54HP-J – SM5806P
KSS-123A

DENON DCD-1400
2 x PCM56P-J
KSS-152A

DENON DCD-1420
2 x PCM54HP – SM5813AP

DENON DCD-1450AR
2 x PCM1702-L – SM5845AF
Sharp H8147AF

DENON DCD-1460
2 x PCM61P – SM5818AP
KSS-150A

DENON DCD-1500
2 x PCM54HP-K – 2 x SM5801P
KSS-121A / KSS-123A

DENON DCD-1500 Mk II
2 x PCM56P-J – SM5807BP
KSS-151A

DENON DCD-1500AE
PCM1791
SACD

DENON DCD-1510
2 x PCM54HP – SM5813AP
KSS-150A

DENON DCD-1515AL
2 x PCM61P – SM5845AF

DENON DCD-1520
2 x PCM64P – SM5813AP
KSS-151A

DENON DCD-1530
2 x PCM61P – SM5818AP
KSS-150A

DENON DCD-1550AR
2 x PCM61P – SM5845AF
Sharp H8147AF

DENON DCD-1560
2 x PCM1701P – SM5813AP
KSS-151A

DENON DCD-1600
2 x PCM56P-J
KSS-151A

DENON DCD-1610
2 x PCM64P – SM5803
KSS-151A

DENON DCD-1630
2 x PCM1701P – SM5813AP
KSS-150A

DENON DCD-1650G
4 x AD1862N-Z - SM5840AP - SM5828P
KSS-150A / KSS-210A

DENON DCD-1650GL
4 x AD1862N-Z - SM5841AP - SM5828BP
KSS-150A / KSS-210A

DENON DCD-1650AR
4 x PCM1702 – SM5845AF
Sharp H8147AF

DENON DCD-1650SR
4 x PCM1704U

DENON DCD-1650AE
PCM1790 – SACD
SACD

DENON DCD-1700
2 x PCM56P-K – SM5804D
KSS-123A

DENON DCD-1800
PCM53
Toshiba 4990076001 / 4998008000

DENON DCD-1800R
PCM53JP-V
Toshiba 4990039006 / 4990074003

DENON DCD-1880AR
2 x PCM61P – SM5845AF
Sharp H8147AF

DENON DCD-2000
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)

DENON DCD-2000AE
PCM1790 – SACD
SACD

DENON DCD-2060
2 x AD1861N-D – SM5840AP
KSS-240A

DENON DCD-2560
4 x AD1862N-D - SM5840AP - SM5828P
KSS-151A

DENON DCD-2560GL
4 x AD1862N-Z - SM5841AP - SM5828BP
KSS-150A / KSS-210A

DENON DCD-2700
4 x PCM1702-J – SM5845AF
KSS-240A

DENON DCD-2800AL
4 x PCM1702 – SM5845AF
Sharp H8147AF

DENON DCD-2880AR
4 x PCM1702 – SM5845AF
Sharp H8147AF

DENON DCD-3000
4 x PCM1702-J – SM5845AF
KSS-240A

DENON DCD-3300
2 x PCM56P-K – SM5804D
KSS-123A

DENON DCD-3500G
2 x PCM64P – SM5803AP
KSS-151A

DENON DCD-3500GL
4 x PCM58P-K – SM5803AP
KSS-151A

DENON DCD-3500RG
4 x PCM58P-K – SM5803AP
KSS-151A

DENON DCD-3520
2 x PCM64P – SM5803AP
KSS-151A

DENON DCD-3560
4 x PCM58P-K – SM5803AP
KSS-151A

DENON DCD-F100
SM5871AN
KSS-213C

DENON DCD-S1
4 x PCM1702-K
KSS-151A

DENON DCD-S10
4 x PCM1702-J – SM5845AF
KSS-240A

DENON DCD-S10 Mk II
4 x PCM1702-J
Sharp H8147AF

DENON DCD-S10 Mk III
4 x PCM1704 + HDCD
Sharp H8147AF

DENON DCD-SA1
2 x PCM1792 – SACD
SACD

DENON DCM-270
PCM1716E
KSS-213C

DENON DCM-280
PCM1748
-

DENON RCD-100
PCM1710
-

DENON UCD-F1
2 x PCM61
KSS-240A

DENON UCD-F10
2 x PCM61
KSS-240A

DIATONE DP-1000H
2 x PCM56P-S
MLP-4

DIORA CD-502
TDA1543
CDM-4

DIORA CD-504
TDA1311
CDM 12.1

DIORA CD-704
TDA1301 – SAA7345
CDM 12.1

DPA BIGGER BIT
TDA1547 (DAC7)
D/A converter

DPA ENLIGHTENMENT DRIVE
Transport
CDM12.1

DPA LITTLE BIT
SAA7350 – YM3414 – YM3623B

DPA PDM 1
SAA7320
D/A converter

DPA PDM 1.2
SAA7322
D/A converter

DPA PDM 1.3
SAA7350
D/A converter

DPA PDM 2
2 x TDA1547 – SAA7350
D/A converter

DPA T1
Transport
CDM-4/19

DUAL CD20
CX20017
KSS-123A

DUAL CD40
TD6705AP – TC9179F
-

DUAL CD41
CX20017
KSS-123A

DUAL CD100
2 x AD1861N / PCM61P – YM3433
KSS-210A

DUAL CD115
MN6471M / MN6474A
KSS-210A

DUAL CD120
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)

DUAL CD130
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)

DUAL CD135
MN6471M / MN6474A
KSS-210A

DUAL CD1016RC
MN6474
Hitachi HOP-M3

DUAL CD1025
CX20017
KSS-123A ?

DUAL CD1045
2 x AD1856N
KSS-150A

DUAL CD1050
2 x AD1856N
KSS-150A

DUAL CD1080
MN6471 / MN6474
KSS-150A / KSS-210A

DUAL CD3600
YM3020
MLP-9

DUAL CD5070
1 x PCM56P-J – CXD1130Q
Sanyo SF-88

DUAL CD5150
TDA1541A – SAA7220P/B
CDM-4/19

DUGOOD BOUNDLESS
4 x PCM1702 – DF1704
VAM 1201

DUGOOD DAC-3
AK4394VF

DUGOOD GLORY YEAR
TDA1541A – SAA7220
VAM 1201

DUGOOD NEW CENTURY
AK4394
Philips

E | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

EAD CD-1000
2 x PCM63P-K – DF1700P
Pioneer Stable Platter PEA1030

EAD CD-1000 SERIES III
2 x PCM63P-K – PMD100
Pioneer Stable Platter PEA1030

EAD DSP-1000 SERIES II
2 x PCM63P-K – DF1700P – CS8412-CP
D/A converter

EAD DSP-1000 SERIES III
2 x PCM63P-K – PMD100
D/A converter

EAD DSP-7000
2 x AD1862N-J – SM5813AP
D/A converter

EAD DSP-7000 SERIES II
2 x PCM63P-K – DF1700P – CS8412-CP
D/A converter

EAD DSP-7000 SERIES III
2 x PCM63P-K – PMD100
D/A converter

EAD DSP-9000 PRO
PCM63P-K
D/A converter

EAD T-1000
Transport
Pioneer Stable Platter PEA1030

EAD T-7000
Transport
Sony KHS-130A

EASTSOUND CD-E3
CS4390
CDM 12

EASTSOUND CD-E5
CS4390-KP
VAM 1202

ELECTROCOMPANIET ECC-1
CS4398
Philips

ELECTROCOMPANIET ECD-1
CS4397 – CS8420
D/A converter

EMT 981 PROFESSIONAL
TDA1541A-S1 (Single Crown)
CDM-1 Mk II

EMT 982 PROFESSIONAL
TDA1547 (DAC7)
CDM-9 Pro

ENSEMBLE DICHRONO DRIVE
Transport
TEAC VRDS CMK-3

ENSEMBLE DICHRONO HI-DAC
CS4397
D/A converter

ENSEMBLE DIRONDO DRIVE
Transport
Philips CD-Pro 2 (VAM 1254)

Entech Number Cruncher 203.2
CS4329-KP – CS8412-CP
D/A converter

Entech Number Cruncher 205.2
CS4329-KP – CS8412-KP
D/A converter

ESTONIA 001
2 x TDA1540P – SAA7030
CDM-2

EXPOSURE CD Player
TDA1545A
CDM 12.4

EXPOSURE CD 2010
PCM1716
KSS-213

EXPOSURE CD 3010
2 x PCM1704
KSS-213

EXPOSURE CD XXII
2 x PCM1704
Sony

EZO FOG STAGE3
AD1853
-

F | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

FISHER AD-800
CX20017 / PCM51JG-V
4 180T00271 (Toshiba OPH-32)

FISHER AD-834
PCM53JG-V – YM201F-K
-

FISHER AD-844
PCM53JP-V
MLP-1C

FISHER AD-850
2 x TDA1540D – SAA7030
Same as Toshiba OPH-32

FISHER AD-935
LC7881
Sanyo SF-P1

FISHER AD-9020
PCM67P – SM5840
KSS-210A

FISHER AD-9030
2 x PCM56P – LC7860J – PD0050
Sanyo SF-88

FISHER AD-9060
PCM67P – SM5840CP
KSS-210A

FISHER AD-M82
LC7880
Sanyo SF-88

FISHER AD-M700
2 x TDA1540D – SAA7030
Same as Toshiba OPH-32

FISHER AD-Z1
2 x PCM58P – YM3434
Sanyo SF-P1

FISHER DAC-205
PCM56P
-

FISHER FCD-2600
PCM54HP
-

FISHER FCD-3500
PCM54HP
-

Forsell Air Reference Air Bearing
Transport
CDM-9 Pro

FUNAI CD 6600
YM3020
-

GG | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

GAMUT CD1
CS4390
-

GAMUT CD3
PCM1792
-

GRUNDIG CD1 FineArts
SAA7341GP
CDM 12.1

GRUNDIG CD3 FineArts
TDA1547 – SAA7350 – SM5840AS
CDM 12.1

GRUNDIG CD 23
TDA1549 – SAA7345GP
CDM 12.1

GRUNDIG CD 30
2 x TDA1540D – M4551 (SAA7030)
CDM-0

GRUNDIG CD 35
2 x TDA1540P – SAA7030
CDM-2

GRUNDIG CD 103
LC7881
Sanyo SF-90

GRUNDIG CD 360
LC78816 M – YM7121C (filter)
Hitachi HOP-M3

GRUNDIG CD 435
LC78816 M – YM7121C (filter)
Hitachi HOP-M3

GRUNDIG CD 660
LC7881
Sanyo SF-90

GRUNDIG CD-903 FineArts
TDA1541A – SAA7220P/B
CDM-2 / CDM-4

GRUNDIG CD-904 FineArts
SAA7350 – YM3433
KSS-210A

GRUNDIG CD-905 FineArts
JVC – JCE4302A
JVC OPTIMA-5S

GRUNDIG CD 1000 FineArts
2 x DAC(TDA1547) – TDA1307

GRUNDIG CD 5200
TDA1543
CDM-4/19

GRUNDIG CD 5500
TDA1543
CDM-4/19

GRUNDIG CD 7500
2 x TDA1540D – SAA7030
CDM-0

GRUNDIG CD 7550
2 x TDA1540P – SAA7030
CDM-1

GRUNDIG CD 8100
TDA1541

GRUNDIG CD 8150
TDA1543
CDM-4/19

GRUNDIG CD 8200
TDA1541
CDM-2/10

GRUNDIG CD 8400
TDA1541 – SAA7220P/A
CDM-2/10

GRUNDIG CD 8400 Mk II
TDA1541A – SAA7220P/B
CDM-2 / CDM-4

GRUNDIG CD 9000 FineArts
TDA1541A
CDM-2/29 / CDM-4/11

GRUNDIG CD 9009 FineArts
2 x TDA1541A-S1 – CXD1244
CDM-1 Mk II

H | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

HARMAN KARDON HD100
YM3020 – M50421P
MLP-7

HARMAN KARDON HD200
YM3020 – M50422P
Hitachi HOP-M14

HARMAN KARDON HD300
1 x PCM56P – YM3815
MLP-3C

HARMAN KARDON HD500
PCM53JP-V – YM2201F-K
KSS-121B / KSS-123A

HARMAN KARDON HD710
MN6474
Samsung SOH-A1

HARMAN KARDON HD720
PCM1710U – LC78621
Sanyo SF-P101

HARMAN KARDON HD730
SAA7350 – YM3433
KSS-240A

HARMAN KARDON HD740
2 x PCM1702U – SM5843AP
Sanyo SF-P101

HARMAN KARDON HD750
PCM1732U
KSS-213C

HARMAN KARDON HD755
PCM1732
-

HD760
4 x PCM1702-K – PMD100
Sanyo

HARMAN KARDON HD800
2 x PCM56P – SM5807EP – M50422P
Hitachi HOP-M14

HARMAN KARDON HD970
AD1955
DVD-ROM DVS DSL-710A

HARMAN KARDON HD7225
MN6474
KSS-150A / KSS-210A

HARMAN KARDON HD7300
1 x PCM61P – M50423FP
KSS-150A

HARMAN KARDON HD7325
MN6474
KSS-150A / KSS-210A

HARMAN KARDON HD7400
1 x PCM61P – M50423FP
KSS-150A

HARMAN KARDON HD7425
2 x PCM61P
KSS-210A

HARMAN KARDON HD7450
MN6471M – M50423FP
KSS-210A

HARMAN KARDON HD7500
MN6471M – M50423FP
KSS-150A

HARMAN KARDON HD7525
4 x PCM61P
KSS-210A

HARMAN KARDON HD7600
MN6471M – M50423FP
KSS-150A

HARMAN KARDON HD7600 Mk II
MN6471M – M50423FP
KSS-210A

HARMAN KARDON HD7625
4 x PCM61P – SM5840
KSS-210A

HARMAN KARDON HD7725
4 x PCM61P-K – SM5840CP
KSS-210A

HARMAN KARDON FL8300
SM5871AS – CXD2507Q
KSS-210A

HARMAN KARDON FL8350
TDA1305
-

HARMAN KARDON FL8370
PCM1732
-

HARMAN KARDON FL8380
PCM1732
-

HARMAN KARDON FL8400
SM5871AN – CXD1167Q
KSS-210A

HARMAN KARDON FL8450
SAA7350GP – YM3433
KSS-210A

HARMAN KARDON FL8550
PCM1702
-

HARMAN KARDON FL8570
PCM61P
-

HCM ROYAL CDR3030
YM3020
-
HELIOS MODEL 1S
CS4328
CDM 12.4 - Pro

HELIOS MODEL 2S
CS4328
CDM 12.4 - Pro

HELIOS MODEL 3S
CS4328
CDM 12.4 - Pro

HELIOS STARGATE
CS4328
CDM 12.4 - Pro

HEYBROOK SIGNATURE
PCM67
-

HI-VI SOUND CD-01
2 x SM5864AP – SM5841CS
CDM 12

High Tech GoldLine CX904
YM3020
-

HITACHI DA-005
1 x PCM54HP-J – 2 x SM5800P
Hitachi HOP-M3TR

HITACHI DA-006
Hitachi HA12096NT
Hitachi HOP-M14

HITACHI DA-007
Hitachi HA12096 – TM6002 (MSM6285)
Hitachi HOP-M14

HITACHI DA-009
Hitachi HA12096NT – MSM6285
Hitachi HOP-M14

HITACHI DA-403
2 x PCM56P-L – CXD1088
Hitachi HOP-M3

HITACHI DA-404D
2 x AD1860N
Hitachi HOP-M3

HITACHI DA-800
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)

HITACHI DA-1000
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)

HITACHI DA-2000
2 x PCM56P – YM3433
KSS-210A

HONOR TCD-1
1 x AD1865N – SM5843AP
KSS-210A

HONOR TCD-2
2 x AD1865N – SM5843AP
KSS-210A

HONOR TCD-50
1 x AD1865N – SM5843AP
KSS-210A

I | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

ICEBERG CDK900PR
LC7881
Samsung SOH-OT4 / KSS-210

INKEL CD-772
AD1852
-

INKEL CD-7080R
2 x PCM1702-K
-

INKEL TEMA CD-1
TDA1547
CDM-9 Pro

ITT HIFI 9015
CX20017 / PCM51JG-V
4 180T00271 (Toshiba OPH-32)

J | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

JADIS JD-1
Transport
CDM-9 Pro

JADIS SYMPHONIA
TDA1545A
Philips VAM 1210

JAS-AUDIO MUSIK 1.2
PCM1732
KSS-213

JAXON ACD-150
LC7880 – CXD1130
KSS-210 / Samsung

JOLIDA JD-100A
PCM1716E
CDM 12.1

JVC XL-E900
PCM56P
OPTIMA-3

JVC XL-V1
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000) / EGH4021251

JVC XL-V3
PCM53JP
-

JVC XL-V22
PCM54
OPTIMA-2

JVC XL-V131
LC7881 – YM7121B (filter)
OPTIMA-5

JVC XL-V151
JVC – JCE4501 – CXD2554P (filter)
OPTIMA-5S

JVC XL-V152
JVC – JCE4501 – CXD2554P (filter)
OPTIMA-5S

JVC XL-V221
LC7881
OPTIMA-5



JVC XL-V242
JVC – JCE4501 – CXD2554P (filter)
OPTIMA-5S

JVC XL-V250
PCM56
OPTIMA-2

JVC XL-V251
JVC – JCE4501 – CXD2554P (filter)
OPTIMA-5S

JVC XL-V252
JVC – JCE4501 – CXD2554P (filter)
OPTIMA-5S

JVC XL-V261
MN35500
OPTIMA-6

JVC XL-V264
MN35500
OPTIMA-6S

JVC XL-V300
PCM53JP
-

JVC XL-V311
MN6471
OPTIMA-4S

JVC XL-V450
PCM56
OPTIMA-2

JVC XL-V464
MN35500
OPTIMA-6S

JVC XL-V550
PCM54HP – SM5806P
OPTIMA-2

JVC XL-V1100
2 x PCM54
OPTIMA-1

JVC XL-Z232
MN35503
OPTIMA-6S

JVC XL-Z555
2 x PCM56P – SM5807EP – YM3613B
OPTIMA-4S

JVC XL-Z1010
2 x PCM56P-J – YM3414 – YM3613B
OPTIMA-4S

JVC XL-Z1011
JVC – JCE4302
OPTIMA-5

JVC XL-Z1050
JVC – JCE4501 – JCE4300 – YM3414
JVC OPTIMA-5S

K | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

KAVENT CD831
PCM1732
Philips VAM 1202

KENWOOD DP-CD1
TD6709N
-

KENWOOD DP-3E
TC9218F
-

KENWOOD DP-3J
TDA1543 – PD0034
KSS-150A

KENWOOD DP-3R
PCM56P
Toshiba TOPH7833

KENWOOD DP-7i
µPD6376CX – PD0060
-

KENWOOD DP-7R
Transport – CXD1125Q
KSS-152A

KENWOOD DP-28
TC9268P – LC78681E
Sharp H8136

KENWOOD DP-47
TD6720N – CXD1135QZ
KSS-152A

KENWOOD DP-87
TD6720N – CXD1135QZ
Toshiba TOPH7833

KENWOOD DP-235
2 x AD1856N / PCM56P – YM7121
Sanyo SF-90

KENWOOD DP-460
TD6709N
-




KENWOOD DP-492
TC9237BN – CXD1167Q
KSS-210A

KENWOOD DP-700
TD6705AP
Toshiba OPH-32

KENWOOD DP-730
2 x PCM56P – PD0050
KSS-210A

KENWOOD DP-770
CX20152 – CX23035

KENWOOD DP-840
TD6705AP
Toshiba TOPH7810

KENWOOD DP-850
CX20152 – CX23035
Toshiba TOPH7810

KENWOOD DP-880SG
2 x PCM56P – CXD1088
Toshiba TOPH7815 / TOPH7833

KENWOOD DP-990D
CX20152 – CX23034
Toshiba TOPH7810

KENWOOD DP-990SG
2 x PCM56P-K – SM5804D
Kenwood J91-0341-05 / TAOHS-

KENWOOD DP-1000
CX20152 – CX23035
MLP-3C

KENWOOD DP-1001
TDA1547 – SAA7350GP – SM5840CP
KSS-240A

KENWOOD DP-1060
TC9268P – LC78681
Sharp H8136A

KENWOOD DP-1080
LC78620E
T25-0051-05

KENWOOD DP-1100
CX20017
Toshiba OPH-32

KENWOOD DP-1100D
CX20152 – SM5802B
Kenwood J91-0315-05

KENWOOD DP-1100SG
2 x PCM56P-K – SM5804D
Kenwood J91-0341-05 / TAOHS-

KENWOOD DP-1510
2 x PCM56P-L – SM5807
KSS-150A / KSS-210A

KENWOOD DP-2000
CX20152 – CX23034
MLP-3C

KENWOOD DP-2010
2 x PCM56P-L
KSS-210A

KENWOOD DP-2030
TC9237N
KSS-210A

KENWOOD DP-2060
TC9268P
Sharp H8136

KENWOOD DP-2080
LC78620E (LC78820)
Sharp H8151AF

KENWOOD DP-3000
PCM56P-K

KENWOOD DP-3010
2 x PCM56P-L – PD0036
KSS-210A

KENWOOD DP-3030
1 x SM5860 – SM5840
KSS-210A

KENWOOD DP-3060
SM5872BS
KSS-240A

KENWOOD DP-3080
SM5864 – SM5841
KSS-240A / T25-0010-05

KENWOOD DP-3080 Mk II
Kenwood KAN-03 – CXD2507AQ
Sharp KCP1H

KENWOOD DP-3090
Kenwood KAN-03 – CXD2507AQ
Sharp KCP1H

KENWOOD DP-3300D
2 x PCM56P-K – SM5804B
Kenwood J91-0315-05

KENWOOD DP-4030
1 x SM5860 – SM5840
KSS-210A

KENWOOD DP-4090
Kenwood KAN-03 – CXD2507AQ
Sharp KCP1H

KENWOOD DP-5010
2 x PCM56P – SM5813AP
KSS-210A

KENWOOD DP-5020
2 x PCM1701P – SM5818AP

KENWOOD DP-5030
CXD2552Q – SM5840CP – SM5827CP
KSS-210A

KENWOOD DP-5040
CXD2552Q
KSS-210A

KENWOOD DP-5050
SAA7350
-

KENWOOD DP-5060
SM5864AP – SM5841AP
KSS-240A

KENWOOD DP-5090
Kenwood KAN-05 – SM5843AS1
Sharp KCP1H

KENWOOD DP-6020
2 x PCM1701P – SM5818AP
KSS-150A

KENWOOD DP-7010
2 x PCM58P – SM5813AP
KSS-150A

KENWOOD DP-7020
2 x PCM1701P – SM5813AP
KSS-150A

KENWOOD DP-7030
CXD2552Q – SM5840CP – SM5827CP
KSS-210A

KENWOOD DP-7040
CXD2552Q – SM5840CP
KSS-210A

KENWOOD DP-7050
TDA1547 (DAC7) – SM5840CP
KSS-210A

KENWOOD DP-7060
TDA1547 (DAC7) – SM5843AP
KSS-240A

KENWOOD DP-7090
8 x PCM1702 – SM5843AS1
KSS-213B

KENWOOD DP-8010
2 x PCM58P – SM5813AP
DLBA2Z002B / J91-0377-05

KENWOOD DP-8020
2 x PCM1701P – SM5813AP
KSS-152 - Magnetic

KENWOOD DP-X9010
Transport – CXD1125Q
DLBA2Z002B / J91-0377-05

KENWOOD DPF-1010
CXD2587Q
KSS-213C

KENWOOD DPF-1030
LC78620E
Sharp HPC1LX

KENWOOD DPF-2010
CXD2587Q
KSS-213C

KENWOOD DPF-2030
LC78620E
Sharp HPC1LX

KENWOOD DPF-3010
Kenwood KAN-03 – CXD2587Q
KSS-213C

KENWOOD DPF-3030
AD1855 – KAN06
KSS-213C

KENWOOD DPF-7002
8 x PCM1702 – SM5843AS1
KSS-213B

KENWOOD L-03DP
CX890
Toshiba OPH-31

KENWOOD L-1000D
2 x CX20152 – CXD1144
KSS-152 - Magnetic

KENWOOD L-D1
TDA1547 (DAC7)
Kenwood CDM-21

KENWOOD LVD-Z1
TDA1547 (DAC7)
-

Kinergetics Research KCD-20
TDA1541A-R1
CDM-2/10 / CDM-4/19

Kinergetics Research KCD-30
TDA1541A
CDM-2/10 / CDM-4

Kinergetics Research KCD-40
4 x AD1860N-K – CXD1144
CDM-2/10 / CDM-4/19

Kinergetics Research KCD-55 Ultra
2 x UltraAnalog D20400A
D/A converter

KODAK PCD-5855
SAA7321
CDM-9

KOREA CHINA CD 022
KDA0316LN (Samsung)
-

KOREA HCD 630
Y3015

KRELL CD-1
CS4328-KP
CDM-1 Mk II

KRELL CD-DSP
2 x PCM61P-J + Motorola DSP
CDM-1 Mk II

KRELL CD-DSP Mk2
2 x PCM61P-K + Motorola DSP
CDM-1 Mk II

KRELL DT-10
Transport
CDM-4/36 Pro Metallic

KRELL KAV-250cd
2 x PCM1702 – PMD100
C.E.C. – Sanyo

KRELL KAV-280cd
4 x PCM1704 – DF1704
CDM 12 Pro / VAM 1201

KRELL KAV-300cd
2 x PCM1702-K – PMD100
VRDS CMK-4 – KSS-240A

KRELL KPS 20i
4 x PCM63P-K – Motorola XC56002F
CDM-9 Pro ( CDM-9/60 )

KRELL KPS 25s
2 x UltraAnalog D20400A - XC56009F
JVC EXU-901A

KRELL KPS 25sc
4 x PCM1704 – XC56009F – PMD100
JVC Pro

KRELL KPS 28c
4 x PCM1704K – PMD100
TEAC VRDS

KRELL KPS 30i
4 x PCM63P-K – PMD100
CDM 12 Pro / CDM 12.4

KRELL MD-1
Transport – SAA7210P
CDM-3

KRELL MD-2
Transport – SAA7210P
CDM-1 Mk II

KRELL MD-10
Transport – SAA7210P
CDM-3

KRELL MD-20
Transport – SAA7210P
CDM-1 Mk II

KRELL SACD STANDARD
3 x PCM1738
Philips 5.2 SACD

KRELL SBP-16X
2 x PCM58P-K + Motorola DSP-56001
D/A converter

KRELL SBP-32X
2 x PCM58P-K + 2 x Motorola XSP56001
D/A converter

KRELL SBP-64X
2 x PCM64P + 4 x Motorola DSP56001
D/A converter

KRELL STUDIO
2 x PCM63P-K + 2 x Motorola DSP56000
D/A converter

KYOCERA DA-01
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)

KYOCERA DA-9cx
2 x PCM56P-S – SM5804B

KYOCERA DA-310cx
PCM54HP
KSS-152A

KYOCERA DA-410cx
CX20152
-

KYOCERA DA-710cx
2 x PCM56P-S – SM5804B
KSS-152A

KYOCERA DA-910
2 x TDA1540D – SAA7030
HLPL 030020

L | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL

LAVRY DA10
AD1955 – AD1896
D/A converter

LECTOR CDP 3T
TDA1541A-S1 (Single Crown)
Philips CDM 12

LECTOR CDP 7T
2 x PCM63P
Philips CDM 12

LECTOR CDP 7TL
2 x PCM1704
Philips CDM 12

LECTOR DIGICODE
TDA1541A-S1 (Single Crown)
D/A converter

LECTOR DIGIDRIVE
Transport
CDM-4/19

LINDEMANN 820
PCM1792
SACD Sony KHM-230AAA

LINDEMANN 822
PCM1792
SACD Sony KHM-230AAA

LINN CD12 SONDEK
4 x PCM1702-K – PMD100
Philips

LINN GENKI
PCM1732U
Sanyo SF-91 / SF-P101N

LINN IKEMI
PCM1732U
Sanyo SF-91

LINN MIMIK
CS4328
Hitachi HOP-M3 / Sanyo SF-91

LINN NUMERIK
2 x PCM63P-K – DF1700
D/A converter

LINN NUMERIK Mk 3
2 X PCM1702-K
D/A converter

LO–D DA-403D
2 x PCM56P – CXD1088
Hitachi HOP-M3

LO–D DA-404D
2 x AD1860N
Hitachi HOP-M3

LO–D DA-505D
2 x PCM61P
KSS-150A

LO–D DA-703D
2 x PCM56P-J + 2 x PCM56P
Hitachi HOP-M14

LO–D DAD-003
1 x PCM54HP-J – 2 x SM5800P
D/A converter

LO–D DAP-003
Transport
Hitachi HOP-M14

LO–D DAD-800
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)

LO–D DAD-1000
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)

LO–D DAD-3000
PCM53JP-V – TM5001 (HD61902H)
Hitachi (DA-1000)

LO–D DAD-5500
PCM54HP
Hitachi HOP-M14

LOEWE CD9000
2 x TDA1540D – SAA7030
CDM-0

LUXMAN D-01
1 x PCM56P-J – CXD1135QZ
KSS-152A / DLBA2Z

LUXMAN D-007
Transport – CXD1135QZ
KSS-152A / DLBA2Z

LUXMAN D-90
TD6720N
Toshiba TOPH7833

LUXMAN D-102
TD6709N
Toshiba OPH-32

LUXMAN D-103
TD6705AP
Toshiba TOPH7810

LUXMAN D-103U
2 x PCM1701P
KSS-152A

LUXMAN D-105
TD6705AP
Toshiba OPH-32

LUXMAN D-105U
2 x PCM1701P – SM5813AP
KSS-152A

LUXMAN D-107U
2 x AD1860 – SM5813AP
KSS-152A

LUXMAN D-109
1 x PCM56P-J
Sony BU-1C

LUXMAN D-111
LC7880 – CXD1135QZ
KSS-152A / DLBA2Z

LUXMAN D-112
1 x PCM56
-

LUXMAN D-113
1 x PCM56P – CXD1135QZ
KSS-152A / DLBA2Z

LUXMAN D-113D
Transport – CXD1125QZ
KSS-152A / DLBA2Z

LUXMAN D-115
1 x PCM56P-J – CXD1135QZ
KSS-152A / DLBA2Z

LUXMAN D-322
2 x PCM61P – SM5841BP
KSS-240A

LUXMAN D-351
AD1864N
KSS-150A

LUXMAN D-373
AD1864N-J
-

LUXMAN D-404
TD6705AP
Toshiba TOPH7810

LUXMAN D-405
TD6705AP
Toshiba OPH-32

LUXMAN D-500
2 x PCM1701P – SM5813AP
CDM-3

LUXMAN D-500X’s II
TDA1541A-S1 (Single Crown)
CDM-3

LUXMAN DU-7
CS4392 + NSdap FN1242A
-

LUXMAN DX-104
CX890
Toshiba OPH-31

LUXMAN DZ-03
2 x PCM1701P
KSS-152A

LUXMAN DZ-92
LC7881
-

LUXMAN DZ-111
LC7881C – SM5807EP
KSS-152A / DLBA2Z

LUXMAN DZ-112
2 x PCM1701P – SM5813AP
KSS-152A

M | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
MAGNAVOX CDB262
TDA1543A
CDM-4/19
PDF
MAGNAVOX CDB460
TDA1541 – SAA7220P/A
CDM-2/10
PDF
MAGNAVOX CDB465
TDA1541
CDM-2
PDF
MAGNAVOX CDB470
TDA1541 – SAA7220P/A
CDM-2
PDF
MAGNAVOX CDB471
TDA1541 – SAA7220P/A
CDM-2
PDF
MAGNAVOX CDB472
TDA1541 – SAA7220P/A
CDM-2
PDF
MAGNAVOX CDB480
TDA1543
CDM-4/19
PDF
MAGNAVOX CDB500
TDA1543
CDM-4/19
PDF
MAGNAVOX CDB560
TDA1541 – SAA7220P/A
CDM-2
PDF
MAGNAVOX CDB600
TDA1543 – SAA7220
CDM-4/19
PDF
MAGNAVOX CDB650
TDA1541 – SAA7220P/A
CDM-2
PDF
MAGNAVOX FD1000
2 x TDA1540D – M4551 (SAA7030)
CDM-0
PDF
MAGNAVOX FD1010
2 x TDA1540D – SAA7030
CDM-0
PDF
MAGNAVOX FD1040
2 x TDA1540P – SAA7030
CDM-1
PDF
MAGNAVOX FD1041
2 x TDA1540P – SAA7030
CDM-2/10
PDF
MAGNAVOX FD1051
2 x TDA1540P – SAA7030
CDM-2/10
PDF
MAGNAVOX FD2000
2 x TDA1540D – SAA7030
CDM-0
PDF
MAGNAVOX FD2020
2 x TDA1540D – SAA7030
CDM-0
PDF
MAGNAVOX FD2040
2 x TDA1540P – SAA7030
CDM-1
PDF
MAGNAVOX FD2041
2 x TDA1540P – SAA7030
CDM-2
PDF
MAGNAVOX FD3000
2 x TDA1540D – SAA7030
CDM-0
PDF
MAGNAVOX FD3030
2 x TDA1540D – SAA7030
CDM-0
PDF
MAGNAVOX FD3040
2 x TDA1540P – SAA7030
CDM-1
PDF
MANLEY A TO D CONVERTER
2 x UltraAnalog D20400A
D/A converter
PDF
MANLEY DELTA SIGMA DAC
CS4328-KP – CS8412
D/A converter
PDF
MANLEY JUNIOR 20 Bit DAC
1 x UltraAnalog D20400A
D/A converter
PDF
MANLEY Reference 20 Bit DAC
2 x UltraAnalog D20400A – SM5803AP
D/A converter
PDF
MANLEY WAVE
2 x UltraAnalog D20400A
D/A converter
PDF
MANLEY WAVE 24 Bit
2 x PCM1704
D/A converter
PDF
MARANTZ CD-5L
1 x TDA1541 – SAA7220P/A
CDM-2/10
PDF
MARANTZ CD-7
2 x TDA1541A-S2 (Double Crown) + DSP
Philips CD-Pro (VAM 1252)
PDF
MARANTZ CD-10
2 x TDA1547 - SAA7350GP - SM5803APT
CDM-4/36 Metallic
PDF
MARANTZ CD-11LE
2 x TDA1547 - SAA7350GP - SM5803APT
CDM-4/36 Metallic
PDF
MARANTZ CD-11 Mk II
2 x TDA1547
CDM-4/36 Metallic
PDF
MARANTZ CD-12
Transport
CDM-1
PDF
MARANTZ DA-12
TDA1541A-S1 (Double Crown)
D/A converter
PDF
MARANTZ CD-14
2 x TDA1547 – TDA1307
CDM 12.3
PDF
MARANTZ CD-15
2 x TDA1547 – SM5803APT – SAA7350
CDM-4/36 Metallic
PDF
MARANTZ CD-16 / CD-16SE
2 x TDA1547 – SM5803APT – SAA7350
CDM-4/36 Metallic
PDF
MARANTZ CD-16D
2 x TDA1547 – TDA1307
VAM 1201
PDF
MARANTZ CD-17
1 x TDA1547 – SM5841 – SAA7350
CDM 12.1
PDF
MARANTZ CD-17 Mk II
TDA1547 – SM5841 – SAA7350
CDM 12.1
PDF
MARANTZ CD-17 Mk III
2 x PCM1716E
VAM 1201
PDF
MARANTZ CD-19
2 x SM5872BS
CDM 12
PDF
MARANTZ CD-23
2 x TDA1547 (DAC7)
CDM-9 Pro
PDF
MARANTZ CD-25
2 x TDA1540P – SAA7030
CDM-2/10 / CDM-2/29
PDF
MARANTZ CD-32
SAA7350 – SM5840FP
CDM-4/19
PDF
MARANTZ CD-34
2 x TDA1540P – SAA7030
CDM-1
PDF
MARANTZ CD-36
TDA1545 smd
CDM 12.1
PDF
MARANTZ CD-38
TDA1545
CDM 12.1
PDF
MARANTZ CD-40
TDA1541A-R1
CDM-4/19
PDF
MARANTZ CD-41
2 x SAA7321GP
CDM-4/19
PDF
MARANTZ CD-42
SAA7350 – SM5840FP
CDM-4/19
PDF
MARANTZ CD-42 Mk II
SAA7350 – SM5840FP
CDM-4/19
PDF
MARANTZ CD-43
1 x SM5872BS
CDM 12.1/05
PDF
MARANTZ CD-44
2 x TDA1540
CDM-1
PDF
MARANTZ CD-45
2 x TDA1540P – SAA7030
CDM-2/29
PDF
MARANTZ CD-46
TDA1545A – SAA7345GP
CDM 12.1
PDF
MARANTZ CD-48
TDA1549
CDM 12.1
PDF
MARANTZ CD-50
TDA1541A – SAA7220P/B
CDM-4/19 Composite
PDF
MARANTZ CD-52
SAA7350GP – SM5840FP
CDM-4/19
PDF
MARANTZ CD-52 Mk II
SAA7350GP – SM5840FP
CDM-4/19
PDF
MARANTZ CD-52SE
SAA7350GP
CDM-4/19
PDF
MARANTZ CD-53
1 x SM5872BS
CDM 12.1
PDF
MARANTZ CD-54
2 x TDA1540D – SAA7030
CDM-1
PDF
MARANTZ CD-56
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-4/25
PDF
MARANTZ CD-57
SM5872
CDM 12.1
PDF
MARANTZ CD-60
TDA1541A – SAA7220P/B
CDM-4/19 Composite
PDF
MARANTZ CD-62
SAA7350GP – SAA7322
CDM-4/19
PDF
MARANTZ CD-63 (Holland Old)
2 x TDA1540D – M4551 (SAA7030)
CDM-0
PDF
MARANTZ CD-63
1 x SM5872BS
CDM 12.1
PDF
MARANTZ CD-63 II
SM5872BS
CDM 12.1
PDF
MARANTZ CD-63 Mk II KI
SM5872BS
CDM 12.1
PDF
MARANTZ CD-63SE
SM5872BS
CDM 12.1
PDF
MARANTZ CD-65
TDA1541 – SAA7220P/A
CDM-2
PDF
MARANTZ CD-65DX
TDA1541A – SAA7220P/B – SAA7210P
CDM-2/10 / CDM-4/11
PDF
MARANTZ CD-65 Gold
TDA1541-S1 – SAA7220P/A
CDM-2
PDF
MARANTZ CD65 Mk II
TDA1541A – SAA7220P/B
CDM-4/11
PDF
MARANTZ CD-67
SM5872
CDM 12.1
PDF
MARANTZ CD-67SE
SM5872
CDM 12.1
PDF
MARANTZ CD-67 II OSE
SM5872
CDM 12.1
PDF
MARANTZ CD-72
SAA7350GP
CDM-4/19
PDF
MARANTZ CD-72a
TDA1547
CDM-4
PDF
MARANTZ CD-72SE
SAA7350
CDM-4
PDF
MARANTZ CD-72 Mk II SE
TDA1547
CDM-4/28
PDF
MARANTZ CD-73
2 x TDA1540D – SAA7030 (M4551)
CDM-0
PDF
MARANTZ CD-74
2 x TDA1540P – SAA7030
CDM-1
PDF
MARANTZ CD-75
TDA1541 – SAA7220
CDM-2/10 / CDM-4/25
PDF
MARANTZ CD75 Mk II
TDA1541A – SAA7220P/B
CDM-1 Mk II
PDF
MARANTZ CD-80
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
MARANTZ CD-84
2 x TDA1540P – SAA7030
CDM-1
PDF
MARANTZ CD-85
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
MARANTZ CD-94
TDA1541A
CDM-1
PDF
MARANTZ CD94 Mk II
2 x TDA1541A-S1 (Single Crown)
CDM-1
PDF
MARANTZ CD-95
2 x TDA1541A-S1 + 2 x SAA7220P/B
CDM-1
PDF
MARANTZ CD-99SE
2 x TDA1541A-S1 (Single Crown)
CDM-1
PDF
MARANTZ CD273
TDA1541
CDM-2
PDF
MARANTZ CD583
TDA1541A
CDM-2 / CDM-4
PDF
MARANTZ CD650
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-4/25
PDF
MARANTZ CD873
TDA1541
CDM-2 / CDM-4/11
PDF
MARANTZ CD880J
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
MARANTZ CC3000
TDA1545
-
PDF
MARANTZ CD1010
SM5872BS
CDM 12.1 (VAM 1201)
PDF
MARANTZ CD1020
SM5872BS
CDM 12.1 (VAM 1201)
PDF
MARANTZ CD4000
TDA1545 - SAA7378
CDM 12.1 (VAM 1201)
PDF
MARANTZ CD5000
TDA1549 - SAA7378
CDM 12.1 (VAM 1201)
PDF
MARANTZ CD5001
CS4392
KSS-213C
PDF
MARANTZ CD5001-OSE
CS4392
KSS-213C
PDF
MARANTZ CD5400
CS4392
KSS-213C
PDF
MARANTZ CD5400-OSE
CS4392
KSS-213C
PDF
MARANTZ CD6000
2 x SM5872 - SAA7378
CDM 12.1 (VAM 1201)
PDF
MARANTZ CD6000KI
2 x SM5872BS – SAA7372
CDM 12.1 (VAM 1201)
PDF
MARANTZ CD6000-OSE
2 x SM5872BS – SAA7372
VAM 1201
PDF
MARANTZ CD6002
CS4398
-
PDF
MARANTZ CD7300
CS4396
VAM 1202
PDF
MARANTZ CDA-94
TDA1541A-S1 (Single Crown)
D/A converter
PDF
MARANTZ CDV780
TDA1541A
-
PDF
MARANTZ PROJECT D-1
2 x TDA1541A-S2 (Double Crown)
D/A converter
PDF
MARANTZ SA-1
4 x DAC7 (TDA1547) – TDA1307
CDM-10
PDF
MARANTZ SA-7S1
2 x SM5866AS
SACDM-1
PDF
MARANTZ SA-11S1 / S2
SM5866AS
SACDM-1
PDF
MARANTZ SA-12S1
2 x CS4397
SACD
PDF
MARANTZ SA-13S1
CS4397-KS
SACD
PDF
MARANTZ SA-14
CS4397
SACD
PDF
MARANTZ SA-15S1
CS4397
SACD
PDF
MARANTZ SA-17S1
3 x CS4397
SACD
PDF
MARANTZ SA7001
CS4397
SACD
PDF
MARANTZ SA8001
CS4397
SACD
PDF
MARANTZ SA8260
3 x CS4397
SACD Sony KHM-230AAA
PDF
MARANTZ SA8400
CS4397
SACD HOP-1200R
PDF
MARK LEVINSON No 30
2 x UltraAnalog D20400 – SM5803AP
D/A converter
PDF
MARK LEVINSON No 30.5
2 x UltraAnalog D20400A – PMD100
D/A converter
PDF
MARK LEVINSON No 30.6
4 x PCM1704
D/A converter
PDF
MARK LEVINSON No 31.5
Transport
CDM 12 Ind
PDF
MARK LEVINSON No 36
4 x PCM1702-K – PMD100 - CS8412-CP
D/A converter
PDF
MARK LEVINSON No 37
Transport
CDM 12 Ind
PDF
MARK LEVINSON No 39
PCM1702 (PCM1704)
CDM 12 Ind
PDF
MARK LEVINSON No 360S
4 x PCM1704
D/A converter
PDF
MARK LEVINSON No 390S
2 x AD1853
Philips CD-Pro (VAM 1252)
PDF
MBL 1521
Transport
CDM 12 Ind
PDF
MBL 1621
Transport
CDM 12 Pro
PDF
McCORMACK CD DRIVE
Transport
CDM-4/19
PDF
McCORMACK DAC-1
CS4328-KP – CS8412-CP
D/A converter
PDF
McCORMACK PRISM II
TDA1541A-R1 – SAA7220P/B
CDM-4/19
PDF
McCORMACK SST-1
Transport
CDM 12
PDF
MCINTOSH MCD201
CS4398
RAYMEDIA RMC RL-S880
PDF
MCINTOSH MCD751
Transport
VRDS CMK-3 – KSS-151A
PDF
MCINTOSH MCD7000
2 x TDA1540 – SAA7030
CDM-1
PDF
MCINTOSH MCD7005
TDA1541A
CDM-2/10
PDF
MCINTOSH MCD7007
TDA1541A-S1 (Single Crown)
CDM-1
PDF
MCINTOSH MCD7008
2 x PCM1700P
-
PDF
MCINTOSH MCD7009
2 x TDA1547 – SAA7350 – SM5840AP
VRDS CMK-3.2 – KSS-151A
PDF
MCINTOSH MDA4000
2 x PCM1702 – SM5845AF
D/A converter
PDF
MERACUS TANTO
CS4327KS
-
PDF
MERIDIAN MCD
2 x TDA1540D – SAA7030
CDM-1
PDF
MERIDIAN MCD-Pro
2 x TDA1540D – SAA7030
CDM-1
PDF
MERIDIAN 203
2 x SAA7321
-
PDF
MERIDIAN 203 Mk II
TDA1547 (DAC7)
-
PDF
MERIDIAN 206
TDA1541A-S1 (Single Crown)
CDM-4/21
PDF
MERIDIAN 206B
TDA1547 (DAC7)
CDM-4/19
PDF
MERIDIAN 206 BS
2 x SAA7321 – SAA7350
CDM-4/19
PDF
MERIDIAN 206 DS
CS4328
CDM-4/19
PDF
MERIDIAN 207
TDA1541A-S2 (Double Crown)
CDM-1 / CDM-4
PDF
MERIDIAN 208
2 x SAA7321
-
PDF
MERIDIAN 500
Transport
CDM 12
PDF
MERIDIAN 506
CS4328 - SAA7310
CDM 12.4
PDF
MERIDIAN 506.24
CS4390
CDM 12
PDF
MERIDIAN 507
CS4390
-
PDF
MERIDIAN 507.24
AD1852JRC
Philips VAL 1250
PDF
MERIDIAN 508
CS4329 - SAA7310
CDM 12.3
PDF
MERIDIAN 508.24
CS4390
CDM 12.5
PDF
MERIDIAN 588
CS4391
VAE 1250 / DSL-710A
PDF
MERIDIAN G06
AD1852
DVD-ROM DVS DSL-710A
PDF
MERIDIAN G07
AD1852
DVD-ROM DVS DSL-710A
PDF
MERIDIAN G08
AD1852
DVD-ROM DVS DSL-710A
PDF
METAXAS MASDAC
UltraAnalog D20400
D/A converter
PDF
METAXAS MAS PHOS
Transport
CDM-9
PDF
MHZS CD66
PCM1742
KSS-213Q
PDF
MICRO CD-M1
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)
PDF
MICRO CD-M2
TDA1541
CDM-1
PDF
MICRO CD-M100
TDA1541A
CDM-1
PDF
MICROMEGA ARIA
AD1853
VAM 1202
PDF
MICROMEGA CD
AD1852
VAM 1202
PDF
MICROMEGA CD (2006)
AD1853
KSS-213Q
PDF
MICROMEGA CD-SE
AD1853
KSS-213Q
PDF
MICROMEGA CD132
AD1853
VAM 1202
PDF
MICROMEGA CD132-SE
AD1853
KSS-213Q
PDF
MICROMEGA CD F1
Transport
CDM-1 Mk II
PDF
MICROMEGA DATA
Transport
CDM 12
PDF
MICROMEGA DIALOG
TDA1547
D/A converter
PDF
MICROMEGA DRIVE 1
Transport
CDM 12.4
PDF
MICROMEGA DRIVE 2
Transport
CDM 12.10
PDF
MICROMEGA DUO.CD.
Transport
CDM-9 Pro
PDF
MICROMEGA LEADER
SAA7321GP
CDM-4/19
PDF
MICROMEGA LOGIC
SAA7321
CDM
PDF
MICROMEGA MICRODAC
SAA7321GP – YM3623B
D/A converter
PDF
MICROMEGA MICRODRIVE
Transport
CDM-9
PDF
MICROMEGA MINIUM
TDA1549
CDM 12.2
PDF
MICROMEGA PREMIUM18
CS4327
KSS-213C
PDF
MICROMEGA SOLO
TDA1547
CDM 12
PDF
MICROMEGA STAGE2
SAA7321GP
CDM 12.4
PDF
MICROMEGA STAGE4
TDA1305
CDM 12.3
PDF
MICROMEGA STAGE5
2 x TDA1305
CDM 12.1
PDF
MICROMEGA STAGE6
2 x TDA1305
CDM 12.3
PDF
MISSION-Cyrus CD 6S
PCM1738
CDM 12
PDF
MISSION-Cyrus CD 7
PCM1716
CDM 12.1
PDF
MISSION-Cyrus CD 8x
2 x PCM1738
Philips
PDF
MISSION-Cyrus DAC5
TDA1547
D/A converter
PDF
MISSION-Cyrus Dacmaster
2 x AD1862N - SM5813APT - CS8412-CP
D/A converter
PDF
MISSION-Cyrus dAD1
TDA1311
CDM 12.4
PDF
MISSION-Cyrus dAD1.5
TDA1311
CDM 12.1
PDF
MISSION-Cyrus dAD3
TDA1305
CDM 12.4
PDF
MISSION-Cyrus dAD3Q
AD1861
CDM 12.4
PDF
MISSION-Cyrus dAD7
AD1861
CDM-9
PDF
MISSION DAD7000
2 x TDA1540
CDM-1
PDF
MISSION PCM II
TDA1541A
CDM-4/11
PDF
MISSION PCM4000
TDA1541
-
PDF
MISSION PCM7000
TDA1541
CDM-2/10
PDF
MITSUBISHI DP-109
PCM56P
-
PDF
MITSUBISHI M-C5100
2 x PCM56P – YM3414
Sankyo SPM1001 – MLP-10-E2
PDF
MONARCHY AUDIO MODEL 18B
2 x AD1860N – YM3434
D/A converter
PDF
MONARCHY AUDIO MODEL 22B
2 x PCM63P-K – SM5813APT
D/A converter
PDF
MONARCHY AUDIO MODEL 22C
4 x PCM63P-K – DF1704
D/A converter
PDF
MONARCHY AUDIO MODEL 24
2 x PCM63P-K – DF1704
D/A converter
PDF
MONARCHY AUDIO MODEL 33
2 x PCM63P-K – SM5813APT
D/A converter
PDF
MONRIO MJ PLAYER
CS4397
CD-ROM
PDF
MONRIO NAS-DAC
CS4397
VAM 1210
PDF
MONRIO TOP-LOADER
CS4390-KP
Philips CD-Pro (VAM 1252)
PDF
MONRIO TOP-LOADER 2
CS4390-KP
Philips CD-Pro 2M (VAM 1254)
PDF
MUSEATEX BIDAT
TDA1547 – SAA7350GP
D/A converter
PDF
MUSEATEX MELIOR BITSTREAM
SAA7350GP – YM3434 – YM3623B
D/A converter
PDF
MUSEATEX MELIOR CD-D
CDM-1 Mk II
Transport
PDF
MUSIC HALL CD-25
PCM1732
CDM 12.10
PDF
MUSIC HALL CD25.2
PCM1738
VAM 1202
PDF
MUSICAL FIDELITY A2
YDC103
-
PDF
MUSICAL FIDELITY A3 DAC
PCM1738E – CS8420
D/A converter
PDF
MUSICAL FIDELITY A3.2
PCM1738E
KSS-240A
PDF
MUSICAL FIDELITY A3.5
PCM1738
Philips CDM 12
PDF
MUSICAL FIDELITY C2
YDC103
-
PDF
MUSICAL FIDELITY CD1
SAA7323GP – SAA7220P/B
CDM-4/19
PDF
MUSICAL FIDELITY DIGILOG
TDA1541A
D/A converter
PDF
MUSICAL FIDELITY E60
YDC103
Sanyo SF-91
PDF
MUSICAL FIDELITY E624
PCM1716
-
PDF
MUSICAL FIDELITY FCD
SAA7350
KSS-210A
PDF
MUSICAL FIDELITY Nu-Vista 3D
PCM1738
Sony
PDF
MUSICAL FIDELITY Tri-Vista
PCM1738
-
PDF
MUSICAL FIDELITY Tri-Vista 21
PCM1792
D/A converter
PDF
MUSICAL FIDELITY X-24K
PCM1716
D/A converter
PDF
MUSICAL FIDELITY X-RAY
PCM1716
KSS-240A
PDF
MUSICAL FIDELITY X-RAY V3
PCM1732
Philips
PDF
MYRYAD T-10
CS4327
Sony
PDF
MYRYAD T-20
CS4327
Sony
PDF
MYRYAD MC100
CXD2565
CDM 14 - Sony
PDF
MYRYAD MCD600
CS4396
-
PDF
MYRYAD MXC6000
2 x CS4396
Sony
PDF
MYRYAD Z110
CS4391
KSS-213B

N | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
NAD 501
SAA7323GP
CDM-4/19
PDF
NAD 502
MN6474AM – CXD1167Q
KSS-210A
PDF
NAD 510
SAA7350
CDM 12.1 / KSS-210A
PDF
NAD 512
MN6474 – CXD1167Q
KSS-150A / KSS-210A
PDF
NAD 514
MN6474 – CXD1167Q
KSS-210A / KSS-212A
PDF
NAD 520
PCM1710U
Sanyo
PDF
NAD 522
PCM1710U
Sanyo SF-P101
PDF
NAD 523
SM5874
KSS-210
PDF
NAD 524
PCM1716E
Sanyo SF-P
PDF
NAD 5000
MN6471M – YM3412B – CXD1167Q
KSS-210A
PDF
NAD 5100
PCM56
MLP-10
PDF
NAD 5255
TD6705AP
Toshiba OPH-32
PDF
NAD 5325
LC7881
-
PDF
NAD 5420
MN6471M
KSS-210A
PDF
NAD 5425
MN6471M
KSS-210A
PDF
NAD C520
PCM1710U
Sanyo SF-P101
PDF
NAD C521
PCM1710U
Sanyo SF-P101
PDF
NAD C521BEE
PCM1716
KSS-213
PDF
NAD C525BEE
PCM1710U
KSS-213
PDF
NAD C541
PCM1710U
Sanyo SF-P101N
PDF
NAD C542
PCM1732U
KSS-213C
PDF
NAD S500
CS4390
CDM 12.4
PDF
NAGRA DAC
AD1853
D/A converter
PDF
NAIM AUDIO CD1
TDA1541
CDM-2
PDF
NAIM AUDIO CD2
TDA1541A
CDM-9
PDF
NAIM AUDIO CD3
TDA1541A-S1 (Single / Double Crown)
CDM-9
PDF
NAIM AUDIO CD3.5
TDA1305
VAM 1205
PDF
NAIM AUDIO CD5
TDA1305
CDM 12 / VAM 1205
PDF
NAIM AUDIO CD5i
Philips UDA1330ATS
VAM 1202/12
PDF
NAIM AUDIO CD5X
PCM1704
VAM 1201
PDF
NAIM AUDIO CD555
PCM1704 – PMD200
CDM 12 Pro
PDF
NAIM AUDIO CDI
TDA1541A-S1 (Single / Double Crown)
CDM-4/27 / CDM-9 Pro
PDF
NAIM AUDIO CDS 1
TDA1541A-S1 (Single Crown)
CDM-4/25
PDF
NAIM AUDIO CDS II
2 x PCM1702-K
VAM 1205
PDF
NAIM AUDIO CDS 3
2 x PCM1704-K
VAM 1250
PDF
NAIM AUDIO CDX
2 x PCM1702-K + PMD100
CDM 12 / VAM 1205
PDF
NAIM AUDIO CDX2
PCM1704
-
PDF
NAKAMICHI 1000mb/i
2 x PCM1700P-N – SM5813APT
-
PDF
NAKAMICHI CD PLAYER 1
2 x PCM1700P-J
KSS-150A
PDF
NAKAMICHI CD PLAYER 2
2 x PCM1700P – SM5840CP
KSS-210A
PDF
NAKAMICHI CD PLAYER 3
1 x PCM1700P – SM5840CP
KSS-210A
PDF
NAKAMICHI CD PLAYER 4
AD1864N – SM5840BP
KSS-150A / KSS-210A
PDF
NAKAMICHI CDC-3A
TDA1541A – CXD1088
Pioneer PWY1009 / PWY1010
PDF
NAKAMICHI CDP-2 A/E
TDA1541A – CXD1088
KSS-152A
PDF
NAKAMICHI DAC-41
2 x PCM1702 – SM5841CP – YM3623B
D/A converter
PDF
NAKAMICHI DAC-100
4 x PCM1700P-K
D/A converter
PDF
NAKAMICHI DAC-101
2 x TDA1541A-S1 (Single Crown)
D/A converter
PDF
NAKAMICHI DRAGON CD/DAC
4 x PCM1704U-J – DF1704E
Sanyo SF-91
PDF
NAKAMICHI MB-1
2 x PCM1700P-N – SM5813APT
-
PDF
NAKAMICHI MB-1S
2 x PCM1700P – SM5841CP
Sanyo SF-91
PDF
NAKAMICHI MB-2
2 x PCM1700P – SM5840AP
-
PDF
NAKAMICHI MB-2S
AD1868 – SM5841CP
Sanyo SF-91
PDF
NAKAMICHI MB-3S
AD1868 – SM5841CP
Sanyo SF-91
PDF
NAKAMICHI MB-4
LC78840
-
PDF
NAKAMICHI MB-4S
TDA1311A – LC78840M
Sanyo SF-91
PDF
NAKAMICHI MB-5
LC78840
-
PDF
NAKAMICHI OMS-1
PCM56
KSS-150A
PDF
NAKAMICHI OMS-2
1 x PCM54HP
-
PDF
NAKAMICHI OMS-3
1 x PCM54HP-J – YM2601F-K
KSS-121A / KSS-123A
PDF
NAKAMICHI OMS-4
2 x PCM54HP-J
KSS-123A
PDF
NAKAMICHI OMS-5
2 x TDA1540D – SAA7030
HLPL 030020 / CA80255A
PDF
NAKAMICHI OMS-5 II
PCM54HP – SM5804B
KSS-123A
PDF
NAKAMICHI OMS-7
2 x TDA1540D – SAA7030
HLPL 030020 / CA80255A
PDF
NAKAMICHI OMS-7 II
2 x PCM54HP-K – SM5804B
KSS-123A
PDF
NAKAMICHI OMS-20
TDA1541A – CXD1088
KSS-152A
PDF
NAKAMICHI OMS-30
1 x PCM54HP-J – YM2601F-K
KSS-121A / KSS-123A
PDF
NAKAMICHI OMS-50
2 x TDA1540D – SAA7030
HLPL 030020 / CA80255A
PDF
NAKAMICHI OMS-50 II
PCM54HP – SM5804B
KSS-123A
PDF
NAKAMICHI OMS-70
2 x TDA1540D – SAA7030
HLPL 030020 / CA80255A
PDF
NAKAMICHI OMS-70 II
2 x PCM54HP-K – SM5804B
KSS-123A
PDF
NEC CD-10
2 x TDA1541A-S1 (Single Crown)
KSS-150A
PDF
NEC CD-410
PCM54HP
KSS-152A
PDF
NEC CD-430
PCM54HP
KSS-150A
PDF
NEC CD-509
PCM53JP-V
KSS-121 / KSS-123
PDF
NEC CD-600
NEC µPC655CA + NEC µPD6352CA
KSS-123A
PDF
NEC CD-607E
PCM53JP-V – YM2201F
KSS-121 / KSS-123
PDF
NEC CD-609
PCM53JP-V
KSS-121 / KSS-123
PDF
NEC CD-610
PCM54HP – µPD6350
KSS-123A
PDF
NEC CD-620
TDA1541
KSS-150A
PDF
NEC CD-720
TDA1541
KSS-150A
PDF
NEC CD-730
2 x TDA1541A
KSS-150A
PDF
NEC CD-810
2 x PCM56P-J + NEC µPD6352ACA
KSS-123A
PDF
NEC CD-816
2 x TDA1541A-S1 (Single Crown)
KSS-150A
PDF
NEC CD-830DS
2 x TDA1541A-S1 (Single Crown)
Toshiba TOPH7833
PDF
NEC CD-903
4 x PCM56P-K
KSS-123A
PDF
NESCO HCD-50
CX20152 – CX23035
KSS-121A / KSS-123A
PDF
NIKKO NCD 100
TD6705AP
Toshiba OPH-32
PDF
NORDMENDE SYSTEM 2000
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)
PDF
NORDMENDE SYSTEM 2003
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)
PDF
NORH CD-1
PCM1728
CDM 12
PDF
NORTH STAR EXTREMO DAC
2 x PCM1792 – SM5849BF
D/A converter
PDF
NORTH STAR MODEL 192 DAC
CS4396-KS – SM5849AF – CS8420-CS
D/A converter
PDF
NORTH STAR M192 TRANSPORT
Transport – CS8420 – SM5849BF
Philips CD-Pro 2 (VAM 1254)

O | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
ONIX CD-2
PCM1738
CDM 12
PDF
ONIX CD-5
PCM1732U
CDM 12.1
PDF
ONIX XCD-99
PCM1732U
CDM 12
PDF
ONKYO C-1E Integra
2 x TDA1547 (DAC7) – SM5843AP
-
PDF
ONKYO C-1VL
1 x Wolfson WM8740
Sony KSS-213
PDF
ONKYO C-1VL-S
2 x Wolfson WM8740
-
PDF
ONKYO C-500X Integra
CX20152 – CX23034
-
PDF
ONKYO C-501XD
2 x PCM56P – YM3414
KSS-212
PDF
ONKYO C-700 Integra
CX20152 – CX23034
KSS-121A / KSS-123A
PDF
ONKYO C-701A
CXD2589Q
KSS-213C
PDF
ONKYO C-701XD Integra
ONKYO 8D-3170-1 (2 x TC9219F)
DLBA2Z001A - Magnetic
PDF
ONKYO C-701XG Integra
2 x PCM58P – SM5813AP
DLBA2Z001A - Magnetic
PDF
ONKYO C-711
SM5872CN
KSS-240A
PDF
ONKYO C-725 Integra
2 x SM5864AP – SM5843AP
Sanyo SF-P100-S
PDF
ONKYO C-733-S
CS4396
KSS-213C
PDF
ONKYO C-901FX Integra
2 x SM5860BF - SM5813AP - SM5827CP
NEC SPU3011 - Magnetic
PDF
ONKYO C-901XD Integra
2 x PCM58P (ONKYO 8S-3380-1)
DLBA2Z001A - Magnetic
PDF
ONKYO C-2001 Integra
2 x OptoConverter 18Bit (PCM58P)
Sony BU-1E
PDF
ONKYO DX-5
CX890 / CX20017
Same as Toshiba OPH-31
PDF
ONKYO DX-100
1 x TD6705AP
Toshiba OPH-32
PDF
ONKYO DX-150
1 x PCM53JP – YM2201
TAOHS-MR
PDF
ONKYO DX-200 Integra
1 x CX20152 – CX23034
KSS-123A
PDF
ONKYO DX-220
1 x PCM56P – YM3815
KSS-123A
PDF
ONKYO DX-300 Integra
1 x CX20017
TAOHS-L (Toshiba OPH-32)
PDF
ONKYO DX-330
1 x PCM56P – YM3815
KSS-123A
PDF
ONKYO DX-530 Integra
1 x PCM56P – CXD1135Q
KSS-152A
PDF
ONKYO DX-700
1 x MN6472
KSS-210A
PDF
ONKYO DX-701
1 x TC9237BN
KSS-210A
PDF
ONKYO DX-702
1 x MN6472
KSS-210A
PDF
ONKYO DX-703
1 x SM5861AP – YM3433
KSS-210A
PDF
ONKYO DX-704
MN6472
-
PDF
ONKYO DX-705
1 x SM5861AP – YM3433
KSS-210A
PDF
ONKYO DX-706 Integra
2 x SM5861AP – SM5813AP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-708 Integra
2 x SM5861AP – SM5813AP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-788F Integra
2 x TDA1547 - SAA7350GP - SM5843AP
NEC SPU3013 - Magnetic
PDF
ONKYO DX-1400
2 x PCM61P – YM3433
KSS-150A
PDF
ONKYO DX-1500
1 x PCM56P-L – CXD1130Q
KSS-152A
PDF
ONKYO DX-1700
2 x PCM56P-L – SM5817AP
KSS-152A
PDF
ONKYO DX-1800
2 x AD1860N – YM3433
KSS-150A
PDF
ONKYO DX-2500
1 x PCM56P-L – CXD1135Q
KSS-152A
PDF
ONKYO DX-2800
1 x SM5860BF – YM3433 – SM5827CP
KSS-210A
PDF
ONKYO DX-3500
2 x PCM56P-L – YM3414
Toshiba TOPH7833-A
PDF
ONKYO DX-3700
2 x AD1860N-J – SM5813AP
KSS-150A
PDF
ONKYO DX-3800 Integra
2 x SM5860BF - SM5813AP - SM5827CP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-5500 Integra
ONKYO 8D-3170-1 (2 x TC9219F)
DLBA2Z001A - Magnetic
PDF
ONKYO DX-5700 Integra
2 x PCM58P-X – SM5813AP
DLBA2Z001A - Magnetic
PDF
ONKYO DX-6430
YM3020
9110982
PDF
ONKYO DX-6470
PCM56
KSS-152A
PDF
ONKYO DX-6520
1 x PCM56P
KSS-152A
PDF
ONKYO DX-6530
1 x PCM56P
KSS-152A
PDF
ONKYO DX-6540
PCM56P
KSS-152A
PDF
ONKYO DX-6550 Integra
ONKYO 8D-3170-1 (2 x TC9219F)
DLBA2Z001A - Magnetic
PDF
ONKYO DX-6570 Integra
2 x PCM58P (ONKYO 8S-3380-1)
DLBA2Z001A - Magnetic
PDF
ONKYO DX-6620
LC7881
KSS-210A
PDF
ONKYO DX-6640
2 x PCM56P – SM5817AP
KSS-152A
PDF
ONKYO DX-6650
2 x AD1860N-J – SM5813AP
KSS-150A
PDF
ONKYO DX-6660 Integra
2 x PCM58P
DLBA2Z001B
PDF
ONKYO DX-6700
2 x PCM61P – YM3433
KSS-150A
PDF
ONKYO DX-6720
2 x AD1860
-
PDF
ONKYO DX-6750 Integra
2 x SM5860BF - SM5813AP - SM5827CP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-6770 Integra
2 x SM5860BF - SM5813AP - SM5827CP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-6800 Integra
2 x SM5860BF - SM5813AP - SM5827CP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-6850 Integra
2 x SM5861AP – SM5813AP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-6870 Integra
2 x SM5861AP – SM5813AP
NEC SPU3011 - Magnetic
PDF
ONKYO DX-6890 Integra
2 x TDA1547 - SAA7350GP - SM5843AP
NEC SPU3013 - Magnetic
PDF
ONKYO DX-6920
1 x SM5861AP - YM3433
KSS-210A
PDF
ONKYO DX-6930
1 x SM5861AP - YM3433
KSS-210A
PDF
ONKYO DX-6990 Grand Integra
2 x OptoConverter 18Bit (PCM58P)
Sony BU-1E
PDF
ONKYO DX-7011
1 x TC9237
KSS-210A
PDF
ONKYO DX-7110
1 x SM5872CN
KSS-240A
PDF
ONKYO DX-7111
1 x SM5874AM
KSS-213C
PDF
ONKYO DX-7210
1 x SM5872CN
KSS-240A
PDF
ONKYO DX-7211
1 x SM5874AM
KSS-213C
PDF
ONKYO DX-7222
1 x TC9268BP
KSS-213C
PDF
ONKYO DX-7310
1 x SM5872CN
KSS-240A
PDF
ONKYO DX-7333
1 x TC9268P
KSS-213C
PDF
ONKYO DX-7355
1 x WM8716 WolfSon
KSS-213C
PDF
ONKYO DX-7500 Integra
2 x (ONKYO 8S-3380-1) – YM3414
DLBA2Z001A - Magnetic
PDF
ONKYO DX-7510
1 x SM5861AP – SM5843AP
KSS-240A
PDF
ONKYO DX-7511
1 x SM5872CN
KSS-213C
PDF
ONKYO DX-7555
1 x WM8740 WolfSon
KSS-213C
PDF
ONKYO DX-7711 Integra
2 x SM5864AP – SM5843AP
Sanyo SF-P100-S (13 pin)
PDF
ONKYO DX-7911 Integra
2 x SM5864AP – SM5843AP
Sanyo SF-P100-S (13 pin)
PDF
ONKYO DX-F33
PCM56P-L
KSS-152A
PDF
ONKYO DX-G10 Grand Integra
2 x OptoConverter 18Bit (PCM58P)
Sony BU-1E
PDF
ONKYO DX-M505
1 x SM5861AP – YM3433
Pioneer PWY1009 / PWY1010
PDF
ORACLE CD 1000/1500
CS4390
CDM 12.4 Pro
PDF
ORACLE CD DRIVE
Transport
Philips CD-Pro (VAM 1252)
PDF
ORELLE CD100
TDA1541
CDM-4
PDF
ORELLE CD100SE
TDA1541A-S1 (Single Crown)
CDM-4
PDF
Original Electronics CD-2008
PCM1732
VAM 1202
PDF
Original Electronics CD-2008F
PCM1792
VAM 12
PDF
Original Electronics CD-2008Mk-II
PCM1792 + PCM1732
VAM 12
PDF
Original Electronics CD-A6s
CS4390
VAM 1202
PDF
Original Electronics CD-A8s
PCM1732
VAM 1202
PDF
Original Electronics CD-A8T
PCM1732 – SAA7327
VAM 12
PDF
Original Electronics CD-A9 II
PCM1792
KSS-213
PDF
Original Electronics CD-A9.3
PCM1792
VAM 12
PDF
Original Electronics CD-A9.8
PCM1732
VAM 1202
PDF
ORPHEUS Orpheus ONE
AD1853
D/A converter
PDF
ORPHEUS Orpheus Zero D
Transport
Philips CD-Pro 2 (VAM 1254)
PDF
ORPHEUS Orpheus Zero P
WM8740 WolfSon
Philips CD-Pro 2 (VAM 1254)
PDF
OTTO DAD-03
CX20017 / PCM51JG-V
4 180T00271 (Toshiba OPH-32)

P | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
PANASONIC SL-D70
Transport
SOAD70A
PDF
PANASONIC SL-D6000
PCM55HP
SOALP1200 KM3
PDF
PANASONIC SL-PJ324
µPD6276 – SM5807 – MN6625
SOAD70A
PDF
PANASONIC SL-PJ325
µPD6376 – SM5807ES
CDM-4/19
PDF
PARASOUND CD M839
PCM56
-
PDF
PARASOUND C/DP-1000
PCM67U
CEC-Sanyo SF-P1
PDF
PARASOUND C/DC-1500
PCM67P
-
PDF
PARASOUND C/BD-2000
Transport
CEC-Sanyo SF-P1
PDF
PARASOUND C/DP-2000
2 x PCM1702 – PMD100
C.E.C.
PDF
PARASOUND D/AC-800
PCM67P-J – SM5813AP – YM3623B
D/A converter
PDF
PARASOUND D/AC-1000
2 x PCM63P-J - SM5813AP - CS8412-CP
D/A converter
PDF
PARASOUND D/AC-1100 HD
4 x PCM63P-J – PMD100
D/A converter
PDF
PARASOUND D/AC-1500
4 x PCM63P-K - SM5813AP - CS8412-CP
D/A converter
PDF
PARASOUND D/AC-1600 HD
4 x PCM63P-K – PMD100
D/A converter
PDF
PARASOUND D/AC-2000
UltraAnalog D20400A – PMD100
D/A converter
PDF
PASS LABS D1
PCM63P-K
D/A converter
PDF
PATHE MARCONI PM/LA10
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)
PDF
PATHE MARCONI PM/LA20
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)
PDF
PATHOS ENDORPHIN
CS4396
Philips CD-Pro 2 (VAM 1254)
PDF
PATHOS InTransfer
PCM63P-K
D/A converter
PDF
PHASE LINEAR Model 9500
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)
PDF
PHILIPS AK 601
TDA1543A
CDM-4/19
PDF
PHILIPS AK 630
TDA1543A – M50423FP
CDM-4/19
PDF
PHILIPS AK 640
SAA7341GP
CDM-4/19
PDF
PHILIPS CD10
Sony CX20133 – CX23035
CDM-2-P
PDF
PHILIPS CD-80
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
PHILIPS CD-85
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
PHILIPS CD100
2 x TDA1540D – M4551 (SAA7030)
CDM-0
PDF
PHILIPS CD101
2 x TDA1540D – SAA7030
CDM-1
PDF
PHILIPS CD104
2 x TDA1540P – SAA7030
CDM-1
PDF
PHILIPS CD115
TDA1543
CDM-4/19
PDF
PHILIPS CD130
TDA1543
CDM-4/19
PDF
PHILIPS CD140
TDA1543
CDM-4/19
PDF
PHILIPS CD150
2 x TDA1540P – SAA7030
CDM-2/10
PDF
PHILIPS CD151
2 x TDA1540P – SAA7030
CDM-2/10
PDF
PHILIPS CD160
TDA1541 – SAA7220P/A
CDM-2/10
PDF
PHILIPS CD162
SAA7341GP
CDM-4/19
PDF
PHILIPS CD163
TDA1545A – SAA7345GP
CDM 12.1/05
PDF
PHILIPS CD165
TDA1545A – SAA7345GP
CDM 12.1/05
PDF
PHILIPS CD200
2 x TDA1540D – SAA7030 (M4551)
CDM-0
PDF
PHILIPS CD202
2 x TDA1540D – SAA7030
CDM-0
PDF
PHILIPS CD204
2 x TDA1540P – SAA7030
CDM-1
PDF
PHILIPS CD207
TDA1541 – SAA7220P/A – TDA1542
CDM-2-P
PDF
PHILIPS CD210
TDA1543 – SAA7220
CDM-4/19
PDF
PHILIPS CD230
TDA1543A – M50423FP
CDM-4/19
PDF
PHILIPS CD300
2 x TDA1540D – SAA7030 (M4551)
CDM-0
PDF
PHILIPS CD303
2 x TDA1540D – SAA7030
CDM-0
PDF
PHILIPS CD304
2 x TDA1540P – SAA7030
CDM-1
PDF
PHILIPS CD304 Mk II
TDA1541 – SAA7220P/A – SAA7210P
CDM-1
PDF
PHILIPS CD350
2 x TDA1540P – SAA7030
CDM-2 / CDM-2/10
PDF
PHILIPS CD351
2 x TDA1540P – SAA7030
CDM-2
PDF
PHILIPS CD360
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-2/29
PDF
PHILIPS CD371
TDA1541
CDM-2/29 / CDM-4/11
PDF
PHILIPS CD372
TDA1541
CDM-2
PDF
PHILIPS CD373
TDA1541
CDM-2 / CDM-4/11
PDF
PHILIPS CD380
TDA1543
CDM-4/19
PDF
PHILIPS CD450
TDA1541 – SAA7220P/A
CDM-2
PDF
PHILIPS CD460
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-4/25
PDF
PHILIPS CD465
TDA1541
-
PDF
PHILIPS CD470
TDA1541
CDM-2 / CDM-4/11
PDF
PHILIPS CD471
TDA1541
CDM-2 / CDM-4/11
PDF
PHILIPS CD472
TDA1541 – SAA7220P/A
CDM-4/11
PDF
PHILIPS CD473
TDA1541
CDM-2 / CDM-4/11
PDF
PHILIPS CD480
TDA1541 / TDA1543 – SAA7220
CDM-4/19
PDF
PHILIPS CD482
TDA1543 – SAA7220P/A
CDM-4/19
PDF
PHILIPS CD500
TDA1543
CDM-4/19
PDF
PHILIPS CD502
TDA1543
CDM-4/19
PDF
PHILIPS CD560
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-4/25
PDF
PHILIPS CD580
TDA1541
-
PDF
PHILIPS CD581
TDA1541
CDM-4/19
PDF
PHILIPS CD582
TDA1541 – SAA7220P/A
CDM-4/19
PDF
PHILIPS CD584
TDA1541A – SAA7220P/B
CDM-4/19
PDF
PHILIPS CD586
TDA1541A
CDM-4/20
PDF
PHILIPS CD600
TDA1543 – SAA7220
CDM-4/19
PDF
PHILIPS CD604
TDA1543
CDM-4/19
PDF
PHILIPS CD605
SAA7321GP
CDM-4/19
PDF
PHILIPS CD610
TDA1543 – SAA7220
CDM-4/19
PDF
PHILIPS CD614
TDA1543
CDM-4/19
PDF
PHILIPS CD615
SAA7321GP
CDM-4/19
PDF
PHILIPS CD618
SAA7323
CDM-4/19
PDF
PHILIPS CD620
TDA1541A – SAA7220P/B
CDM-4/19
PDF
PHILIPS CD624
SAA7321GP
CDM-4/19
PDF
PHILIPS CD630
TDA1541A – SAA7220P/B
CDM-4/19
PDF
PHILIPS CD634
SAA7321
CDM-4/19
PDF
PHILIPS CD640
TDA1541 – SAA7220P/A
CDM-2
PDF
PHILIPS CD650
TDA1541 – SAA7220P/A – SAA7210P
CDM-2/10 / CDM-4/25
PDF
PHILIPS CD660
TDA1541 – SAA7220P/A
CDM-2 / CDM-4/11
PDF
PHILIPS CD670
TDA1541 – SAA7220P/A
CDM-2/10 / CDM-4/11
PDF
PHILIPS CD680
TDA1541A – SAA7220P/B
CDM-2/10 / CDM-4/11
PDF
PHILIPS CD690
SAA7341
CDM 12.1
PDF
PHILIPS CD692
SAA7341GP
CDM 12
PDF
PHILIPS CD710
TDA1545A – SAA7345
CDM 12.1
PDF
PHILIPS CD713
TDA1545A
VAM 1202
PDF
PHILIPS CD720
TDA1545A
CDM 12.1
PDF
PHILIPS CD721
TDA1545A
CDM 12
PDF
PHILIPS CD722
TDA1545A
VAM 1201
PDF
PHILIPS CD723
TDA1545 – SAA7378
VAM 1201
PDF
PHILIPS CD732
SAA7341
CDM 12.1
PDF
PHILIPS CD740
TDA1549T – SAA7345GP
CDM 12.1
PDF
PHILIPS CD750
SAA7350 – SM5840AS – SAA7345
CDM 12.1
PDF
PHILIPS CD751
TDA1549T – SAA7345
CDM 12.1/05
PDF
PHILIPS CD753
TDA1549 – SAA7378
CDM 12.1 / VAM 1201
PDF
PHILIPS CD771
TDA1541 – SAA7220P/A
CDM-2 / CDM-4/11
PDF
PHILIPS CD780
TDA1541A – SAA7220
CDM-4/19
PDF
PHILIPS CD782
TDA1541 – SAA7220P/A
CDM-2 / CDM-4
PDF
PHILIPS CD820
TDA1541A – SAA7220P/B
CDM-4/19
PDF
PHILIPS CD824
SAA7321GP
CDM-4/19
PDF
PHILIPS CD830
TDA1541A – SAA7220P/B
CDM-4/19 Composite
PDF
PHILIPS CD834
SAA7321GP
CDM-4/19
PDF
PHILIPS CD840
2 x SAA7321GP – SAA7220P/B
CDM-4/19
PDF
PHILIPS CD850
2 x SAA7321GP – SAA7220P/B
CDM-4/19
PDF
PHILIPS CD850 Mk II
SAA7350GP – SAA7322
CDM-4/19
PDF
PHILIPS CD880
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
PHILIPS CD910
SAA7341GP
CDM 12.1/05
PDF
PHILIPS CD911
SAA7341GP
CDM 12.1/05
PDF
PHILIPS CD920
SAA7341GP
CDM 12.1/05
PDF
PHILIPS CD930
SAA7350
CDM-9/44
PDF
PHILIPS CD931
SAA7350
CDM-9/65
PDF
PHILIPS CD940
SAA7350GP – SM5840AS
CDM-9/44
PDF
PHILIPS CD950
TDA1547 – SAA7350
CDM-9/44
PDF
PHILIPS CD951
TDA1547 – SAA7350 – SAA7310
CDM-9/65
PDF
PHILIPS CD960
TDA1541 – SAA7220P/A – SAA7210P
CDM-1
PDF
PHILIPS CDC486
TDA1543
CDM-4/20
PDF
PHILIPS CDC745
SAA7341GP
CDM 12.1/05
PDF
PHILIPS CDC875
TDA1541A
CDM-4/19
PDF
PHILIPS CDD461
TDA1543
CDM-4/19
PDF
PHILIPS CDD882
Transport – SAA7210P
CDM-1 Mk II
PDF
PHILIPS CDI-470
TDA1305T
CDM 12
PDF
PHILIPS CDI-910
SAA7321GP
CDM-9
PDF
PHILIPS CDR950
AD1855
-
PDF
PHILIPS CDV496
TDA1541A – SAA7220P/B – TDA1542
CDM-10
PDF
PHILIPS DAC960
1 x TDA1541A
D/A converter
PDF
PHILIPS LHH100M
1 x TDA1547 – SM5840
CDM-9
PDF
PHILIPS LHH200R
1 x TDA1547 (DAC7)
CDM-9
PDF
PHILIPS LHH300
2 x SAA7321GP – SAA7220P/B
CDM-4/36 Metallic
PDF
PHILIPS LHH300R
1 x TDA1547 (DAC7) – SAA7350
CDM-9
PDF
PHILIPS LHH500
2 x SAA7321GP – SAA7220P/B
CDM-4/36 Metallic
PDF
PHILIPS LHH500R
1 x TDA1547 - SAA7350AGP - SM5803AP
CDM-4/36 Metallic
PDF
PHILIPS LHH600
TDA1547 (DAC7)
CDM-4/36 Metallic
PDF
PHILIPS LHH700
2 x TDA1547 - SAA7350GP - SM5803APT
CDM-4/36 Metallic
PDF
PHILIPS LHH800R
1 x TDA1547 - SAA7350GP - SM5803APT
CDM-4/36 Metallic
PDF
PHILIPS LHH900R
1 x TDA1547 (DAC7)
CDM-4/36 Metallic
PDF
PHILIPS LHH1000
TDA1541A-S1 (Double Crown)
CDM-1
PDF
PHILIPS LHH2000
2 x TDA1540P – SAA7030
CDM-0 / CDM-1
PDF
PINK TRIANGLE CARDINAL
Transport
Sanyo SF-91
PDF
PINK TRIANGLE CORDINAL
2 x TDA1547
Sanyo SF-91
PDF
PINK TRIANGLE DACAPO
SAA7350 – DF1700
D/A converter
PDF
PINK TRIANGLE NUMERAL
TDA1305T
-
PDF
PINK TRIANGLE ORDINAL
2 x TDA1547
D/A converter
PDF
PIONEER CDX-M80
2 x PCM63P – SM5813AF
D/A converter
PDF
PIONEER CLD-77
1 x PCM56P
-
PDF
PIONEER CLD-99S
2 x PCM56P-J – SM5807EP
-
PDF
PIONEER CLD-1500
2 x AD1860N – PD0050
-
PDF
PIONEER CLD-1700
PD2026 – CXD2500
-
PDF
PIONEER CLD-1950
PD2026B
-
PDF
PIONEER CLD-3030
2 x PCM56P-J – SM5807EP
-
PDF
PIONEER DV-717
PE8001A
-
PDF
PIONEER P-D1
PCM52JG-V
Same as Toshiba OPH-31
PDF
PIONEER PD-31
2 x PD2026A
PEA1030 / PWY1013 Stable Platter
PDF
PIONEER PD-52
2 x PD2028B – PD0116A
PEA1030 Stable Platter
PDF
PIONEER PD-54
2 x PD2028B – PD0116A
PEA1179 / PEA1285 Stable Platter
PDF
PIONEER PD-59
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-65
2 x PD2028B – PD0116A
PEA1030 Stable Platter
PDF
PIONEER P-D70
CX20017
VWY-061 / VWY-063
PDF
PIONEER PD-71
2 x PCM58P-K – SM5803AP
PWY1006 - Magnetic
PDF
PIONEER PD-73
2 x PCM63P-K
PWY1011 - Magnetic
PDF
PIONEER PD-75
2 x PD2028A / B
PWY1004 - Magnetic Stable Platter
PDF
PIONEER PD-77
PD2028B
Stable Platter
PDF
PIONEER P-D90
CX20017
VWY-061 / VWY-063
PDF
PIONEER PD-91
2 x PCM65 – YM3414 + PDE023
PWY1004 - Magnetic
PDF
PIONEER PD-93
2 x PCM63P-K – SM5813AP
PWY1004 - Magnetic
PDF
PIONEER PD-95
2 x PD2028A / B
PWY1004 - Magnetic Stable Platter
PDF
PIONEER PD-101
PD2026A
PEA1030
PDF
PIONEER PD-102
PD2026A
PEA1179
PDF
PIONEER PD-103
PD2026B
PEA1179
PDF
PIONEER PD-104
PD2026B
PEA1291
PDF
PIONEER PD-106
CXD2519Q
PEA1335
PDF
PIONEER PD-117
CXD2519Q
PEA1335
PDF
PIONEER PD-201
PD2026A
PEA1030
PDF
PIONEER PD-202
PD2026A
PEA1179
PDF
PIONEER PD-203
PD2026B
PEA1179
PDF
PIONEER PD-204
PD2026B
PEA1291
PDF
PIONEER PD-206
CXD2519Q
PEA1335
PDF
PIONEER PD-217
CXD2519Q
PEA1335
PDF
PIONEER PD-306
PD2029A – CXD2519Q
PEA1335
PDF
PIONEER PD-515
2 x PCM56P-J – SM5807EP
PWY1010
PDF
PIONEER PD-717
2 x AD1860N-J – PD0036
PWY1011 - Magnetic
PDF
PIONEER PD-737
2 x PCM58P – SM5813AP
PWY1011 - Magnetic
PDF
PIONEER PD-2000
2 x PCM58P-K – SM5803AP
PWY1006 - Magnetic
PDF
PIONEER PD-3000
2 x PCM65
PWY1004 - Magnetic
PDF
PIONEER PD-4050
1 x PCM56P-L – CXD1130QZ
PWY1010
PDF
PIONEER PD-4100
LC7881 – PD0034
PWY1009 / PWY1010
PDF
PIONEER PD-4500
PCM1700
PEA1030
PDF
PIONEER PD-4550
PCM1700P-L – SM5840BP
PEA1030
PDF
PIONEER PD-5000
2 x PCM58P-K
PWY1004 - Magnetic
PDF
PIONEER PD-5010
CX20152 – CX23035
PWY-004
PDF
PIONEER PD-5030
CX20152 – CX23035
PWY-007
PDF
PIONEER PD-5050
1 x PCM56P – CXD1130QZ
PWY1010
PDF
PIONEER PD-5100
2 x PCM56P – PD0034
PWY1010
PDF
PIONEER PD-5300
PCM56P-L – SM5818AP
PWY1010
PDF
PIONEER PD-5500
PCM1700P
PEA1030
PDF
PIONEER PD-5700
PD2026A
PEA1030
PDF
PIONEER PD-6010
CX20152 – CX23035
PWY-004
PDF
PIONEER PD-6030
CX20152 – CX23035
PWY-007
PDF
PIONEER PD-6050
1 x PCM56P-J – CXD1135QZ
PWY1010
PDF
PIONEER PD-6070
1 x PCM56P-J – CXD1135QZ
PWY1010
PDF
PIONEER PD-6100
2 x PCM56P
PWY1010
PDF
PIONEER PD-6300
2 x PCM61P – PD0036
PWY1010
PDF
PIONEER PD-6500
PD7007 – SM5840AP
PEA1030
PDF
PIONEER PD-7010
CX20152
PWY-004
PDF
PIONEER PD-7030
CX20152 – CX23034
PWY-007
PDF
PIONEER PD-7050
2 x PCM56P-J – SM5807BP
PWY1010
PDF
PIONEER PD-7070
2 x PCM56P-J – SM5807EP
PWY1010
PDF
PIONEER PD-7100
2 x PCM56P-J – PD0036
PWY1011 - Magnetic
PDF
PIONEER PD-7300
2 x PCM58P – SM5813AP
PWY1011 - Magnetic
PDF
PIONEER PD-7500
PD7007 – SM5840AP
PEA1030
PDF
PIONEER PD-7700
1 x PD2026A
PEA1030 Stable Platter
PDF
PIONEER PD-8030
CX20152 – CX23034
PWY-004
PDF
PIONEER PD-8070
TDA1541
PWY1010
PDF
PIONEER PD-8500
2 x PCM63P-J – SM5813AP
PWY1011 - Magnetic
PDF
PIONEER PD-8700
2 x PD2026A
PEA1030 / PWY1013 Stable Platter
PDF
PIONEER PD-9010X
CX20152 – CX23034
PWY-004
PDF
PIONEER PD-9300
2 x PCM58P-K – SM5803AP
PWY1006 - Magnetic
PDF
PIONEER PD-9700
2 x PD2028A
PEA1030 Stable Platter
PDF
PIONEER PD-D6
2 x PCM1738
-
PDF
PIONEER PD-D9
Wolfson WM8741
SACD
PDF
PIONEER PD-F705
PD2029A
PEA1179
PDF
PIONEER PD-HL5
PE8001 – PD0236AD – CXD2507AQ
PEA1335 Stable Platter
PDF
PIONEER PD-M53
PD2026A
PEA1030
PDF
PIONEER PD-M59
PD2029A
PEA1179
PDF
PIONEER PD-M60
CX20152
PWY-006
PDF
PIONEER PD-M70
CX20152
PWY-006
PDF
PIONEER PD-M90X
CX20152
PWY-006
PDF
PIONEER PD-M407
PD2026B – CXD2519Q
PEA1335
PDF
PIONEER PD-M427
PD2026B – CXD2519Q
PEA1335
PDF
PIONEER PD-M500
LC7881 – PD0034
PWY1009 / PWY1010
PDF
PIONEER PD-M501
PD2026A
PEA1179
PDF
PIONEER PD-M640
PD2026A
PEA1030
PDF
PIONEER PD-M650
PD2026A
PEA1030
PDF
PIONEER PD-M700
2 x PCM56P-J – PD0036
PWY1009 / PWY1010
PDF
PIONEER PD-M701
PD2026A
PEA1179
PDF
PIONEER PD-M801
PD2026A
PEA1030
PDF
PIONEER PD-M900
2 x PCM56P-J – PD0036
PWY1009 / PWY1010
PDF
PIONEER PD-M901
PD2026A
PEA1030
PDF
PIONEER PD-M910
2 x PCM58P-K
PWY1009 / PWY1010
PDF
PIONEER PDR-04
AKM4321
Writer
PDF
PIONEER PDR-05
2 x PD2028B
Writer – Stable Platter
PDF
PIONEER PDR-09
2 x PD2028B
Writer – Stable Platter
PDF
PIONEER PDR-609
PCM1716
Writer
PDF
PIONEER PDR-W739
PCM1716
Writer
PDF
PIONEER PDR-W839
PCM1716
Writer
PDF
PIONEER PD-S06
2 x PCM1702-J – PD7009B – PD0236AD
PEA1343 Stable Platter
PDF
PIONEER PD-S501
PD2026A
PEA1030 Stable Platter
PDF
PIONEER PD-S502
PD2026B – CXD2500BQ
PEA1179 Stable Platter
PDF
PIONEER PD-S503
PD2029A – CXD2500BQ
PEA1179 Stable Platter
PDF
PIONEER PD-S504
PD2029A – CXD2500BQ
PEA1179 Stable Platter
PDF
PIONEER PD-S505
PD2029A – PD0236AD - CXD2507AQ
PEA1291 Stable Platter
PDF
PIONEER PD-S506
PD2029A – CXD2507
PEA1335 Stable Platter
PDF
PIONEER PD-S507
PE8001A – PD0236AM - CXD2507AQ
PEA1335 Stable Platter
PDF
PIONEER PD-S601
PD2026A
PEA1030 Stable Platter
PDF
PIONEER PD-S602
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-S603
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-S604
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-S605
PD2029A – PD0236AD - CXD2507AQ
PEA1291 Stable Platter
PDF
PIONEER PD-S701
PD2026A
PEA1030 Stable Platter
PDF
PIONEER PD-S702
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-S703
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-S705
PD2029A – PD0236AD - CXD2507AQ
PEA1291 Stable Platter
PDF
PIONEER PD-S707
PE8001A – PD0236AD - CXD2507AQ
PEA1335 Stable Platter
PDF
PIONEER PD-S801
2 x PD2028B – PD0116A
PEA1030 Stable Platter
PDF
PIONEER PD-S802
2 x PD2028B – PD0116A
PEA1179 / PEA1285 Stable Platter
PDF
PIONEER PD-S901
2 x PD2028B – PD0116A
PEA1030 Stable Platter
PDF
PIONEER PD-S904
2 x PD2028B – PD7009A
PEA1179 / PEA1285 Stable Platter
PDF
PIONEER PD-T01
PD2026B
PEA1179 Stable Platter
PDF
PIONEER PD-T03
PD2026A
PEA1030 Stable Platter
PDF
PIONEER PD-T04
2 x PD2028B – PD0116A
PEA1179 Stable Platter
PDF
PIONEER PD-T05
2 x SAA7350GP – SM5840AP
PWY1004 - Magnetic Stable Platter
PDF
PIONEER PD-T06
2 x PD2028B
PWY1004 - Magnetic Stable Platter
PDF
PIONEER PD-T07
2 x PD2028B
PWY1004 - Magnetic Stable Platter
PDF
PIONEER PD-T09
2 x PD2028A / B
PWY1004 - Magnetic Stable Platter
PDF
PIONEER PD-UK3
PD2029A
PEA1179 Stable Platter
PDF
PIONEER PD-UK5
2 x PD2028B – PD0116A
PEA1179 Stable Platter
PDF
PIONEER PD-X88
CX20152 – CX23035
PWY-007
PDF
PIONEER PD-X303
CX20152 – CX23035
PWY-004
PDF
PIONEER PD-X520
CX20152 – CX23035
PWY-007
PDF
PIONEER P-DX700
TD6705AP
VWY-061 / VWY-063
PDF
PIONEER PD-X707
CX20152 – CX23035
PWY-004
PDF
PIONEER PD-X737
CX20152 – CX23035
PWY-007
PDF
PIONEER PD-Z71
LC7881 – CXD1135QZ
PWY1010
PDF
PIONEER PD-Z82
LC7881 – CXD1130Q
PWY1009 / PWY1010
PDF
PLINIUS CD-101
2 x PCM1704-J – DF1706E
CD-ROM ASUS CD-S520
PDF
PMG 8800 E
YM3020
-
PDF
PRIMARE CD21
2 x PCM1738 – DIR1703
DVD-ROM DVS DSL-710A
PDF
PRIMARE CD31
4 x PCM1704-K – DF1704
DVD-ROM DVS DSL-710A
PDF
PRIMARE D20
AKM4324
CDM 12.4
PDF
PRIMARE D20 Mk II
AKM4324
KSS-213C
PDF
PRIMARE D30.2
4 x PCM1702-K – DF1704
CDM 12.4
PDF
PROCEED CDD
Transport
Philips CD-Pro (VAM 1252)
PDF
PROCEED CDP
2 x AD1864N-K – PMD100
CDM 12 Ind
PDF
PROCEED DAP
2 x AD1864N-K – PMD100 – CS8412-CP
D/A converter
PDF
PROCEED MRC100
2 x PCM58P
CDM-1 Mk II
PDF
PROCEED PCD
2 x PCM58P – SM5813AP
CDM-1 Mk II
PDF
PROCEED PCD2
2 x PCM58P – SM5813AP
CDM-1 Mk II
PDF
PROCEED PCD3
2 x PCM63P
CDM-1 Mk II
PDF
PROCEED PDP
2 x PCM58P – SM5813APT
D/A converter
PDF
PROCEED PDP2
2 x PCM58P – SM5813APT – YM3623B
D/A converter
PDF
PROTON 830R
2 x TDA1540P – SAA7030
CDM-2
PDF
PROTON AC-300 Mk II
TDA1541A
Philips CDM
PDF
PROTON AC-423
LC78820
-
PDF
PROTON AC-424
TDA1311A
-
PDF
PROTON AC-620
TDA1541A
CDM-4
PDF
PS AUDIO CD-1
2 x TDA1540P – SAA7030
CDM-2
PDF
PS AUDIO DIGILINK II
PCM1702 + HDCD
D/A converter
PDF
PS AUDIO DIGITAL LINK TWO
2 x AD1860N-K – YM3434 - YM3623B
D/A converter
PDF
PS AUDIO DIGITAL LINK III
PCM1798 – CS8416
D/A converter
PDF
PS AUDIO LAMBDA
Transport
CDM-9 Pro
PDF
PS AUDIO LAMBDA 2
Transport
CDM-9 Pro
PDF
PS AUDIO REFERENCE LINK II
UA D20400A + 2 x AD1860N-K
D/A converter
PDF
PS AUDIO SUPERLINK TWO
2 x AD1860N-K - SM5813APT - YM3623B
D/A converter
PDF
PS AUDIO SUPERLINK THREE
2 x PCM63P – PMD100
D/A converter
PDF
PS AUDIO ULTRALINK
UltraAnalog D20400A – SM5803AP
D/A converter
PDF
PS AUDIO ULTRALINK TWO
UltraAnalog D20400A – PMD100
D/A converter

Q | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
QUAD 66
TDA1541A – SAA7220P/B
CDM-4
PDF
QUAD 67
CS4328-KP – SAA7310GP
CDM-9/44
PDF
QUAD 77
CS4328
CDM 12.4
PDF
QUAD 99
CS4396
-

R | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
RADMOR 5450
TDA1543A
CDM-4/19
PDF
RAYSONIC CD128
PCM1732
KSS-213
PDF
RAYSONIC CD168
2 x PCM1792
VAM 1202
PDF
REALISTIC CD-1000
PCM53JP-V – TM5001 (HD61902H)
Hitachi HOP-M14
PDF
REGA APOLLO
Wolfson WM8740
-
PDF
REGA JUPITER 2000
Wolfson WM8740
KSS-213
PDF
REGA PLANET
PCM1710U
KSS-240A
PDF
REGA PLANET 2000
Wolfson WM8716
KSS-213B
PDF
REGA SATURN
2 x Wolfson WM8740
-
PDF
RESOLUTION AUDIO Quantum
UltraAnalog D20400A + HDCD
D/A converter
PDF
RESTEK EPOS
2 x PCM1704-K – PMD100
Philips CD-Pro (VAM 1252)
PDF
RESTEK RADIANT
1 x PCM56P-J – SM5807
-
PDF
REVOX B 126
TDA1541A – SAA7220P/B
CDM-1 / CDM-4
PDF
REVOX B 225
2 x TDA1540 – SAA7030
CDM-0 / CDM-1
PDF
REVOX B 226
TDA1541 – SAA7220P/A
CDM-1
PDF
REVOX B 226 Mk II / Signature
TDA1541A – SAA7220P/B
CDM-1
PDF
REVOX B 226 S / E
TDA1541A-S1 (Single Crown)
CDM-1 Mk II
PDF
REVOX C 221
TDA1305T – SAA7350
CDM-4
PDF
REVOX E 426
TDA1547 (DAC7) – TDA1307
VAM 1205
PDF
REVOX H 2
SAA7323GP
CDM-4
PDF
ROKSAN ATTESSA DP3P
CS4328
-
PDF
ROKSAN CASPIAN
TDA1305T
Sanyo SF-P1
PDF
ROKSAN KANDY KC-1
PCM1716
Sony KSS
PDF
ROKSAN KANDY KC-1 Mk III
PCM1730E
Sanyo SF-P101N
PDF
ROKSAN ROK-DP1
Transport
Sanyo SF-90
PDF
ROTEL RCD-02
PCM1732U
KSS-213C
PDF
ROTEL RCD-06
PCM1716
KSS-213
PDF
ROTEL RCC-955
PCM69
-
PDF
ROTEL RCD-820
TDA1541
-
PDF
ROTEL RCD-850
PCM54HP
MLP-3C
PDF
ROTEL RCD-855
TDA1541A – SAA7220P/B
CDM-4/19
PDF
ROTEL RCD-856BX
SAA7323
-
PDF
ROTEL RCD-865BX
SAA7323
CDM-4
PDF
ROTEL RCD-870
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)
PDF
ROTEL RCD-940BX
LC78820M – LC78840M (filter)
Sanyo SF-P1
PDF
ROTEL RCD-945AX
SAA7341GP T
CDM-4
PDF
ROTEL RCD-950
TDA1305A
KSS-210A
PDF
ROTEL RCD-951
PCM69AP – PMD100
KSS-213
PDF
ROTEL RCD-955
TDA1541
CDM-4
PDF
ROTEL RCD-955AX
TDA1541A – SAA7220P/B
CDM-4/19
PDF
ROTEL RCD-961
PCM1732U
KSS-213
PDF
ROTEL RCD-965BX
SAA7323GP – SAA7220P/B
CDM-4/19
PDF
ROTEL RCD-970BX
1 x TDA1305T
CDM-9
PDF
ROTEL RCD-971
2 x PCM63P – PMD100
KSS-213
PDF
ROTEL RCD-975
2 x TDA1305T
CDM-9
PDF
ROTEL RCD-990
2 x PCM63P – PMD100
CDM-9 Pro
PDF
ROTEL RCD-991
2 x PCM63P – PMD100
KSS-213
PDF
ROTEL RCD-1070
PCM1732U
KSS-213C
PDF
ROTEL RCD-1072
PCM1732
KSS-213C
PDF
ROTEL RDD-980
Transport
CDM-9
PDF
ROTEL RDP-980
AK4328-VP – CS8412-CP
D/A converter

S | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
SABA CD-1015
PCM56P
KSS-123A ?
PDF
SABA CDP 380
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)
PDF
SABA CDP 480
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)
PDF
SAE D102
2 x TDA1540P – SAA7030
CDM-2
PDF
SAE D103
TDA1541
CDM-2 / CDM-4
PDF
SAMSUNG CD-42
LC7881
Samsung SOH-OT1
PDF
SANSUI CD-200
KDA0316 (Samsung)
-
PDF
SANSUI CD-a7
SM5874AM
KSS-210A
PDF
SANSUI CD-a317R
2 x MN6474M
KSS-240A
PDF
SANSUI CD-a507
2 x PCM1702
KSS-213B
PDF
SANSUI CD-a607
2 x PCM1704U – PMD100
KSS-213
PDF
SANSUI CD-a617DR
MN6474M
KSS-152 - Magnetic
PDF
SANSUI CD-a707
1 x PCM54HP-J – SM5806P
Sansui S-706HB / 18734900
PDF
SANSUI CD-a707i
PCM56P-S
KSS-152A
PDF
SANSUI CD-a717DR
2 x MN6474M – YM7402
KSS-152 - Magnetic
PDF
SANSUI CD-a717EXTRA
1 x MN6471M
KSS-152 - Magnetic
PDF
SANSUI CD-a907
2 x PCM56P-S – SM5804B
Sansui S-706HB / 18734900
PDF
SANSUI CD-E910
2 x PCM56P
-
PDF
SANSUI CD-V550
TD6709
KSS-123A
PDF
SANSUI CD-V1000
PCM56
KSS-210A
PDF
SANSUI CD-X105
YM3020 – YM3805
Sanyo
PDF
SANSUI CD-X217
MN6474M – CXD1167Q
KSS-150A / KSS-210A
PDF
SANSUI CD-X301i
LC7881 – CXD1135QZ
KSS-210A
PDF
SANSUI CD-X311
MN6471M / MN6623 – CXD1125QZ
KSS-210A
PDF
SANSUI CD-X501i
2 x PCM56P – SM5807BP
KSS-150A
PDF
SANSUI CD-X510M
LC7881 – CXD1135Q
KSS-150A / KSS-210A
PDF
SANSUI CD-X701
1 x PCM54HP-J – SM5806P
Sansui S-706HB / 18734900
PDF
SANSUI CD-X701i
2 x PCM56P-S
KSS-152A
PDF
SANSUI CD-X711
1 x MN6471M
KSS-152 - Magnetic
PDF
SANSUI CD-X901
2 x PCM56P-S – SM5804B
Sansui S-706HB / 18734900
PDF
SANSUI PC-V500
2 x TDA1540D – SAA7030
-
PDF
SANSUI PC-V1000
2 x TDA1540D – SAA7030
-
PDF
SANYO CP 489
LC7881
Sanyo SF-P1
PDF
SANYO CP 900
CX20152
Sanyo SF
PDF
SANYO CP 6150
CX20152
Sanyo SF
PDF
SANYO CP 6155
LC7880
Sanyo SF-86
PDF
SANYO CP 7150
LC7880
Sanyo SF-86
PDF
SANYO CP 8500
2 x PCM56P-L – PD0029
Sanyo SF-88
PDF
SANYO DAD 8
CX20017 / PCM51JG-V
4 180T00271 (Toshiba OPH-32)
PDF
SANYO DAD M15
2 x TDA1540D – SAA7030
Same as Toshiba OPH-32
PDF
SCHNEIDER CD 1005
2 x TDA1540P – SAA7030
CDM-2/10
PDF
SCHNEIDER CD 1104
2 x TDA1540P – SAA7030
CDM-1
PDF
SCHNEIDER CD 6200 InConcert
PCM56P
KSS-152A
PDF
SCHNEIDER CDP7402
1 x PCM56P
KSS-152A
PDF
SCHNEIDER CDP7500
CX20133 – CX23035
KSS-123A
PDF
SCHNEIDER CDP8000
PCM53JG-V
-
PDF
SEG CD200
YM3020
-
PDF
SENCOR S-334
YM3020 – YM3805
Hitachi HOP-M14
PDF
SENTEC DIANA
2 x PCM63P – DF1700P – CS8412
D/A converter
PDF
SHANLING CD-50
CS4390
CDM 12.10
PDF
SHANLING CD100
PCM1738
VAM 12
PDF
SHANLING CD300
2 x PCM1794
CDM 12.10
PDF
SHANLING CD500
4 x PCM1704U-K – SM5847
Philips CD-Pro 2 (VAM 1254)
PDF
SHANLING CD-A10T
PCM1732
CDM 12
PDF
SHANLING CD-A24
4 x PCM1704 – PMD200
CDM 12.10
PDF
SHANLING CD-S100
PCM1732
CDM 12.10
PDF
SHANLING CD-S100 Mk II
PCM1738
CDM 12.10
PDF
SHANLING CD-T80
PCM1738
CDM 12.10
PDF
SHANLING CD-T100
4 x PCM1704 – PMD200
CDM 12.10
PDF
SHANLING CD-T100SE
2 x PCM1792
VAM 1201
PDF
SHANLING CD-T150
2 x PCM1794
Philips CD-Pro 2 (VAM 1254)
PDF
SHANLING CD-T200
PCM1738 – CXD2753 SACD
Sony KHM-280AAA
PDF
SHANLING CD-T300
8 x PCM1704-K – SM5847AF
Philips CDM-4
PDF
SHANLING DAC-1
4 x PCM1704 – PMD200 – CS8420-CS
D/A converter
PDF
SHANLING HDCD-S12
PCM1732
CDM 12.10
PDF
SHANLING SCD300 SACD
PCM1792 – CXD2753
Sony KHM-280A
PDF
SHANLING SCD-S300 SACD
PCM1738
SACD
PDF
SHANLING SCD-T200 SACD
PCM1738 – CXD2753R
Sony KHM-280A
PDF
SHARP DX-A1
Sharp IR3K16AM
-
PDF
SHARP DX-112
Sharp IR3K16BM
-
PDF
SHARP DX-450
LC7880
Sharp RCTRH8108
PDF
SHARP DX-500
CX20017
Sharp RCTRH0051AF
PDF
SHARP DX-650
LC7880
Sharp RCTRH8112
PDF
SHARP DX-SX1
PCM1716
Sony
PDF
SHENG YA CD-S3
PCM1732
CDM 12
PDF
SHENG YA CD-S10
PCM1732
CDM 12
PDF
SHERWOOD CD-1
TDA1547 – SM5813 – SAA7350
CDM-9 Pro
PDF
SHERWOOD CD-772
AD1852
-
PDF
SHERWOOD CD-880
2 x AD1862
KSS-213C
PDF
SHERWOOD CD-980
2 x PCM1702-K
-
PDF
SHERWOOD CD-1060C
µPD6372CX – SM5807
KSS-210A
PDF
SHERWOOD CD-1160R
PCM56
-
PDF
SHERWOOD CD-1192R
YM4113B
-
PDF
SHERWOOD CD-3020
SM5871AN
KSS-210A
PDF
SHERWOOD CD-4010R
2 x AD1861
KSS-210A
PDF
SHERWOOD CD-4030R
SAA7350BS – YM3433
-
PDF
SHERWOOD CD-5090R
CXD2587Q
KSS-213B
PDF
SHERWOOD CD-7080R
2 x PCM1702-K
-
PDF
SHERWOOD CDC-2000C
µPD6376
-
PDF
SHERWOOD CDC-2010RC
µPD6376
-
PDF
SHERWOOD CDP300R
2 x TDA1540P – SAA7030
CDM-2
PDF
SHERWOOD CDP301R
TDA1541 – SAA7220P/A
CDM-2
PDF
SHERWOOD CDP310R
2 x TDA1540P – SAA7030
CDM-2
PDF
SIEMENS RW 725
CX20017 / PCM51JG-V
4 180T00271 (Toshiba OPH-32)
PDF
SIEMENS RW 726
YM3015
-
PDF
SIGTONE SHEK D1
TDA1543A – CS8412-IS
D/A converter
PDF
SIGTONE SHEK D2
TDA1545A – CS8412-IS
D/A converter
PDF
SIMAUDIO MOON ANDROMEDA
PCM1704U-K – DF1704
Philips CD-Pro 2 (VAM 1254)
PDF
SIMAUDIO MOON ECLIPSE
4 x PCM1704-K – DF1704 - PMD100
Philips CD-Pro 2 (VAM 1254)
PDF
SIMAUDIO MOON EQUINOX
PCM1730E
Philips L1210
PDF
SIMAUDIO MOON NOVA
2 x PCM1704-J – DF1704
Philips CD-Pro (VAM 1252)
PDF
SIMAUDIO MOON SUPERNOVA
PCM1798
Philips
PDF
SONIC FRONTIERS ANTHEM
2 x PCM1702 – PMD100
KSK-2000A
PDF
SONIC FRONTIERS Processor 3
2 x UltraAnalog D20400A – PMD100
D/A converter
PDF
SONIC FRONTIERS SFCD-1
UltraAnalog D20400A – PMD100
CDM 12.4
PDF
SONIC FRONTIERS SFD-1
UltraAnalog D20400A – SM5803APT
D/A converter
PDF
SONIC FRONTIERS SFD-1 Mk II
UltraAnalog D20400A – PMD100
D/A converter
PDF
SONIC FRONTIERS SFD-2
2 x UltraAnalog D20400A – SM5803AP
D/A converter
PDF
SONIC FRONTIERS SFD-2 Mk II
2 x UltraAnalog D20400A – PMD100
D/A converter
PDF
SONIC FRONTIERS Transdac
2 x PCM1702-J – DF1700P
D/A converter
PDF
SONIC FRONTIERS Transport 1
Transport
CDM 12 Ind
PDF
SONIC FRONTIERS Transport 3
Transport
Philips CD-Pro (VAM 1252)
PDF
SONNETEER BYRON
AKM2496 – CS8412-CP
CDM 12.1
PDF
SONY CDP-25
PCM54HP
KSS-120C
PDF
SONY CDP-35
PCM54HP
KSS-120C
PDF
SONY CDP-38
LC7880
KSS-150A
PDF
SONY CDP-40
1 x PCM54HP-J – CX23035
KSS-121A / KSS-123A
PDF
SONY CDP-45
PCM54HP
KSS-121A
PDF
SONY CDP-48
LC7880
KSS-150A
PDF
SONY CDP-50
PCM54HP-J
KSS-123
PDF
SONY CDP-55
PCM54HP-J
KSS-121A / KSS-123A
PDF
SONY CDP-65
PCM54HP-J
KSS-121A / KSS-123A
PDF
SONY CDP-68
1 x TDA1541 – CXD1088
KSS-150A
PDF
SONY CDP-70
CX20017
KSS-122A
PDF
SONY CDP-101
CX20017
KSS-100A
PDF
SONY CDP-102
CX20152
Sony BU-1
PDF
SONY CDP-103
CX20152 – CX23034
Sony BU-1C
PDF
SONY CDP-111
CX20017
KSS-100A
PDF
SONY CDP-195
CXD2552AQ – CXD2554P
KSS-240A
PDF
SONY CDP-203ES
CX20152 – CX23034
KSS-123A
PDF
SONY CDP-205ESD
PCM56P-J – CX23034
KSS-150A
PDF
SONY CDP-207ESD
1 x TDA1541 – CXD1088
KSS-150A
PDF
SONY CDP-208ESD
PCM56P
KSS-150A
PDF
SONY CDP-209ES
CXD2552Q – CXD2551P
KSS-240A
PDF
SONY CDP-211
CXD2565M – CXD2515Q
KSS-240A
PDF
SONY CDP-222ES
2 x PCM56P-J – CX23034
KSS-151A
PDF
SONY CDP-222ESD
1 x TDA1541 – CXD1088
KSS-151A
PDF
SONY CDP-227ESD (Old ver.)
1 x TDA1541 – CXD1088
KSS-151A
PDF
SONY CDP-227ESD (New ver.)
2 x TDA1541A-R1 – CXD1144
KSS-151A
PDF
SONY CDP-228ESD
2 x PCM58P-J – CXD1244
KSS-151A
PDF
SONY CDP-255
LC7880
KSS-150A
PDF
SONY CDP-270
LC7881
KSS-210A
PDF
SONY CDP-291
TDA1543A – CXD2554M
KSS-240A
PDF
SONY CDP-295
CXD2552AQ – CXD2554P
KSS-240A
PDF
SONY CDP-297
CXD2561BM C-Pulse – CXD2560M
KSS-240A
PDF
SONY CDP-301V
TDA1541 – CXD1088
KSS-210A
PDF
SONY CDP-302ES
CX20152 – CX23034
Sony BU-1
PDF
SONY CDP-303ES
CX20152 – CX23034
Sony BU-1C
PDF
SONY CDP-303ESII
CX20152
Sony BU-1C
PDF
SONY CDP-307ESD
1 x TDA1541A – CXD1088A
KSS-150A
PDF
SONY CDP-308ESD
PCM58P – CXD1244
KSS-210A
PDF
SONY CDP-311
CXD2565M – CXD2515Q
KSS-240A
PDF
SONY CDP-313
CXD2565M
KSS-213B / KSS-240A
PDF
SONY CDP-315
CXD2565M
KSS-240A
PDF
SONY CDP-333ES
CXD2562
KSS-240A
PDF
SONY CDP-333ESA
1 x CXD2562Q – CXD2560M
KSS-272A
PDF
SONY CDP-333ESD
1 x TDA1541 – CXD1088
Sony BU-1E
PDF
SONY CDP-333ESJ
1 x CXD2562Q – CXD2567M
KSS-272A
PDF
SONY CDP-337ESD
2 x TDA1541A – CXD1144
KSS-190A
PDF
SONY CDP-338ESD
2 x PCM58P-J – CXD1244
KSS-151A
PDF
SONY CDP-361
CXD2565
KSS-240A
PDF
SONY CDP-390
TDA1543A – CXD2551
KSS-210A
PDF
SONY CDP-391
TDA1543A – CXD2554M
KSS-240A
PDF
SONY CDP-395
CXD2552Q – CXD1244
KSS-240A
PDF
SONY CDP-397
CXD2561BM C-Pulse – CXD2560M
KSS-240A
PDF
SONY CDP-400
CX20017
KSS-100A
PDF
SONY CDP-411
CXD2565M – CXD2515Q
KSS-240A
PDF
SONY CDP-470
CXD1161P – CXD2550
KSS-210A
PDF
SONY CDP-490
2 x PCM56P
KSS-210A
PDF
SONY CDP-491
CXD2552AQ – CXD2554P
KSS-240A
PDF
SONY CDP-497
CXD2561BM C-Pulse – CXD2560M
KSS-240A
PDF
SONY CDP-501ES
CX20017
KSS-100A
PDF
SONY CDP-502ES
CX20152 – CX23034
Sony BU-1
PDF
SONY CDP-502ES II
2 x PCM53JP-V-K
Sony BU-1C
PDF
SONY CDP-505ESD
1 x TDA1541 – CXD1088
KSS-151A
PDF
SONY CDP-507ESD
2 x TDA1541A-R1 – CXD1144
KSS-151A
PDF
SONY CDP-508ESD
2 x PCM58P-1 – CXD1244
KSS-151A
PDF
SONY CDP-510
PCM56P
KSS-210A
PDF
SONY CDP-511
CXD2565M – CXD2515Q
KSS-240A
PDF
SONY CDP-520ES
CX20152
Sony BU-1
PDF
SONY CDP-552ESD
CX20152 – CX23034
Sony BU-1
PDF
SONY CDP-552ESD II
2 x PCM53JP-V-K – CX23034
Sony BU-1C
PDF
SONY CDP-553ESD
2 x PCM53JP-V-K – CX23034
Sony BU-1C
PDF
SONY CDP-555ESA
1 x CXD2562Q – CXD2560M
KSS-272A
PDF
SONY CDP-555ESD
1 x TDA1541A – CXD1088Q
Sony BU-1E
PDF
SONY CDP-555ESJ
1 x CXD2562Q – CXD2567M
KSS-272A
PDF
SONY CDP-557ESD
2 x PCM64P – CXD1144
KSS-190A
PDF
SONY CDP-561
CXD8505Q
KSS-213B
PDF
SONY CDP-590
2 x PCM56P – CXD2554P
KSS-210A
PDF
SONY CDP-591
CXD2552AQ – CXD1244
KSS-240A
PDF
SONY CDP-597
CXD2561AM C-Pulse – CXD2560M
KSS-240A
PDF
SONY CDP-605ESD
TDA1541 – CXD1088
Sony BU-1E
PDF
SONY CDP-608ESD
2 x PCM58P-J – CXD1244
KSS-151A
PDF
SONY CDP-610ES
CX20017
KSS-100A
PDF
SONY CDP-620ES
CX20152 – CX23034
Sony BU-1
PDF
SONY CDP-620ES II
2 x PCM53JP-V-K
Sony BU-1C
PDF
SONY CDP-650ESD
PCM53JP / CX20152– CX23034
Sony BU-1
PDF
SONY CDP-650ESD II
2 x PCM53JP-V-K – CX23034
Sony BU-1C
PDF
SONY CDP-670
2 x PCM56P – CXD2550
KSS-210A
PDF
SONY CDP-690 (Old ver.)
2 x AD1860N – CXD2551
KSS-240A
PDF
SONY CDP-690 (New ver.)
1 x CXD2552Q – CXD2554P
KSS-240A
PDF
SONY CDP-701ES
2 x CX890 / CX20017
KSC-100A (Toshiba OPH-31)
PDF
SONY CDP-705ESD
1 x TDA1541A – CXD1088Q
Sony BU-1E
PDF
SONY CDP-707ESD
2 x PCM64P – CXD1144
KSS-190A
PDF
SONY CDP-710
1 x TDA1541 – CXD1088
KSS-150A / KSS-210A
PDF
SONY CDP-750
1 x TDA1541 – CXD1088
KSS-210A
PDF
SONY CDP-770
2 x PCM56P – CXD2550
KSS-210A
PDF
SONY CDP-771
CXD2552Q – CXD1244
KSS-240A
PDF
SONY CDP-777ESA
2 x CXD2562Q – CXD2560M
KSS-272A
PDF
SONY CDP-777ESJ
2 x CXD2562Q
KSS-272A
PDF
SONY CDP-790 (Old ver.)
2 x AD1860N-T – CXD2551P
KSS-240A
PDF
SONY CDP-790 (New ver.)
1 x CXD2552Q – CXD2551P
KSS-240A
PDF
SONY CDP-791
CXD2552Q – CXD1244
KSS-240A
PDF
SONY CDP-797
CXD2561AM-1 C-Pulse – CXD2560M
KSS-240A
PDF
SONY CDP-910
1 x TDA1541 – CXD1088
KSS-151A
PDF
SONY CDP-911
CXD2562Q – CXD2567M
KSS-240A
PDF
SONY CDP-915
CXD2562Q
KSS-240A
PDF
SONY CDP-950
1 x TDA1541A – CXD1088A
KSS-150A / KSS-210A
PDF
SONY CDP-970
2 x PCM58P-1 – CXD1244
KSS-210A
PDF
SONY CDP-990 (Old ver.)
4 x AD1860N-K – CXD1244
KSS-240A
PDF
SONY CDP-990 (New ver.)
1 x CXD2552Q-3 – CXD1244
KSS-240A
PDF
SONY CDP-991
CXD2552Q – CXD1244
KSS-240A
PDF
SONY CDP-2700
2 x AD1860N – CXD1244
KSS-240A
PDF
SONY CDP-C5M
1 x PCM56P
KSS-210A
PDF
SONY CDP-C100
TDA1541A
KSS-210A
PDF
SONY CDP-CA70ES
CXD8505BQ + CXA8055M
KSS-213B
PDF
SONY CDP-CA80ES
CXD8505BQ + CXA8055M
KSS-213B
PDF
SONY CDP-CE315
CXD8567AM
KSS-213B
PDF
SONY CDP-CE515
CXD8567AM – CXD2545Q
KSS-213BA
PDF
SONY CDP-D500
2 x PCM1702-J – SM5843
KSS-213B
PDF
SONY CDP-M7
PCM1710U
KSS-213B
PDF
SONY CDP-M11
CXD2552 – CXD2554 (filter)
KSS-240A
PDF
SONY CDP-M12
TDA1543
KSS-210A / KSS-240A
PDF
SONY CDP-M18
TDA1543A – CXD2554P
KSS-240A
PDF
SONY CDP-M20
1 x PCM56P – CXD1135Q
KSS-150A
PDF
SONY CDP-M25
LC7881
KSS-150A
PDF
SONY CDP-M30
1 x PCM56P – CXD1135Q
KSS-150A
PDF
SONY CDP-M31
CXD2552
KSS-240A
PDF
SONY CDP-M35
CXD1161 – CXD1162
KSS-150A
PDF
SONY CDP-M46
CXD2565M – CXD2515Q
KSS-240A
PDF
SONY CDP-M49
2 x PCM56P
KSS-210A
PDF
SONY CDP-M51
CXD2552Q
KSS-240A
PDF
SONY CDP-M69
2 x PCM56P
KSS-240A
PDF
SONY CDP-M70
PCM56P – CXD1088
KSS-210A
PDF
SONY CDP-M75
TDA1541 – CXD1088
KSS-210A
PDF
SONY CDP-M77
PCM56P – CXD2550P
KSS-150A
PDF
SONY CDP-M79
2 x AD1860N – CXD2551P
KSS-240A
PDF
SONY CDP-M95
TDA1541 – CXD1088
KSS-150A / KSS-210A
PDF
SONY CDP-M97
PCM56P – CXD2550P
KSS-150A
PDF
SONY CDP-MS1
CXD8594 + CXA8042AS
KSS-274A / KSS-240A
PDF
SONY CDP-R1
Transport – CXD1125
KSS-190A
PDF
SONY DAS-R1
2 x TDA1541A-S1 – CXD1144
D/A converter
PDF
SONY CDP-R1A
Transport
KSS-151A
PDF
SONY DAS-R1A
2 x CXD2552Q - CXD1244 - CXD2900
D/A converter
PDF
SONY CDP-R3
2 x CXD2552Q
KSS-151A
PDF
SONY CDP-X7ESD
2 x PCM58P-S – CXD1244
KSS-190A
PDF
SONY CDP-X33ES
1 x CXD2552Q – CXD1244
KSS-270A / KSS-151A
PDF
SONY CDP-X55ES
CXD2552Q – CXD1244
KSS-270A / KSS-151A
PDF
SONY CDP-X77ES
2 x CXD2552Q-1 – CXD1244
KSS-280A
PDF
SONY CDP-X111ES
CXD2552Q – CXD1244
KSS-240A
PDF
SONY CDP-X202ES
CXD2562Q – CXD2567M
KSS-240A
PDF
SONY CDP-X222ES
2 x CXD2552Q-3 – CXD1244
KSS-240A
PDF
SONY CDP-X229ES
CXD2562Q
KSS-240A
PDF
SONY CDP-X303ES
1 x CXD2562Q – CXD2567M
KSS-272A
PDF
SONY CDP-X333ES
2 x CXD2552Q-2 – CXD1244
KSS-271A
PDF
SONY CDP-X339ES
1 x CXD2562Q – CXD2560M
KSS-272A
PDF
SONY CDP-X505ES
1 x CXD2562Q – CXD2567M
KSS-272A
PDF
SONY CDP-X555ES
2 x CXD2552Q-2 – CXD1244
KSS-271A
PDF
SONY CDP-X559ES
1 x CXD2562Q – CXD2560M
KSS-272A
PDF
SONY CDP-X707ES
2 x CXD2562Q
KSS-272A
PDF
SONY CDP-X777ES
2 x CXD2552BQ – CXD1244
KSS-281A
PDF
SONY CDP-X779ES
2 x CXD2562Q – CXD2560M
KSS-272A
PDF
SONY CDP-X900
CXA8042
KSS-313A
PDF
SONY CDP-X3000
CXD2562Q + 2 x CXA8042AS
Fixed Pick-Up KSS-213B
PDF
SONY CDP-X5000
CXD2562Q + 2 x CXA8042AS
Fixed Pick-Up KSS-274A
PDF
SONY CDP-XA1ES
CXD8505Q – CXD2515Q
KSS-240A
PDF
SONY CDP-XA2ES
CXD2562Q + 2 x CXA8042S
KSS-213B
PDF
SONY CDP-XA3ES
CXD2562Q + 2 x CXA8042S
KSS-240A
PDF
SONY CDP-XA5ES
CXD2562Q + 2 x CXA8042S
Fixed Pick-Up KSS-273A
PDF
SONY CDP-XA7ES
CXD2562Q + 2 x CXA8042AS
Fixed Pick-Up KSS-273A
PDF
SONY CDP-XA20ES
CXD8505BQ + 2 x CXA8042AS
KSS-213B
PDF
SONY CDP-XA30ES
CXD2562Q + 2 x CXA8042AS
Fixed Pick-Up KSS-213B
PDF
SONY CDP-XA50ES
CXD2562Q + 2 x CXA8042AS
Fixed Pick-Up KSS-273A / B
PDF
SONY CDP-XA55ES
CXD8594Q + CXA8042S - CXD8762Q
Fixed Pick-Up KSS-273B
PDF
SONY CDP-XA555ES
CXD8762Q - CXD9521Q - CXA8042AS
Fixed Pick-Up KSS-273B
PDF
SONY CDP-XB630
CXD8567AM – CXA2568M
KSS-213BA
PDF
SONY CDP-XB720E
CXD8735N – CXA2568M
KSS-213BA
PDF
SONY CDP-XB740E
CXD9556Q – CXD2585Q
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XB820
CXD8735N – CXA2568M
KSS-213B
PDF
SONY CDP-XB920
CXD8735N + CXA8055M
-
PDF
SONY CDP-XB930
CXD8735N - CXA8055M - CXA2568
Fixed Pick-Up KSS-213BA
PDF
SONY CDP-XE200
CXD8567AM – CXD2545Q
Sony CDM14 – KSS-213B
PDF
SONY CDP-XE220
CXD2529Q – CXA1992AR
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XE270
CXD2587Q – CXA2581N
KSS-213C
PDF
SONY CDP-XE300
CXD8567AM – CXD2545Q
Sony CDM14 – KSS-213B
PDF
SONY CDP-XE310
CXD8567
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XE320
CXD2529Q – CXA1992AR
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XE330
CXD2529Q
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XE370
CXD2587Q – CXA2581N
PXR-104X / KSS-213C
PDF
SONY CDP-XE500
CXD8567AM – CXD2545Q
Sony CDM14 – KSS-213B
PDF
SONY CDP-XE520
CXD8567AM – CXD2585Q
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XE530
CXD8567AM – CXD2585Q
Sony CDM14 – KSS-213BA
PDF
SONY CDP-XE570
CXD2587Q – CXA2581N
PXR-104X (1-796-033-11)
PDF
SONY CDP-XE700
CXD8567AM – CXD2545Q
Fixed Pick-Up – KSS-213B
PDF
SONY CDP-XE800
CXD8505BQ
Fixed Pick-Up – KSS-213B
PDF
SONY CDP-XE900
CXD8505BQ + CXA8055M
Fixed Pick-Up – KSS-213B
PDF
SONY DAS-702ES
2 x PCM53
D/A converter
PDF
SONY DAS-703ES
2 x PCM53JP-I-K – CXD1058
D/A converter
PDF
SONY SCD-XB790
CXD9709Q
-
PDF
SOUNDSTREAM DAC-1
1 x PCM67P – DF1700P – YM3623B
D/A converter
PDF
SOUNDWAVE CD1100
LC7881
-
PDF
SPECTRAL SDR-1000
2 x TDA1541A-S1 (Single Crown)
CDM-1
PDF
SPECTRAL SDR-2000
2 x UltraAnalog D20400A – PMD100
D/A converter
PDF
SPECTRAL SDR-3000
Transport
VRDS CMK-2 – KSS-151A
PDF
SPECTRAL SDR-4000
2 x AD1853 – PMD100
TEAC VRDS
PDF
SPHINX MYTH 9
TDA1305
CDM 12
PDF
SPHINX PROJECT 32
4 x PCM1704 – PMD100
CDM 12.4
PDF
STAX CDP QUATTRO
PCM54HP
MLP-3C
PDF
STAX CDP QUATTRO II
PCM56P – YM3414
-
PDF
STAX DAC-TALENT
2 x PCM63P – SM5803
D/A converter
PDF
STAX DAC-TALENT BD
4 x PCM1702 – SM5843 – YM3623B
D/A converter
PDF
STAX DAC-X1T
2 x UltraAnalog D20400 – SM5803
D/A converter
PDF
STUDER A725
2 x TDA1540 – SAA7030
CDM-0 / CDM-1
PDF
STUDER A727
TDA1541A-S1 (Single Crown)
CDM-1
PDF
STUDER A730
TDA1541A-S1 (Double Crown)
CDM-3
PDF
STUDER D730
TDA1547 (DAC7) – SM5813APT
CDM-4/36 Pro Metallic
PDF
STUDER D731
TDA1547 (DAC7) – SM5813APT
CDM-4/36 Pro Metallic
PDF
STUDER D732
TDA1305T
CDM-4 Pro
PDF
SUGDEN CD21SE
TDA1547 (DAC7)
-
PDF
SUGDEN CDT1
TDA1541
-
PDF
SUGDEN MASTER
TDA1549
CDM 12.1
PDF
SUGDEN MASTERCLASS
TDA1541A-S1-Crown – SAA7220P/B
CDM 12.1
PDF
SUGDEN OPTIMA
TDA1543
-
PDF
SUGDEN SDA-1
TDA1541A-S1 (Single Crown)
D/A converter
PDF
SUGDEN SDT-1
TDA1541A-S1 (Single Crown)
CDM-9/44
PDF
SYLVANIA CD1460
TDA1541
CDM-2
PDF
SYLVANIA CD1473
TDA1541 – SAA7220P/A
CDM-2
PDF
SYLVANIA FDC303
2 x TDA1540D – SAA7030
CDM-0
PDF
SYLVANIA FDD304
2 x TDA1540P – SAA7030
CDM-1

T | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
T+A CD1000 AC
TDA1541 – SAA7220P/A
CDM-2/29
PDF
T+A CD1200R
TDA1547
CDM-9
PDF
T+A CD1210R
SM5864AP
CDM 12.3
PDF
T+A CD1220R
2 x SM5864AP + 2 x PCM63P-K
CDM 12.4
PDF
T+A CD1230R
2 x AD1853
VAM 1250
PDF
T+A CD1240R
2 x SM5864AP + 2 x PCM63P-K
VAM 1250
PDF
T+A CD1400AC
SM5864
CDM-9 Pro
PDF
T+A CD1500R
SM5864AP + PCM1702-K
CDM-9
PDF
T+A CD3000R
SM5864AP + PCM1702-K
CDM-9
PDF
TAG McLAREN CD20R
CS4329
CDM 12.4
PDF
TAG McLAREN F3 CDT20
Transport
CDM 12.4
PDF
Talk Electronics Thunder 2
CS4390
Sony CDM14 (KSS-213BA)
PDF
Talk Electronics Thunder 3
CS4390
Sony CDM14 (KSS-213BA)
PDF
TANDBERG TCP 3015A
2 x TDA1540P – SAA7030
CDM-2
PDF
TANDBERG TCP 3015A 16 bit
TDA1541 – SAA7220
CDM-2
PDF
TASCAM CD-201
MN6474
KSS-210A
PDF
TASCAM CD-301
MN6474M
KSS-210A
PDF
TASCAM CD-401
2 x PCM54HP
KSS-151A
PDF
TASCAM CD-401 Mk II
SAA7350AGP – SM5840AP
KSS-151A
PDF
TASCAM CD-501
2 x PCM53JP-V – CX23034
MLP-3C
PDF
TASCAM CD-701
2 x PCM54HP – CXD1162
VRDS CMK-3 – KSS-151A
PDF
TEAC C-1D
PCM1710U
-
PDF
TEAC CD-5
SAA7350 – SM5840AP
KSS-210A
PDF
TEAC CD-P1440R
µPD63711
Sanyo SF-P101
PDF
TEAC CD-P1450
µPD63711
Sanyo SF-P101
PDF
TEAC CD-P1820
PCM1710
-
PDF
TEAC CD-P3000
MN6474M
KSS-150A / KSS-210A
PDF
TEAC CD-P3500
SAA7350
KSS-210A
PDF
TEAC CD-P4500
SAA7350GP – SM5840AP
KSS-210A
PDF
TEAC CD-Z500
2 x TDA1541A – PD0050
KSS-150A
PDF
TEAC CD-Z5000
2 x TDA1541A – PD0050
KSS-210A
PDF
TEAC CPD3450SE
YDC103
-
PDF
TEAC D-1 ESOTERIC
2 x PCM64P
D/A converter
PDF
TEAC P-1 ESOTERIC
Transport
VRDS CMK-4 – KSS-151A
PDF
TEAC D-01 ESOTERIC
8 x PCM1704
D/A converter
PDF
TEAC P-01 ESOTERIC
Transport
VRDS-NEO
PDF
TEAC D-2 ESOTERIC
4 x PCM1701P-K
D/A converter
PDF
TEAC P-2 ESOTERIC
Transport
VRDS CMK-3 – KSS-151A
PDF
TEAC D-3 ESOTERIC
8 x AD1862N-J – SM5843AP
D/A converter
PDF
TEAC D-03 ESOTERIC
8 x AD1955
D/A converter
PDF
TEAC P-03 ESOTERIC
Transport
VRDS-NEO
PDF
TEAC D-70 ESOTERIC
4 x PCM1704
D/A converter
PDF
TEAC P-70 ESOTERIC
Transport – CXD2545Q
VRDS CMK-3-S – KSS-151A
PDF
TEAC D-500
2 x TDA1541A-S1 – SM5813
D/A converter
PDF
TEAC P-500
Transport
VRDS CMK-4 – KSS-151A
PDF
TEAC D-700
4 x AD1862N – SM5813APT
D/A converter
PDF
TEAC P-700
Transport
VRDS CMK-3 – KSS-151A
PDF
TEAC D-T1
2 x TDA1547 (DAC7) + 2 x SAA7350
D/A converter
PDF
TEAC P-2S ESOTERIC
Transport – CXD1125
VRDS CMK-2 – KSS-151A
PDF
TEAC P-30 ESOTERIC
Transport – CXD2500AQ
VRDS CMK-3 – KSS-151A
PDF
TEAC PD-155mk2
Y3015
-
PDF
TEAC PD-160
TC9218F
9A0102660
PDF
TEAC PD-175
Y3015
-
PDF
TEAC PD-365
LC7881 – YM7121B
Sanyo SF-90
PDF
TEAC PD-435
LC97000
Sanyo SF-90
PDF
TEAC PD-H300C
TC9462F
KSS-213
PDF
TEAC PD-H500C
PCM69AP – SM5841AP
KSS-213
PDF
TEAC S-Z1 ESOTERIC
CS4398
VRDS-NEO
PDF
TEAC VRDS-7
2 x SAA7350GP – SM5840AP
VRDS CMK-4 – KSS-240A
PDF
TEAC VRDS-8
4 x PCM1702 – SM5843AP
VRDS CMK-4.5
PDF
TEAC VRDS-9
4 x PCM1702 – SM5840
VRDS CMK-4.2
PDF
TEAC VRDS-10
2 x TDA1547 – SAA7350 – SM5840AP
VRDS CMK-3.2 – KSS-151A
PDF
TEAC VRDS-10SE
2 x TDA1547 + 2 x SAA7350 - SM5840
VRDS CMK-3.2 – KSS-151A
PDF
TEAC VRDS-20
2 x TDA1547 – SAA7350 – SM5840
VRDS CMK-3 – KSS-151A
PDF
TEAC VRDS-25
4 x AD1862N-J - SM5843 - CXD2545
VRDS CMK-3 – KSS-151A
PDF
TEAC VRDS-25X / XS
4 x AD1862N-J - SM5843 - CXD2545
VRDS CMK-3.2 – KSS-151A
PDF
TEAC VRDS-50
NSdap FN1241
VRDS CMK-3.2 – KSS-151A
PDF
TEAC VRDS-T1
Transport
VRDS CMK-4 – KSS-240A
PDF
TEAC X-1 ESOTERIC
4 x AD1862N-J – SM5813AP
VRDS CMK-3 – KSS-151A
PDF
TEAC X-1S ESOTERIC
4 x AD1862N-J – SM5813APT
VRDS CMK-2 – KSS-151A
PDF
TEAC X-01 ESOTERIC
8 x PCM1704 – SM5847AF
VRDS-NEO
PDF
TEAC X-03 ESOTERIC
4 x PCM1704
VRDS-NEO
PDF
TEAC ZD-700
1 x PCM53
-
PDF
TEAC ZD-880
2 x PCM54HP
-
PDF
TEAC ZD-900
2 x PCM54HP
KSS-151A
PDF
TEAC ZD-3000
2 x PCM53JP-V – CX23034
MLP-3C
PDF
TEAC ZD-4000
2 x PCM53JP-V – CX23034
MLP-3C
PDF
TEAC ZD-5000
2 x PCM53
-
PDF
TEAC ZD-6000
2 x PCM53JP-V – CX23034
MLP-3C
PDF
TEAC ZD-7000
2 x PCM64P
MLP-3C
PDF
TECHNICS SL-P1
PCM53JP-V
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-P2
PCM53JP-V
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-P3
PCM53JP-V
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-P7
AN6806 (Matsushita 16 Bit)
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-P8
AN6806 (Matsushita 16 Bit)
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-P10
AN6806 (Matsushita 16 Bit)
Technics SRUD010N01Z
PDF
TECHNICS SL-P50
2 x AN6806 / 2 x PCM53JP-V
Technics SRLP007N04A
PDF
TECHNICS SL-P75
AN6806 (Matsushita 16 Bit)
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-P100
1 x PCM54HP
SZZP1084 / SOAD20A
PDF
TECHNICS SL-P110
PCM54HP – MN6618A (filter)
SOALP1200
PDF
TECHNICS SL-P111
PCM55HP
SOALP1200 KM3
PDF
TECHNICS SL-P115
PCM54HP – MN6618A (filter)
SOALP1200
PDF
TECHNICS SL-P120
PCM54HP
SOALP1200
PDF
TECHNICS SL-P170
MN6474 – MN6625
SOAD70A
PDF
TECHNICS SL-P202A
MN6471 – MN6625
CDM-4/19
PDF
TECHNICS SL-P210
1 x PCM54HP
SOALP1200
PDF
TECHNICS SL-P212A
MN6471
CDM-4/19
PDF
TECHNICS SL-P220
1 x PCM54HP
SOALP320 / SOAD32A
PDF
TECHNICS SL-P272A
MN6474
CDM-4/19
PDF
TECHNICS SL-P277A
MN6474 – MN6625
CDM-4/19
PDF
TECHNICS SL-P300
1 x PCM54HP
SZZP1084 / SOAD20A
PDF
TECHNICS SL-P310
1 x PCM54HP
SOALP1200
PDF
TECHNICS SL-P320
1 x PCM54HP-J
SOALP320 / SOAD32A
PDF
TECHNICS SL-P333
MN6623 MASH – MN6625
SOAD70A
PDF
TECHNICS SL-P350
2 x PCM56P-J – YM3404
SOAD60A
PDF
TECHNICS SL-P370
MN6474 – MN6625
SOAD70A
PDF
TECHNICS SL-P377A
MN6474 – MN6625
CDM-4/19
PDF
TECHNICS SL-P500
1 x PCM54HP-K
SZZP1084 / SOAD20A
PDF
TECHNICS SL-P520
1 x PCM54HP-J – MN6618A (filter)
SOALP1200
PDF
TECHNICS SL-P550
2 x PCM56P-J – YM3404
SOAD60A
PDF
TECHNICS SL-P555
MN6471 – MN6625
SOAD70A
PDF
TECHNICS SL-P720
PCM54HP-K – MN6618A (filter)
SOALP1200
PDF
TECHNICS SL-P770
2 x PCM56P-J + 2 x PCM56P – YM3404
SOAD60A
PDF
TECHNICS SL-P777
MN6471 – MN6622
SOAD70A
PDF
TECHNICS SL-P990
4 x PCM56P-J – YM3404
SOAD60A
PDF
TECHNICS SL-P999
4 x PCM56P-J – SM5813AP
SOAD70A
PDF
TECHNICS SL-P1000
2 x PCM54HP-M – MN51005PDN
SOALP320 / SOAD32A
PDF
TECHNICS SL-P1200
2 x PCM54HP-M – MN51005PON
SOALP1200
PDF
TECHNICS SL-P1300
4 x PCM56P-K + 2 x MB671431
SOALP1200
PDF
TECHNICS SL-P2000
2 x MN64731 + MASH MN64732
SOAD70A
PDF
TECHNICS SL-PA10
Transport
SOAD70A
PDF
TECHNICS SL-PD687
MN66271RA
RAE0150Z (Panasonic)
PDF
TECHNICS SL-PD887
MN662741RH
Panasonic
PDF
TECHNICS SL-PD987
MN662712RA
Panasonic
PDF
TECHNICS SL-PG3
MN662790RSC
Panasonic
PDF
TECHNICS SL-PG4
MN662790RSC
Panasonic
PDF
TECHNICS SL-PG5
MN662790RSC
Panasonic
PDF
TECHNICS SL-PG350
MN662746
Panasonic RAE0150Z
PDF
TECHNICS SL-PG360A
MN662713RG1
CDM 12.1
PDF
TECHNICS SL-PG380A
MN662713
CDM 12.1/15
PDF
TECHNICS SL-PG400A
MN6474
CDM-4/19
PDF
TECHNICS SL-PG440A
MN6474
CDM-4/19
PDF
TECHNICS SL-PG450
MN662746
Panasonic RAE0150Z
PDF
TECHNICS SL-PG460A
MN662713RG1
CDM 12.1/05
PDF
TECHNICS SL-PG480A
MN662713
CDM 12.1/15
PDF
TECHNICS SL-PG490
MN662713RG1
RAE1100Z / CDM 12
PDF
TECHNICS SL-PG500A
MN6474
CDM-4/19
PDF
TECHNICS SL-PG520A
MN6474 – MN6626
CDM-4/19
PDF
TECHNICS SL-PG540A
MN6474
CDM-4/19
PDF
TECHNICS SL-PG580A
MN662713
CDM 12.1/15
PDF
TECHNICS SL-PJ1
1 x PCM53JP-V
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-PJ2
1 x PCM53JP-V
SRLP007N01A / SRLP007N03A
PDF
TECHNICS SL-PJ11
PCM54HP-J
SZZP1084 / SOAD20A
PDF
TECHNICS SL-PJ28A
MN6477
CDM-4/19
PDF
TECHNICS SL-PJ33
PCM54HP-K
SZZP1084 / SOAD20A
PDF
TECHNICS SL-PS7
MN64735 MASH
CDM 12
PDF
TECHNICS SL-PS30
MN6474
SOAD70A
PDF
TECHNICS SL-PS50
MN6474
SOAD70A
PDF
TECHNICS SL-PS70
MN6472 MASH – MN6625
SOAD70A
PDF
TECHNICS SL-PS670D
MN6474
CDM 12.1
PDF
TECHNICS SL-PS700
MN6474
SOAD70A
PDF
TECHNICS SL-PS770A
MN64733 + 2 x AN96A08SE2
CDM 12.1
PDF
TECHNICS SL-PS770D
MN64733-D + 2 x AN96A08S
CDM 12.1/15 (VAM 1202/12)
PDF
TECHNICS SL-PS840
MN64761 MASH
SOAD70A
PDF
TECHNICS SL-PS860
2 x AN96A08S
SOAD70A
PDF
TECHNICS SL-PS900
MN6476 MASH
SOAD70A
PDF
TECHNICS SL-X840
PCM54HP
-
PDF
TECHNICS SL-X845
PCM56P
-
PDF
TECHNICS SL-X970
PCM55HP
SOALP1200 KM3
PDF
TECHNICS SL-Z1000
Transport
SOAD70A - Metallic
PDF
TECHNICS SH-X1000
2 x MN64731 D + PCM56P-J – MN64730
D/A converter
PDF
TELEFUNKEN CD500
TD6720N
KSS-210A
PDF
TELEFUNKEN DP1000
2 x PCM58P
KSS-210A
PDF
TELEFUNKEN HS 685
TD6720N
KSS-210A
PDF
TELEFUNKEN HS 695
2 x PCM56P – YM3433
KSS-210A
PDF
TELEFUNKEN HS 810 (ver. 1)
1 x PCM56P
KSS-123A ?
PDF
TELEFUNKEN HS 810 (ver. 2)
TD6720N
KSS-150A
PDF
TELEFUNKEN HS 820
TD6720N
KSS-210A
PDF
TELEFUNKEN HS 885
TD6720N
KSS-150B / KSS-210B
PDF
TELEFUNKEN HS 895
2 x PCM56P – YM3433
KSS-210A
PDF
TELEFUNKEN HS 950
PCM53JG-V – TM5001 (HD61902H)
Hitachi (DA-1000)
PDF
TENSAI TAD-2000
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)
PDF
TESLA MC 900
2 x TDA1540P – SAA7030
CDM-1
PDF
TESLA MC 901
2 x TDA1540P – SAA7030
CDM-2/10
PDF
TESLA MC 902
TDA1541 – SAA7220P/A
CDM-2/29
PDF
TESLA MC 911
TDA1541A – SAA7220P/B
CDM-4/25
PDF
THETA CHROMA 396 DAC
1 x PCM67P-K – CXD1244 / PMD100
D/A converter
PDF
THETA COBALT 307 DAC
1 x PCM67P-K – CXD1244 – CS8412-CP
D/A converter
PDF
THETA DATA BASIC
Transport
CDM-9/44
PDF
THETA DATA BASIC II
Transport
CDM-9 Pro
PDF
THETA DATA UNIVERSAL
Transport – SAA7310GP
Sony KHS-130A
PDF
THETA DS PRO BASIC
2 x AD1860 / PCM61P-K - Motorola 56001
D/A converter
PDF
THETA DS PRO BASIC II
2 x PCM67P + 2 x Motorola 56001
D/A converter
PDF
THETA DS PRO BASIC III
4 x PCM1702-K + 2 x Motorola 56001
D/A converter
PDF
THETA DS PRO GENERATION II
2 x AD1860 + 2 x Motorola XSP56001
D/A converter
PDF
THETA DS PRO GENERATION III
2 x PCM63P-K + 3 x Motorola 56001
D/A converter
PDF
THETA DS PRO GENERATION V
2 or 4 x PCM63P-K + 3 x Motorola 56001
D/A converter
PDF
THETA DS PRO PRIME
PCM67P – Motorola 56001
D/A converter
PDF
THETA DS PRO PRIME II
2 x PCM67P-K – Motorola 56001
D/A converter
PDF
THETA DS PRO PROGENY
1 x PCM67P-K – Motorola DSP56001
D/A converter
PDF
THETA DIGITAL MILES
2 x PCM67P-J – Motorola DSP
Pioneer Stable Platter PEA1343
PDF
THETA PEARL
Transport
Pioneer Stable Platter PEA1343
PDF
THOMSON AD 100
Hitachi HA16633P / PCM53JG-V
Hitachi (DA-1000)
PDF
THOMSON LAD 300
TD6720N
-
PDF
THOMSON LAD 440
2 x PCM56P – YM3433
KSS-210A
PDF
THORENS TDA 2000
2 x TDA1547 – TDA1307
D/A converter
PDF
THULE AUDIO CD100
CS4303
CDM 12.1
PDF
THULE AUDIO DAC200
TDA1547 – SAA7350GP – SM5813APT
D/A converter
PDF
THULE AUDIO Spirit CD100
1 x PCM1716E
CDM 12.4 / KSS-213
PDF
THULE AUDIO Spirit CD150B
2 x PCM1716E
CDM 12.4
PDF
THULE AUDIO Spirit CD150B Digit
4 x PCM1702-K
CDM 12.4
PDF
THULE AUDIO TR200
Transport
CDM 12.4
PDF
TIMBRE TT-1
CS4328 – CS8412-CP
D/A converter
PDF
TOSHIBA XR30
TD6705
KSS-123A
PDF
TOSHIBA XR40
TD6705AP
Toshiba TOPH7810
PDF
TOSHIBA XR-Z50
TD6705AP
Toshiba OPH-32
PDF
TOSHIBA XR-Z70
Toshiba T1587
Toshiba OPH-32
PDF
TOSHIBA XR-Z90
CX890
Toshiba OPH-31
PDF
TRI Triode Supply TR CD1
PCM1702
VAM 1202
PDF
TRICHORD GENESIS
PD2029A
Pioneer PEA

U | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
UHER UCD-210
LC7882
-
PDF
UHER UCD-410R
MN6471M
Hitachi HOP-M3
PDF
UHER X-2
Toshiba T1587
Toshiba OPH-32
PDF
ULTECH HDCD-10
2 x PCM1702 – PMD100 – CS8412-CP
D/A converter
PDF
Unison Research UNICO CD
CS4392 – CS8414
CD-ROM TEAC CD-552
PDF
UNIVERSUM AD2000
2 x TDA1540D – SAA7030
HLPL 030010 (Toshiba OPH-31)
PDF
UNIVERSUM CD1035
LC7881
KSS-210A
PDF
UNIVERSUM CD4315
NEC µPD6376CX – SM5840
KSS-210A
PDF
UNIVERSUM CD4682
PCM56
-
PDF
UNIVERSUM DP2046
PCM53JG-V – YM2201F – YM3511F
MLP-1C
PDF
USHER CD-1
PCM1738
CDM 12.10
PDF
USHER CD-7
CS4398
KSS-213Q
PDF
USHER CD-100
PCM1732
CDM 12.3

V | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
VECTOR RESEARCH VCD-770
PCM54HP
KSS-123A
PDF
VICTOR XL-F3
MN35502 – JVC JCE4313
OPTIMA-6S
PDF
VICTOR XL-M700
1 x PCM54HP – YM2601
OPTIMA-20
PDF
VICTOR XL-V1-N
MN35502 – JVC JCE4313
OPTIMA-6S
PDF
VICTOR XL-V440
1 x PCM54HP – YM2601
OPTIMA-2
PDF
VICTOR XL-V1100
2 x PCM54HP
OPTIMA-1
PDF
VICTOR XL-Z311
2 x PCM56P-L – SM5807EP
-
PDF
VICTOR XL-Z505
JVC – JCE4302A
JVC OPTIMA-5S
PDF
VICTOR XL-Z511
PCM56P
OPTIMA-3
PDF
VICTOR XL-Z521
2 x PCM56P – YM3414
OPTIMA-4S
PDF
VICTOR XL-Z531
JVC – JCE DD-K2-Converter
OPTIMA-4S
PDF
VICTOR XL-Z621
2 x PCM56P-J – YM3414 – YM3613B
OPTIMA-4S
PDF
VICTOR XL-Z711
2 x PCM56P-J – YM3414 – YM3613B
OPTIMA-4S
PDF
VICTOR XL-Z900
JVC – JCE4501 – CXD1244
OPTIMA-4
PDF
VINCENT CD-S1.1
PCM1732
-
PDF
VINCENT CD-S3
PCM1732
CDM 12
PDF
VINCENT CD-S5
PCM1792
VAM1202/12
PDF
VINCENT CD-S6
PCM1732
VAM1202

W | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
WADIA 6
4 x AD1864N-K / 4 x PCM63P-K
VRDS CMK-3 – KSS-151A
PDF
WADIA 7
Transport
VRDS CMK-2 – KSS-151A
PDF
WADIA 8
Transport
VRDS CMK-4 – KSS-151A
PDF
WADIA 12
2 x AD1865
D/A converter
PDF
WADIA 15
4 x PCM63P-K
D/A converter
PDF
WADIA 16
4 x PCM1702-K
VRDS CMK-3 – KSS-151A
PDF
WADIA 20
Transport
VRDS CMK-3 – KSS-151A
PDF
WADIA 21
4 x PCM1702-K
VRDS CMK-4 – KSS-240A
PDF
WADIA 23
2 x AD1865N – XC3042A
Pioneer Stable Platter PEA1030
PDF
WADIA 25
4 x PCM1702
D/A converter
PDF
WADIA 27
PCM1702
D/A converter
PDF
WADIA 270
Transport
VRDS CMK-3.2 – KSS-151A
PDF
WADIA 301
2 x PCM1704
Pioneer Stable Platter PEA1343
PDF
WADIA 302
2 x PCM1704-K
Philips VAE 1250
PDF
WADIA 830
4 x PCM1702
Pioneer Stable Platter PEA1343
PDF
WADIA 831
PCM1704
Pioneer Stable Platter
PDF
WADIA 850
2 x PCM1702-K
VRDS CMK-4-a – KSS-240A
PDF
WADIA 860
4 x PCM1702
VRDS CMK-3.2 – KSS-151A
PDF
WADIA 861
4 x PCM1704-K
VRDS CMK-3.2 – KSS-151A
PDF
WADIA WT2000
Transport
VRDS CMK-3 – KSS-151A
PDF
WADIA WT3200
Transport – SAA7210P
CDM-1

X | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
XINDAK C06
TDA1543
KSS-213
PDF
XINDAK DAC-5
AD1852
D/A converter
PDF
XINDAK SCD 2
PCM1702
-
PDF
XTZ CD-100
AD1955
-

Y | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
YAMAHA CD-1
2 x CX890
Same as Toshiba OPH-31
PDF
YAMAHA CD-1a
CX20017
Same as Toshiba OPH-31
PDF
YAMAHA CD-2
PCM53JP-V – YM2201F – YM3511F
MLP-1C
PDF
YAMAHA CD-3
PCM53JP-V – YM2201F-K
MLP-2A
PDF
YAMAHA CD-350
PCM54HP
MLP-3C
PDF
YAMAHA CD-550
PCM54HP
MLP-3C
PDF
YAMAHA CD-750
PCM54HP
MLP-3C
PDF
YAMAHA CD-1000
1 x PCM54HP-K – YM2601
TAOHS-DG1 / MLP-3C
PDF
YAMAHA CD-2000
1 x PCM54HP-K – 2 x SM5800P
TAOHS-DG1
PDF
YAMAHA CD-4050
2 x PCM58P – YM3414
TAOHS-JP3
PDF
YAMAHA CD-5050
4 x PCM58P-J
TAOHS-HG1 / NX602610
PDF
YAMAHA CDC-625
PCM69
-
PDF
YAMAHA CDC-775
YAC514-F – MN35511
Sharp
PDF
YAMAHA CDV-1070
1 x PCM56P-J
-
PDF
YAMAHA CD-X1
PCM53JP-V – YM2201F – YM3511F
MLP-1C
PDF
YAMAHA CD-X2
YM4006 / PCM53JP-V – YM2201F-K
MLP-2C
PDF
YAMAHA CD-X3
PCM54HP – YM2201
-
PDF
YAMAHA CDX-10
YAC514
KSS-210A
PDF
YAMAHA CDX-390
MN35511
KSS-210A
PDF
YAMAHA CDX-393
MN66271RA
KSS-213C
PDF
YAMAHA CDX-396
MN35511AL
KSS-213C
PDF
YAMAHA CDX-397
CS4392
KSS-213C
PDF
YAMAHA CDX-400
1 x PCM56P
MLP-7
PDF
YAMAHA CDX-410
1 x PCM56P
TAOHS-JP3
PDF
YAMAHA CDX-420
2 x PCM56P-L
-
PDF
YAMAHA CDX-450
PCM67P-J
KSS-210A
PDF
YAMAHA CDX-470
YDC103
KSS-150A / KSS-210A
PDF
YAMAHA CDX-480
MN66271
KSS-150A / KSS-210A
PDF
YAMAHA CDX-490
MN66271R
KSS-210A
PDF
YAMAHA CDX-493
MN66271RA
KSS-213C
PDF
YAMAHA CDX-496
MN35511AL
KSS-213C
PDF
YAMAHA CDX-497
CS4392
KSS-213C
PDF
YAMAHA CDX-500
1 x PCM56P
MLP-7
PDF
YAMAHA CDX-510
PCM56
-
PDF
YAMAHA CDX-520
2 x PCM56P
-
PDF
YAMAHA CDX-530
2 x PCM61P
KSS-210A
PDF
YAMAHA CDX-530E
2 x AD1860N
KSS-150A
PDF
YAMAHA CDX-550E
YM7141 (DAC) – YM3417E (filter)
KSS-210A
PDF
YAMAHA CDX-570
YDC103-F – LC9211
KSS-150A / KSS-210A
PDF
YAMAHA CDX-580
YAC514
KSS-150A / KSS-210A
PDF
YAMAHA CDX-590
YAC514
KSS-210A
PDF
YAMAHA CDX-593
YAC514
-
PDF
YAMAHA CDX-596
AD1854JRS
KSS-213C
PDF
YAMAHA CDX-600
2 x PCM56P-J – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-620
2 x PCM58P – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-630E
TDA1541A – CXD1088
KSS-150A
PDF
YAMAHA CDX-670
YDC103
KSS-150A / KSS-210A
PDF
YAMAHA CDX-700
1 x PCM56P – YM3619
MLP-7 / TAOHS-DG1
PDF
YAMAHA CDX-710
2 x PCM56P-J – YM3414
TAOHS-JP1
PDF
YAMAHA CDX-730
2 x PCM61P-J
KSS-150A
PDF
YAMAHA CDX-730E
2 x AD1860N-J – YM3417D (filter)
KSS-150A
PDF
YAMAHA CDX-750E
YM7141 (DAC) – YM3417E (filter)
KSS-210A
PDF
YAMAHA CDX-800
2 x PCM56P-J – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-810
2 x PCM56P-J – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-820
2 x PCM58P – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-860
YAC507 – YM3433
KSS-210A
PDF
YAMAHA CDX-870
YDC103
KSS-150A / KSS-210A
PDF
YAMAHA CDX-880
YAC514
KSS-150A / KSS-210A
PDF
YAMAHA CDX-890
YAC514
KSS-210A
PDF
YAMAHA CDX-893
YAC514
-
PDF
YAMAHA CDX-900
2 x PCM56P-J – YM3619
MLP-7 / TAOHS-DG1
PDF
YAMAHA CDX-910
2 x PCM56P-J – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-920
2 x PCM58P – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-930
MN6471M
TAOHS-KP2
PDF
YAMAHA CDX-993
YAC514-F – CXD2545Q
Sharp KCP1H
PDF
YAMAHA CDX-1000
2 x PCM56P-J – YM3414 – YM3023
TAOHS-JP3
PDF
YAMAHA CDX-1020
2 x PCM58P – YM3414
TAOHS-JP3
PDF
YAMAHA CDX-1030
MN6471M – YM7402
TAOHS-KP2
PDF
YAMAHA CDX-1050
YAC501-D
TAOHS-KP2
PDF
YAMAHA CDX-1060
YAC506-D – YM7402
TAOHS-KP2
PDF
YAMAHA CDX-1100
2 x PCM56P – YM3404
MLP-7
PDF
YAMAHA CDX-1110
2 x PCM56P-K – YM3414
TAOHS-HGI / VE720301
PDF
YAMAHA CDX-1120
4 x PCM58P-J
TAOHS-HG1 / NX602610
PDF
YAMAHA CDX-2000
2 x PCM56P-K
MLP-7
PDF
YAMAHA CDX-2020
4 x PCM58P-J
TAOHS-HG1 / NX602610
PDF
YAMAHA CDX-2200
2 x PCM56P-K – YM3404
MLP-7
PDF
YAMAHA CDX-5000
2 x PCM56P-K – YM3404
MLP-7 / VD190300
PDF
YAMAHA CDX-10000
2 x PCM56P-K – YM3404-Gold
MLP-7 / VD190300
PDF
YAMAHA DX-U1
2 x PCM56P-K – YM3404 – YM3623B
D/A converter
PDF
YAMAHA GT-CD1
2 x YAC507-N – YSF210B-D – YM3623B
TAOHS-KP2
PDF
YAMAHA GT-CD2
2 x YAC507-N – YSF210B-D – YM3623B
TAOHS-KP2
PDF
YAMAMOTO YDA-01
2 x PCM1794-A – CS8416
D/A converter
PDF
YBA YC201
Wolfson WM8740
-
PDF
YOKO F-420R
PCM56P
-

Z | Top

CD-PLAYER
DAC D/A converter
TRANSPORT
MANUAL
PDF
ZANDEN MODEL 2000
Transport
Philips CD-Pro 2 (VAM 1254)
PDF
ZANDEN MODEL 5000
TDA1541A-S2 (Double Crown)
D/A converter
저작자 표시 변경 금지
신고
Posted by 종합전자




폭스 테리어 한 마리가 축음기의 나팔관에서 마치 주인의 목소리라도 흘러나오는 듯,

가만히 앉아 귀 기울이고 있다.

이 그림은 전 세계적으로 오랫동안 사랑 받아 온 한 음반 회사의 로고다.

소위 '니퍼'라 불리는 이 로고는 1900년 처음으로 광고에 등장했다.

이제 그에 얽힌 뒷이야기를 들어보시길!



니퍼



1884년 영국 브리스톨에 살던 마크 바로(Mark Barraud)

어느 날 떠돌이 개 한 마리를 발견해 집으로 데려온다.

이 녀석은 사람들의 뒤를 따라다니며 자주 다리를 물어뜯곤 했는데,

그런 까닭으로 '니퍼'라고 불렸다.

 3년 뒤 마크가 세상을 떠나자, 화가였던 그의 남동생 프란시스가

자신이 살던 리버풀로 니퍼를 데리고 가 보살폈다.

프란시스의 집에서 축음기를 처음 발견한 니퍼는 마치 이 목소리가 어디에서 나오는

건가 궁금하기라도 한 것처럼 나팔관 앞에 가만히 앉아 고개를 갸웃하곤 했다.

이 모습이 프란시스의 뇌리에 깊이 새겨졌음에 분명하다.

왜냐하면 니퍼가 죽은 지 3년 후, 모습을 그림으로 그려냈으니 말이다.



'주인님의 목소리'



이 그림의 오리지널 버전은 1899년 초에 완성되었는데, 검은색 나팔관에서 나오는

소리를 듣는 개의 모습을 담고 있었다.

1899 2 11일 그림의 저작권을 신청하면서 바로는 '축음기를 바라보며 그 소리를

듣는 개'라는 제목을 붙였으나,

나중에 '주인님의 목소리'로 바꾸었다.

바로는 이 그림을 영국 왕립 아카데미에 전시하려 애썼지만 허사였고,

잡지에 게재해보려 노력했지만 그 역시 마찬가지였다.

'아무도 이 개가 무엇을 하고 있는 건지 모를 텐데요'. 잡지사들의 거절 사유란 그랬다!

축음기의 주요 생산회사였던 에디슨 벨 사에도 그림을 보여주었지만,

역시 아무런 성과가 없었다. '

개가 무슨 축음기를 듣습니까', 라는 대답만이 돌아왔을 뿐이었다


프란시스 바로는 축음기 회사의 주문을 받아, 24개의 복제화를 그렸다.
이 사진의 좌측을 보면 복제화를 그리고 있는 중임을 알 수 있다



베를리너 그라모폰(Berliner Gramophone)

얼마 후 바로는 친구 한 명에게 이런 이야기를 듣게 된다.

검은색 나팔관 대신 금빛 나팔관이 더 모던하지 않겠느냐,

그러면 그림도 돋보일 테고 그림을 팔 기회도 더 생겨날 것이라고 말이다.

프란시스 바로는 그림을 싸들고 새로 문을 연 축음기 회사에 방문해 금빛 나팔관을 빌려달라고 부탁한다.

사장 게리 오언은 바로의 그림을 맘에 들어 했고, “그 그림에 있는 에디슨의 축음기를

우리 그라모폰 사의 제품으로 바꿔 그려준다면 당신의 그림을 사겠소라고 제안했다.

이를 수락한 프란시스는 1899 10 17일 새로운 그림을 보냈다.




축음기를 보고 그 소리를 듣는 개', 원본
-
처음으로 선보인 니퍼의 초상화는 개 한 마리가 검은색 나팔관이 달린

축음기에서 나오는 소리를 듣고 있는 모습이었다.



등록상표



게리 오언의 사무실을 방문한 에밀 베를리너(Emile Berliner, 독일 출신으로 미국에서

활동하며 디스크형 레코드와 축음기를 발명했다)는 벽에 걸린 개와 축음기의 그림을 보게 된다. 베를리너는 바로에게 연락, 판권을 살 수 있는지 타진했고, 이 그림을 가지고 미국으로 돌아가 새로이 설립한 레코드 회사의 등록 상표로 쓰게 되었다.

이후 베를리너는 동료 엘드리지 R. 존슨(Eldridge R. Johnson)에게 이 상표를 넘겨주었다. 그리고 존슨의 '빅터 토킹 머신(Victor Talking Machine)'은 상표의 보호권을 중남미를 비롯해 멀리 아시아와 일본에까지 확대 적용했다.






에밀 베를리너가 고안하고 엘드리지 R. 존슨이 제작한 축음기 개선판.
이 축음기가 바로의 그림에 사용되었다.



광고

미국에서 니퍼 로고는 존슨의 '빅터 토킹 머신'의 신상품 선전 팸플릿에 등장했다. 빅터 사의 카탈로그와 음반 라벨에 니퍼 로고가 새겨진 것이다.

게다가 이 상표는 영국 그라모폰 사의 새로운 상표가 되어, 이 회사의 모든 팸플릿에도 등장했다.

그라모폰 사는 이전부터 이미 '레코딩 엔젤(Recording Angel)'이라는 그림을 사용해왔지만, 개와 축음기 그림으로 대체되었다. 독일의 DGG(Deutshe Grammophon Gesellschaft; 도이치 그라모폰 가젤샤프트) 사에서도 니퍼 로고를 독일어로 번역하여 소개했다.

그러나 음반사간의 상표권 제휴는 제2차 세계대전을 겪으면서 국가간 관계 때문에 어려움을 겪게 되었고,

결국 니퍼 아이콘은 1929 RCA와 합병된 빅터 사에서만 쓰이게 되었다.



주인님의 목소리



프란시스 바로

1924
8 29 69세를 일기로 숨을 거뒀다. 생전에 그라모폰 & 빅터(The Gramophone and Victor) 사의 전 세계 지사들로부터 의뢰 받았던, 니퍼 로고의 복제화 24점을 남겼다.

애석하게도 바로는 니퍼 그림의 저작권을 획득하지 못했다. 그 대신 두 번에 걸쳐 각각 50파운드씩, 100파운드의 수임을 받는 데에 그쳤다. 첫 번째 그림을 넘기며 받은 50파운드는 원본의 복제 이미지를 회사에 넘기는 명목이었으나,

마지막으로 받은 50파운드로 그림에 대한 저작권을 그라모폰 사에 완전히 귀속시켰다.

그라모폰의 후신인 EMI 본사에는 아직도 바로의 원본이 걸려 있다.


미국 특허청의 등록상표 등록서류(no. 34,690)
-1900
7 10일 에밀 베를리너는 '주인님의 목소리' 로고의 상표를

승인 받았다.


'주인님의 목소리', 베를리너 그라모폰의 광고


축음기 회사의 팸플렛


니퍼 로고의 첫 번째 기념물





원문출처 : www.desigineflux.co.kr


저작자 표시 변경 금지
신고
Posted by 종합전자

티스토리 툴바

사업자 등록번호201-02-73828 상호명:종합전자 대표자명:김태완 주소:동대문구 신설동 114-19번지 2층 종합전자 TEL:02-2238-6626 H.P:010-9050-3142
